Installation &
Operation Guide
ADS35/60
Mixer Amplifier
PLEASE NOTE: THIS MANUAL AND THE NOTES CONTAINED HEREIN ARE
COPYRIGHT AND MAY NOT BE REPRODUCED EITHER WHOLLY OR IN PART, IN ANY
WAY WHATSOEVER, WITHOUT WRITTEN CONSENT OF ADSworldwide.
Audio Design Services Ltd, St David's House, Adcroft St, Higher Hillgate, Stockport, Cheshire SK1 3HW,UK.
www.ads-worldwide.net
TEL: +44 (0)161 666 6363
FAX: +44 (0)161 666 6366. WEB:
© 2018
1
Advertisement
Table of Contents
Related Manuals for ADS Worldwide MP35
Summary of Contents for ADS Worldwide MP35
- Page 1 Installation & Operation Guide ADS35/60 Mixer Amplifier PLEASE NOTE: THIS MANUAL AND THE NOTES CONTAINED HEREIN ARE COPYRIGHT AND MAY NOT BE REPRODUCED EITHER WHOLLY OR IN PART, IN ANY WAY WHATSOEVER, WITHOUT WRITTEN CONSENT OF ADSworldwide. Audio Design Services Ltd, St David’s House, Adcroft St, Higher Hillgate, Stockport, Cheshire SK1 3HW,UK. www.ads-worldwide.net TEL: +44 (0)161 666 6363 FAX: +44 (0)161 666 6366.
- Page 2 Product Compliance to EC directives for Standard Products All standard products conform to the relevant directives, regulations and standards for electronic and associated apparatus. The equipment is CE marked both on the apparatus and the packaging. Our products meet the appropriate British and International standards. A product ‘Declaration of Conformity’...
-
Page 3: Product Description
1. Product Description 1.1 Introduction The ADS35/60 is a small mixer amplifier, compact, cost-effective. Suitable for small PA systems and background music. 1.2 Introduction 2 microphone inputs, 1priority input, 1 or 2 aux inputs, 1 – output. 100V, 70V constant voltage output and 4Ω ~ 16 Ω constant impedance output. ... -
Page 4: Rear Panel
6. TREBLE adjustment Adjust high frequency. 7. MASTER Vol Adjustment Adjust volume level of all inputs. 8. Power switch 9. Indicator Power, protection, signal level 2.2 Rear panel Power line socket AC~110-240V/50-60Hz Power input DC24V input DC 24V power input. 4-16Ω... - Page 5 MIC2 input XLR socket for connection of balanced microphone. 10. MIC2 gain adjustment Adjust to obtain a suitable input sensitivity. 11. Priority input (350mV, 6.3mm Jack) This input has highest Vox priority. 12. Priority input (100V, Phoenix interface) This input can be used for connection to an existing 100V line loudspeaker circuit. 13.
- Page 6 Technical Specifications Model MP35 MP60 Rated power MIC1 & 2 Input sensitivity AUX、 350mV Priority ≥60 dB Signal to Noise ≥70 dB AUX、 Priority 100Hz-10kHz Frequency response AUX, priority 80Hz-16kHz ≤0.2%（1kHz ,1/3 output voltage） Operating temperature -20℃-50℃ Rated output 70V/100V or 4-16Ω...
