Summary of Contents for Kinetik HERETIK
- Page 2 Axle to Axle is the length of the bow measured from the center of one cam axle to the other. Brace height is the distance between the string and the pivot point of the bow grip (deepest position of the bow grip).
- Page 3 Your Kinetic Heretik bow is warranted to be free of defects in materials and workmanship for the lifetime of the original owner when purchased from an Authorized Retailer. This warranty includes all bow parts, except the string, buss cable, cable glide and cosmetic appearance.
- Page 4 Never work on or attempt to shoot your bow while on medication or while using drugs or alcohol which may impair your judgment, physical abilities or reflexes. Doing so can result in damage to the bow, serious injury or even death. Your bow is a precision instrument.
- Page 5 Damaged strings and cables will adversely affect the performance of your bow. This can result in further damage to other bow components and may cause serious injury yourself those around you. Any damaged bow parts or accessories should be reported to your authorized retailer for inspection or replacement.
- Page 6 Damage caused by shooting an arrow that is too light will not be covered under warranty. Shooting an underweight arrow has an effect similar to that of a dry-fire and may cause serious injury to yourself and those around you. If you are unsure about the arrow compliance to your bow, contact your...
- Page 7 Make sure that there are no people, animals, buildings, roads or other objects behind or near your target. Ensure that your backstop is large enough to catch a stray arrow and thick enough so that the arrow will not be able to pene- trate completely through it.
- Page 8 Once you have set the draw weight, you need to readjust the location of the string suppressor. Change the location of the string suppressor by loosening the set screws and ensure that the string rests on the rubber suppressor. Once in place, secure the set screws.
- Page 9 Never expose your bow to excessive heat or prolonged moisture. Avoid storing your bow for extended periods of time in places such as in a garage, attic, or in the trunk of a vehicle as this can subject your bow to extreme heat or moisture.
- Page 10 This cam system offers good performance and adjustability. The draw length of the Heretik compound bow can easily be adjusted from 24” to 26“ on the small cam and from 26.5” to 29.5” on the large cam. You can safely and easily adjust it with an Allen wrench.
- Page 11 Small Cam : 24 – 26 inch draw length IBO DRAW LENGTH (inch) 25.5 24.5 Large Cam : 26.5 – 29.5 inch draw length IBO DRAW LENGTH (inch) 29.5 28.5 27.5 26.5...
- Page 12 The Kinetic Heretik bow offers 72% let-off with a 99.4 stored energy curve. An ideal hunting and speedbow for more competitive archer, that will push your boundaries and take your scores to a higher level. Thank you for choosing a Kinetic Heretik Bow!
