SPT SH-113FB User Manual

PORTABLE WARMER
SH-113FB (Black)
SH-113FP (Pink)
SH-113FW (White)
User manual
Thank you for your purchase. Please read this user manual thoroughly
before using. Keep in safe place for future reference.
This product contains Li-Batteries inside. Before initial
use or after a long period of non-usage, please fully
charge the warmer.
* Be cautious of low temperature burn.
* Li-Batteries are rechargeable up to 500 times and will
retain up to 80% of standard capacity.
PART IDENTIFICATION
Power Key
(On/Off, High,
Low)
Indicator Light
front
USB to Mini USB cable
USB to AC power adapter
CHARGING
USB power
Personal computer / laptop
 Connect Mini-USB plug of dedicated charging line into
warmer's Mini-USB socket.
 Connect USB plug of dedicated charging line to
standard USB equipment, such as PC, notebook, etc.
* While charging, unit will power off (heat function
stops) and Power key will not respond.
When charging is complete, all lights will illuminate
with no rotation.
* Charging time is approximated 5 hours.
 Disconnect cable when charging is completed.
* Charge unit within ambient temperature of 32-104°F.
* If charging causes static in radio or TV, please relocate unit to a
different location.
OPERATING INSTRUCTIONS
Backaches
Cold hands
Muscle pain
Mini USB
interface (B-
female socket)
Heat plate
Lanyard hole
back
Menstrual pain
 In OFF mode, press and hold the Power Key for 3
seconds to turn on warmer. Lights will rotate twice
(clockwise)
 Warmer will begin to heat in Low setting.
 Double click the Power Key to switch between Low
and High setting.
 To turn off warmer, press and hold Power Key for 3
seconds. Lights will rotate twice (counter-clockwise).
 Heat function will turn off when warmer is in charge.
 When using the warmer in very cold weather, the
heating temperature may not be sufficient enough. To
isolate from cold environment, it is suggested to wrap
the warmer with cloth, such as a sock or glove.
* Only the metal side of the warmer will heat.
* Power Key doesn't work in charge mode.
REMAINING BATTERY CAPACITY
Indicated once after warmer is turned on (after the lights rotate twice
clockwise).
LIGHTS STATUS
Lights step slowly from 1 to 4
then back from 4 to 1
Lights step slowly from 1 to 3
then back from 3 to 1.
Lights step slowly from 1 to 2
then back from 2 to 1
Light 1 blinks
LIGHTS STATUS
LIGHTS STATUS
Two lights blink slowly on and off
Four lights blink slowly on and off
Four lights constantly rotate counter-
clockwise
Four lights remain on
Fast clockwise rotation (twice)
Fast counter-clockwise rotation (twice)
HEATING TEMPERATURE
Heat Highest
Setting Temperature*
Low 104°F
High 113°F
* Highest temperature: temperature standing after 1 hour.
** Average temperature based on 68°F ambient temperature.
*** Usage time may vary due to different ambient temperature.
SPECIFICATION
Model
Input
Dimension
Weight (unit only)
Heat temperature range
Operating temperature range
Batteries (inside)
Charge time
Heating time
CAUTION
Do not use warmer
in high moisture
environments, such
as bathroom.
Avoid impact
CAPACITY
≤100%
≤75%
≤50%
prepare to charge
≤25%
low capacity
please charge soon
INDICATION
Heating in low setting
Heating in high setting
Charging
Charging completed
Turning on
Turning off
Average Usage
Temperature** Time***
100°F Approx 10 hrs
106°F Approx 7 hrs
SH-113F
5V – 1A
3.57L x 2.6W x 0.8H inches
3.175 oz.
100°F ~ 113°F
14°F ~ 113°F
Li-batteries 3.7V 2600mAh
Approx 5 hours
Approx 7 ~ 10 hours
Do not place in
oven; keep away
from heat sources
Do not use near
flammable or
explosive objects
