Installation
and
Operation
Manual
Convection Oven
MODELS
CO5TG
CO5TE

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the CO5TG and is the answer not in the manual?

Questions and answers

Summary of Contents for Bake Max CO5TG

  • Page 1 Installation Operation Manual Convection Oven MODELS CO5TG CO5TE...
  • Page 2: Table Of Contents

    10. MAINTENANCE 11. DIGITAL CONTROLLER 12. OPERATION 13. ELETRIC SCHEMATICS 14. EXPLODED VIEW / PARTS LIST 15. PARTS LIST CO5TG 16. EXPLODED VIEW CO5TE 17. PARTS LIST CO5TE WARRANTY TERM FOR YOUR SAFETY Do not store or use gasoline or other flammable vapors or liquids in the vicinity of this or any other appliance.
  • Page 3: Introduction

    They should make arrangements so that children do not play with the equipment. - The Convection Oven Gas (CO5TG) is manufactured in model NATURAL GAS, with optional for GLP (propane gas), with the voltage being 240V.
  • Page 4: Installation Requirements

    1. Remove all packaging and transit protection including all protective plastic coating from the exterior stainless steel panels. 2. Check the oven and supplied parts for damage. Report any damage immediately to the carrier and distributor. 3. Check that the following parts have been supplied with your oven:- CO5TG CO5TE Manual...
  • Page 5: Cleaning

    5. GAS INSTALLATION INSTRUCTIONS THIS APPLIANCE IS INTENDED FOR OTHER THAN HOUSE HOLD USE All BakeMax commerical gas appliances are manufactured by skilled craftsman using the finest quality materials. PROPER installation by qualified personnel is essential for safe, efficient, and trouble-free operation of the unit. Any alteration and/or tampering, without proper knowledge, tools, and test equipment, is DANGEROUS and will void all warranties.
  • Page 6 GAS CONNECTION - The gas inlet line size of this appliance is 3/4" NPT. For proper operation, the gas supply service line must be the same size or greater than the inlet line size of the appliance. The gas line size must not be reduced at any point along the supply line.
  • Page 7: Operating Instructions

    Before connecting the regulator, check the incoming line pressure as these regulators can only withstand a maximum inlet pressure of 14" W.C. (1/2 PSI); exceeding this pressure will damage them. If the gas supply line pressure is greater than this amount, a step-down regulator will be required.
  • Page 8 PROPANE GAS CONVERSION INSTRUCTIONS A griddle is equipped with xed ori ce hoods and shipped from the factory for use on natural gas. To convert to propane gas, install the propane burner ori ce hoods supplied as follows: 1 - Remove the griddle plate by lifting with two people and set a side. 2 - Slide the burners back o of the valve ori ce hoods a couple of inches and let it rest.
  • Page 9 6. ELETRIC INSTALLATION INSTRUCTIONS Installation - Electric Utility Connections-Standards and Codes The installation instructions contained here are for the use of quali ed installation and service personnel only. Installation or service by other than certi ed / licensed personnel will void the warranty and will result in damage to the oven and/or injury to the operator. Quali ed installation personnel are individuals, a rm or a company which either in person or through a representative are engaged in and responsible for the installation of electrical wiring from the electric meter, main control box or service outlet to the electric appliance.
  • Page 10 7. TWO STATE OPENING DOOR The Convection Oven's doors have two (2) opening stages. Below is a statement of the door opening position in its two (2) stages. 1st Opening 2nd Opening Stage Stage 8. CLEANING To perform the equipments cleaning, it must be completely disconnected from the power grid in order to avoid accidents. To clean, use a damp cloth with water and mild detergent, taking care not to damage the electrical components.The inner chamber is easy to clean, it is completely enamelled, which facilitates the procedure.
  • Page 11: Technical Data

    It is possible to clean inside of the double glass door, to do this, remove the top and bottom M5 screws holding the Internal Glass Lock using a screwdriver - Flat Tip (Philips) 1/4 "x 6" (Fig . 3). Remove the screw that holds the Internal glass latch Open Internal...
  • Page 12: Maintenance

    10. MAINTENANCE Before any electrical, mechanical or hydraulic maintenance, make sure that the equipment is disconnected from the power grid and that the deterring or register valves valves are completely closed. IMPORTANT: The maintenance of the equipment should only be performed by professional technician authorized by the manufacturer.
  • Page 13: Digital Controller

    11. DIGITAL CONTROLLER 12. OPERATION 1 - In the control panel turn to the right on / off switch , it will be illuminated. With the door closed, the engine will start working and the light will turn on automatically. OBS .: the internal light will be lit throughout the procedure, until the on / off switch is switched off.
  • Page 14: Eletric Schematics

    13. ELETRIC SCHEMATICS CO5TG On / Off Neutral safety thermostat motor thermic door switch protection(PTC) J-Type Thermocouple Door Door Lamp Lamp 24V input 24V input Environment thermostat command 127V input 127V input CO5TE Phase Phase 6500W 240V Resistence Phase on / off 320°C...
  • Page 15 14. EXPLODED VIEW CO5TG...
  • Page 16: Parts List Co5Tg

    15. PARTS LIST CO5TG Item Description Code SENSOR BASE 8.02.13.07000082 8.02.13.05000023 TOP HINGE LOWER FRONT BASE 8.02.13.05000029 TOP CLOSURE 8.02.13.05000030 CONTROL PANEL 8.02.13.05000017 EXTERNAL ROFF 8.02.13.05000028 FIXED ILLUMINATED CSW SWITCH (on-off key) 2.80.02.00381555 LEFT SIDE 8.02.13.05000015 LOWER OUT FRONT FINISHING 8.02.13.05000018...
  • Page 17: Exploded View Co5Te

    16. EXPLODED VIEW CO5TE...
  • Page 18: Parts List Co5Te

    17. PARTS LIST CO5TE H PÑÖ Description Code SENSOR BASE 8.02.13.07000082 ‫و‬ TOP HINGE 8.02.13.05000023 8.02.13.05000029 LOWER FRONT BASE TOP CLOSURE 8.02.13.05000030 CONTROL PANEL 8.02.13.05000017 EXTERNAL ROFF 8.02.13.05000028 FIXED ILLUMINATED CSW SWITCH (on-off key) 2.80.02.00381555 LEFT SIDE 8.02.13.05000015 LOWER OUT FRONT FINISHING 8.02.13.05000018 LAMP SET 8.02.13.05002300...
  • Page 19: Warranty Term

    W A R R A N T Y T E R M METALÚRGICA VENÂNCIO LTDA offers a warranty to manufactured equipment as is specified below: Every alleged manufacturing defect must be analysed only by technical assistance from VENÂNCIO. When proven, an eventual manufacturing defect repair will be free of charge. Equipment repaired without proper authorization from the manufacturer or altered, disassembled and/or utilized ajar from the indications presented in their respective guides, are not covered by this warranty.
  • Page 20 170 Millennium Blvd, Moncton, NB, E1E2G8 3601 Pinnacle Point Dr, Dallas, TX 75211 Toll Free: 1-800-565-BAKE(2253) Telephone: 1-506-858-8990 Fax: 1-506-859-6929 E-mail: sales@bakemax.com Web site: www.bakemax.com...
