Janus Remote Communications LTE910CF User Manual

Cat1 embedded cellular modem
Hide thumbs Also See for LTE910CF:
Table of Contents

Advertisement

Quick Links

Download this manual
LTE910CF CAT1 Embedded
Cellular Modem User Manual
Bulletin
JA03-UM-LTE-Cat1
Revision
P01
Date
04 April 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LTE910CF and is the answer not in the manual?

Questions and answers

Related Manuals for Janus Remote Communications LTE910CF

Summary of Contents for Janus Remote Communications LTE910CF

  • Page 1 LTE910CF CAT1 Embedded Cellular Modem User Manual Bulletin JA03-UM-LTE-Cat1 Revision Date 04 April 2018...

  • Page 2: Table Of Contents

    5 LTE910CF TECHNICAL SPECIFICATIONS ........................16-23 5.1 Electrical Specifications ........................... 15-19 5.2 Mechanical Specifications............................. 5.3 Setting Up a Terminal Emulator for use with the LTE910CF Modem ............... 21-23 6 DESIGN CONSIDERATIONS .............................. 24 6.1 Minimum Required Module Pin Connects......................6.2 Debug ..................................

  • Page 3: Applicability Table

    LE910 Module. Telit LE910 V2 AT Commands Reference Guide Telit LE910 V2 Hardware User Guide Telit HE/UE910, UL865 Digital Voice Interface Application Note LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 3 Rev: P01 Date: 04/04/18 Specifications subject to change without notice ©...

  • Page 4: Overview

    1.100 PIN 1 PIN 25 .100 TYP 2.400 LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 4 Rev: P01 Date: 04/04/18 Specifications subject to change without notice © Copyright 2018 Janus Remote Communications All Rights Reserved See website for latest revision.

  • Page 5: Lte Features

    1.8v UART (TRACE) 1.8v PWRMON SIM CARD SIM CARD Figure 1 LTE910CF CAT1 Block Diagram LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 5 Rev: P01 Date: 04/04/18 Specifications subject to change without notice © Copyright 2018 Janus Remote Communications All Rights Reserved See website for latest revision.

  • Page 6: Fota Notice

    4 INTERFACES 4.1 Interface Voltage Selection The LTE910CF is equipped with a variable voltage interface solution. This allows the user to match the device to the system’s level without extra hardware. Once a voltage has been injected, the unit will swap to the chosen voltage immediately for the affected I/O.

  • Page 7: Interfaces

    • Parity: None • Hardware Handshaking: Yes The LTE910CF does not support autobaud, and must be changed via the AT+IPR command. It is defaulted to 115200 bps Note: If you are not using Hardware Handshaking, please note that RTS must be connected to GROUND for proper communications where flow control is unused.
  • Page 8 4.2.2.1 USB Connection Diagram When VBUS_ENABLE is HIGH the VBUS 5.0v signal will be passed to USB_VBUS, (pin 29) turning the USB ON. Figure 3 USB Connection Diagram LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 8 Rev: P01 Date: 04/04/18 Specifications subject to change without notice ©...

  • Page 9: Power Supply

    The 910CF modules use a DVI audio interface which will not work with the analog audio inerface of the other Plug- In modems. The LTE910CF supports PCM master mode and can use a CODEC to convert the interface to analog.

  • Page 10: Plug-In Pin-Out

    4. RTS must be connected to GROUND if flow control is not used. 5. Not used on the LTE910CF 6. Refer to the electrical specifications for I/O levels LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 10 Rev: P01 Date: 04/04/18 Specifications subject to change without notice ©...

  • Page 11: Vrtc Details

    IRTC = N/A For Example, using the LTE910CF numbers: Btime = 96 hours (4 days) C = 1.0F LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 11 Rev: P01 Date: 04/04/18 Specifications subject to change without notice © Copyright 2018 Janus Remote Communications All Rights Reserved See website for latest revision.

  • Page 12: Gpio Details

    4.7.4 I2C The I2C interface is an alternate function of the modem’s GPIO, for the LTE910CF, those two signals are designated for GPIO 9 (SDA) and GPIO 10 (SCL) and are 1.8V logic level to match the DVI interface for easy usage with a codec. The signals are not pulled up on the Plug-In module and must be pulled up externally as they may also be used as spare GPIO.
  • Page 13 7. It is required to stop driving terminal inputs high when turning ON the Plug-In module by floating or bringing them low. If this is not done, power sequencing issues may occur. Figure 7 On / Off Pin Diagram LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 13 Rev: P01 Date: 04/04/18 Specifications subject to change without notice ©...

  • Page 14: Internal Interfaces

    A regulator power supply output that is provided in order to supply small devices from the module itself. When PWRMON is HIGH, VAUX will be ON. When PWRMON is LOW, VAUX will be OFF. On the LTE910CF, the VAUX signal voltage will match to the VL IN voltage if utilized.

  • Page 15: Rf Interface

    THT version. 4.13 Screw Mounting The LTE910CF allows for the use of a #4 machine screw to help keep a socketed module in place where environmental variables may cause problems otherwise. If the user wishes to have a stand-off underneath the module to help alleviate possible stress from mounting hardware, below are the Janus part numbers and associated drawings for an available solution.

  • Page 16: Lte910Cf Technical Specifications

    WCDMA data call (RMC, TX = 23dBm) Note: WCDMA only available on LTE910 V7.00 Note: Values are calculated based on power supply efficiency. LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 16 Rev: P01 Date: 04/04/18 Specifications subject to change without notice ©...
  • Page 17 Volt It is required that this input be controlled by an Open Collector/Drain Output. Do not use an external pull-up resistor, a pull-up is included internal to the Modem. LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 17 Rev: P01 Date: 04/04/18 Specifications subject to change without notice ©...
  • Page 18 >24dBm Average Power ≤ 10:1 VSWR Absolute Max ≤ 2:1 VSWR Recommended LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 18 Rev: P01 Date: 04/04/18 Specifications subject to change without notice © Copyright 2018 Janus Remote Communications All Rights Reserved See website for latest revision.
  • Page 19 CL = 50 to 600 pF Fall time CL – 50 to 600 F Rise/fall time matching LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 19 Rev: P01 Date: 04/04/18 Specifications subject to change without notice © Copyright 2018 Janus Remote Communications All Rights Reserved See website for latest revision.

  • Page 20: Mechanical Specifications

    5 LTE910CF TECHNICAL SPECIFICATIONS continued 5.2 Mechanical Specification LTE910CF Figure 10 LTE910CF Mechanical Dimensions LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 20 Rev: P01 Date: 04/04/18 Specifications subject to change without notice © Copyright 2018 Janus Remote Communications All Rights Reserved See website for latest revision.

  • Page 21: Setting Up A Terminal Emulator For Use With The Lte910Cf Modem

    • Enter AT<cr> from terminal and wait for OK Note that Autobaud is not supported on the LTE910CF Modem. If you are utilizing the serial interface and you wish to change the baud rate on the module, you must use AT+IPR. You must also change the rate in the host UART (i.e.
  • Page 22 5.3 LTE910CF GETTING STARTED continued 5.3 Setting Up a Terminal Emulator for Use With the LTE910CF Modem continued 5.3.3 Setting Up Service – Network Settings 5.3.3.1 Set Up The network settings for the Modem will vary depending on the cellular carrier you are using. Below are two of the North American Cases for these settings.
  • Page 23 5.3 LTE910CF GETTING STARTED continued 5.3 Setting Up a Terminal Emulator for Use With the LTE910CF Modem continued 5.3.5 Making a Data Call Data connections require that the carrier’s Access Point Name (APN) be properly set in the data contexts using the AT+CGDCONT command.

  • Page 24: Design Considerations

    • PWRMON • USB D+ • USB D- • USB V_BUS • USB_ID LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 24 Rev: P01 Date: 04/04/18 Specifications subject to change without notice © Copyright 2018 Janus Remote Communications All Rights Reserved See website for latest revision.

  • Page 25: Appendices

    GPRS General Packet Radio Service WAAS Wide Area Augmentation System Global System Mobile LTE910CF Plug-In Hardware User Manual JA03-UM-LTE-Cat1 Page 25 Rev: P01 Date: 04/04/18 Specifications subject to change without notice © Copyright 2018 Janus Remote Communications All Rights Reserved See website for latest revision.

  • Page 26: Ordering Information

    LTE Cat.1 Plug-In Modem - AT&T Revision History Revision Revision Date Note 06/21/17 Preliminary LTE910CF CAT1 Individual Plug-In User Manual 04/04/18 Addition of documentation and block diagram edit Division of The Connor-Winfield Corporation 2359 Diehl Road • Aurora, IL 60502 Phone: 630.499.2121...
