Power On Remote Display
1. Install the battery pack or
connect to a DC power source.
2. Connect antenna.
3. Press Execute for two
seconds; display enters the
4. Press the Down arrow to
access the Main menu.
Remote Display Main Menu
Remote Mode
Power off
Use the arrow buttons to highlight menu options and
Execute to select. Use the Remote Mode locating screen
during drilling.
Settings
Use the Settings menu to set the following items:
Telemetry channel
Receiver model
Telemetry frequency designation
Depth units
Pitch units
DCI recommends setting the units (m, degrees) to match
those on the receiver.
© Apr 2015 Digital Control Incorporated
All rights reserved. 402-1012-21-A metric 9/2
Settings
www.DigiTrak.com
1
Arrow
buttons
Execute
button
F Series
Display
(FSD)
