Summary of Contents for Datafox ZK-Box V4

  • Page 1 Manual Datafox ZK-Box V4 Flexible data collection with method...
  • Page 2 Datafox GmbH. The assertion of all rights in this respect is reserved to Datafox GmbH, especially in case of the grant of a patent. The handover of this documentation does not establish a claim to the license or the use of the soft- and hardware.
  • Page 3 Datafox MasterIV, SW version xxx.pdf list as shown. The file is located on the Datafox DVD and for download on the homepage. Please also note the instructions in each chapter in the manual. The updates are available on our website under www.datafox.de download.

  • Page 4: Table Of Contents

    3.8. Disposal ........................8 System Requirements / Hardware 4.1. System Structure ....................... 9 4.2. Requirements for Operating Datafox Devices ............9 4.3. Kompatibilität Compatibility ................... 10 4.3.1. Firmware File Archive (*.dfz) ..................10 4.3.2. Datafox Devices and Device Firmware ..............10 4.3.3.
  • Page 5 Configuration of Access control adn stuckture ............47 5.7.2. Description of Tables for Access Control 2 ..............50 5.7.3. Wirering variants for the ZK/AC (Access control Box) ZK-Box V4 ......52 5.7.3.1. Wire in a star form for the AC-Box ................52 5.7.3.2.
  • Page 6 IO-Box V4 / ZK-Box-V4 / Mobile-Box 6.1. communication modules ..................96 6.2. access modules ....................... 96 6.3. Module digital in and out ..................96 6.4. Modules miscellaneous ................... 96 Index Manual Datafox ZK-Box V4 page VI date: 16.01.2018 Version: 04.03.06.XX...

  • Page 7: For You Safty

    For you Safty Safety Information for Datafox Products The must only be operated according to the instructions given in the manual. Do no insert any foreign objects into the openings and ports. The device must not be opened. All maintenance work must only be performed by authorized specialists.

  • Page 8: Introduction

    Datafox data terminals have been developed to fulfill the requirements of modern personnel time recording where users have high demands concerning flexible and elegant design. Furthermore, the Datafox Embedded-Concept also covers access control. All relevant data can be recorded with modern technology and be transferred to the analysis software immediately.

  • Page 9: Typography Of The Documentation

    Due to technical development, illustrations, function steps, procedures and technical data may vary slightly. The Datafox device has been developed for the purpose of creating a flexible and easily inte- grated terminal for data recording serving for a great variety of applications. The device is robust and easy to use.
  • Page 10 Note: Due to DatafoxStudioIV, Datafox devices offer many functions and combinations of  functions not all of which can be tested in the case of updates. This applies especial- ly to setups defined by you as customer.

  • Page 11: Intended Use And Environmental Protection

    Extreme environmental influences may damage or destroy the device and should be avoided. This includes fire, extreme sunlight, water, extreme cold and extreme heat. See respective type label of the device. Manual Datafox ZK-Box V4 page 5 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 12: Mounting Outdoors

    We recommand, if you use the devices outsite, then let it running permanently. Both in terms of temperature as well as condensation, it is recommended to not switch off devices which are used outdoors. Manual Datafox ZK-Box V4 page 6 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 13: Repair

    Except for the battery replacement in mobile devices , Datafox devices are maintenance-free and must only be opened by authorized professionals. In case of defects, please contact your dealer or the Datafox service hotline. If a definite defect is present, you can also send the device directly to Datafox. 3.6. Cleaning CAUTION Risk of explosion if batteries are replaced improperly.

  • Page 14: Disposal

    The correct disposal of electrical and electronic equipment protects human life and the environment. For more information regarding the disposal of electrical and electronic equipment, please contact your local authorities or waste disposal companies. Manual Datafox ZK-Box V4 page 8 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 15: System Requirements / Hardware

    4.2. Requirements for Operating Datafox Devices In order to operate the Datafox device, you need a 230 V power connection for the Datafox power supply. Depending on the main communication set, you need a corresponding transfer medium or connection cable.

  • Page 16: Kompatibilität Compatibility

    Device files (*.hex) of the MasterIV devices are delivered in a common firmware file archive. It has the file extension DFZ (stands for Datafox Zip). Now simply the firmware file archives (*.dfz) are in- dicated instead of the device files (*.hex). This applies to the DatafoxStudioIV and the DLL. The in- dication of device files (*.hex) is still possible.

  • Page 17: Device Firmware And Communications Dll

    A newer version of DatafoxStudioIV does not work with an older DLL. 4.3.6. DatafoxStudioIV and Device Setup With the DatafoxStudioIV, you create a device setup (application program) for the Datafox device. That means that in the setup only those functions were defined which were available in the Data- foxStudioIV version at the time of the setup creation.

  • Page 18: Update / Downgrade

    When performing a firmware downgrade the firmware has to be transmitted to the device twice. This has technical reasons. Errors shown on the display of the device after the first transfer can be ignored. Manual Datafox ZK-Box V4 page 12 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 19: Device

    Keep in mind the message - FlashService - in the display of the device. It means that the live time of the flash memory according to the manufacturer instruction will be reached soon. Then the device has to be sent to Datafox for service.

  • Page 20: Guidline For Commissioning

    Access control ► Finishing installation of the device ► Setting for man communication 5.2.3. Troubleshooting during Commissioning ► Please see the FAQ on our website: http://www.datafox.de/faq-de.html. ► Tips: o Connection to the device cannot be set up via TCP/IP ...

  • Page 21: Communication Of Hardware V4 Devices

    The type of communication depends on the device. All possible communications are listet in the device.  Note: Datafox-devices are able to communicate encrypted. „DatafoxStudioIV“. Read more in the manual for the The switching of the communication can be done via : 1.

  • Page 22: Automatic Dedected Conectet Usb To Pc

    If the device is connected to a pc no other connections (for example Wi-Fi) will happen If the USB-cable is disconnected it will automatically switch to the configured main com- munication Manual Datafox ZK-Box V4 page 16 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 23: Installing Usb Driver For Hardware V4 Devices

    Follow the instructions on the screen: Caution: Only use the driver wich are delivered with the device! Note:  If you have DatafoxStudioIV installed the USB-driver will already be installed on your Manual Datafox ZK-Box V4 page 17 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 24: Comunication / Record Transfer Via Usb-Stick (Host)

    Lists of access control can be transferred individually, operation lists must always be transmitted in complete form. All lists defined in the setup must also exist on the stick in the "List" directory. Manual Datafox ZK-Box V4 page 18 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 25: Error Message By Using Usb-Stick (Host)

    Error by checking the handle, the file is not open Error write protect Error by the record stucture Error duren the firmware update No USB stick Incorrect password No list Manual Datafox ZK-Box V4 page 19 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 26: Communication Via Tcp / Ip

    The LAN / WLAN configurations are saved in a file with the filename extension "*. df0". Here you now have the possibility to edit the file, load it into the Datafox device (upload) or read it from the device (download).

  • Page 27: Communication Tcp / Ip Via Network-Cable

    For devices with display, the IP address can also be entered directly on the device. Press ESC and ENTER simultaneously to enter the Bios menu of the device. More information can be found in the chapter „bios menu“. Manual Datafox ZK-Box V4 page 21 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 28: Communication Tcp / Ip Via Wlan / Wifi

    When setting the encryption AES or WEP, only one type is used at a time. The setting AES+WEP means for some access points that AES encryption is performed first and then additionally encrypted with WEP. In this case, only set AES. Manual Datafox ZK-Box V4 page 22 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 29 WLAN connection. The user therefore has no insight into the dial-in parameters at the various locations.  Hint: With automatic selection of the configuration / location, the first attempt is always made to establish a connection with the default schema. Manual Datafox ZK-Box V4 page 23 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 30: Location Selection In The Bios Menu Wlan

    Recommended setting We recommend the following setting: - WPA2 - AES - Shared/PSK Datafox uses the following access points internally for testing: - Longshine LCS-WA5-45 IEEE802.11g - WatchGuard XTM WEB UI - Longshine IEEE802.11n - TP-Link WR841N v6/v7 00000000 Setting Access-Point...

  • Page 31: Communication Via Cellular Network (Gprs)

    Wir empfehlen T-Mobile oder Vodafone als Provider für Mobilfunk einzusetzen! Un- sere Erfahrung zeigt, dass bei anderen Anbietern mit häufigeren Einwahlen und da- mit auch verzögerter Datenübertragung und ggf. mit höheren Kosten gerechnet wer- den muss. Informationen zu M2M: http://www.t-mobile.de/business/machinetomachine/m2m-im-einsatz/0,23219,26762-_,00.html Manual Datafox ZK-Box V4 page 25 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 32: Communication Via Sms

    Caution: Enter the phone number always with a country code. Example.: +49161458 The device can be saved 128 SMS. Then there is additional as follows to clear the oldest SMS. Manual Datafox ZK-Box V4 page 26 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 33: Receive Sms

    (default setting). Save you an empty Key, then receive the device every SMS. The last received SMS can you see in the Bios-Menu under „general information Bios (Menu)“. Manual Datafox ZK-Box V4 page 27 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 34 Connection to the server with the saved parameters in the „active mode“. b) and c) Connection on Port 8000 to the server (www.datafox.de/123.123.123.123). d) Connection to the server “www.datafox.de” and port “4711”. Manual Datafox ZK-Box V4 page 28...
  • Page 35 Control a technical system and send a SMS in trouble: Is the level of regulation from the system not correct then gives a report via SMS. The Datafox MasterIV is here not the regulator. He gives only a report in trouble. If necessary, a procedure also can be done.

  • Page 36: Communication Via Rs485

    BUS A BUS A Pin 15 - BUS B BUS B BUS B Pin 14 - BUS A Pin 1 - GND Pin 1 - GND Pin 7 - GND Manual Datafox ZK-Box V4 page 30 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 37: Operation With Box-Devices V4

    Click on Configuration Click on „Device configuration (Bios)“ Use the corectly com port. You see the Datafox Virtual COM Port in the device manager of you PC: Click on, „Switch to BiOS mode“ Manual Datafox ZK-Box V4 page 31...
  • Page 38 Cklick on “Switch to BIOS mode“ Manual Datafox ZK-Box V4 page 32 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 39 The volume of the buzzer can also set here. Caution: Alle new settings first accepted after a device reboot.  Note: Further information about GPRS, TCP/IP setting you find in the Manual “DatafoxStudioIV”. Manual Datafox ZK-Box V4 page 33 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 40: Led Status Display With Box Devices V4

    10 Hz + alle LEDs Kurz ein 1 Hz flashing Setup communication 50 ms active flash GPRS 1 KHz connect 50 ms on Saved records 2450 ms off Memmory full Manual Datafox ZK-Box V4 page 34 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 41: Mounting Of The Box Devices

    A mounting clamp for top-hat rails can be ordered as an option for the devices. Item Number: 119401 Rear view of the mounted Example application: The mounting clamp is box on a hat-rail ZK-Boxes installed in an factory-installed: electrical distribution board. Manual Datafox ZK-Box V4 page 35 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 42: Connecting Of The Box

    - Memmory active - Button , no function View on the left: Relay Relay -Button , no function - USB Micro Description of the different modules ZK-Box V4 Number Modul description Modulplace 1 ground RS 485 for access reader (ZK-Bus ID...
  • Page 43 It can also modules are installed, which are not listed here. Please refer to the chapter "Module assemblies for EVO" for the exact connection for the respective module. Manual Datafox ZK-Box V4 page 37 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 44: Power Supply Of The Box

    Reverse polarity protected plug 12 V bis 24 V DC  If you use the Datafox standard Power supply (12V, 1,5A) the can you use the power for one access control reader per pus line connector.  If you use an external Power supply then don’t use the power of the access control plug.

  • Page 45: Power Via Poe

    IEEE 802.3af 15,4 Watt 12,95 Watt PoE+ IEEE 802.3at 25,4 Watt 21,90 Watt If power is supplied via POE, an external access-reader can also be supplied via the access control plug. Manual Datafox ZK-Box V4 page 39 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 46: Modules For Devices Of Hardware V4

    5.6.4. Modules for devices of hardware V4 5.6.4.1. Description of the various extension modules The Datafox devices of the generation V4 are particularly distinguished by the variable configuration of individual modules. Depending on the device, a certain number of module locations are available.
  • Page 47 You see here, in the IO-Box are Modulplaces usable. This can be indi- vidually fitted. Exceptions: Modulplace 8, only here TCP is possible. RS 485 for access control - maximum 4 Modules can be fitted. Manual Datafox ZK-Box V4 page 41 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 48: Read Out Important Module Information From The Device

    5.6.4.3. Read out important module information from the device Click on: "Configuration -> Device Configuration BI- OS" Then click on "Status" thereafter Click "Read". Manual Datafox ZK-Box V4 page 42 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 49 Status of the digital outputs: Output 1 is continuous here from left to right. Analog inputs from left to right with respective currently applied voltage. Number of stored records in the device and memory used. Manual Datafox ZK-Box V4 page 43 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 50: Connection Of The Individual Modules

    Analog inputs, 4 times analog IN common ground; GND / Ground + 0-10 V Signal 4 + 0-10 V Signal 3 + 0-10 V Signal 2 + 0-10 V Signal 1 Manual Datafox ZK-Box V4 page 44 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 51: Times Digital Out

    4 times digital IN Connectiom example (Connection of 4 contacts): e.g.: 4x digital in max. 30V 0 - 1,5 V Input logical 0 3,5 V - 30 V Input logical 1 Manual Datafox ZK-Box V4 page 45 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 52: Bus For Access Control

    Furthermore, the connection for a digital input and output is available. The pin assignment looks as follows: How the individual access components are connected or wired, can be found in the chapter "Access control" Manual Datafox ZK-Box V4 page 46 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 53: Connection And Wirering Of The Accesscontrol

    When adding comments, you have to notice that in a comment line no field values can be given and that the comment line has to start with a semicolon. The table Reader.txt might look like this: RefLocation RefAction PinGeneral Manual Datafox ZK-Box V4 page 47 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 54 Online / offline after time-out is a combination. If the serv- er is unavailable, the terminal can decide on basis of its lists whether to grant access to a person or not. Manual Datafox ZK-Box V4 page 48 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 55 (19.00) on all weekdays. The corresponding relay is at the door module with the bus number 2. Reader.txt RefLocation RefAction PinGeneral Time.txt Weekdays TimeEnd TimeEnd 10:00 12345 00:00 12345 16:00 00:00 1234567 07:00 19:00 Action.txt RefReader PortOut Elapse RefTime Manual Datafox ZK-Box V4 page 49 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 56: Description Of Tables For Access Control 2

    Indicates the assigned time model. (0 = not used) During this time access is RefTime granted. Thus, also "‘half holidays"’ like New Year’s Eve can be realized. (Time) Table Holiday (setting blocking days like holidays or company holidays) Manual Datafox ZK-Box V4 page 50 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 57 The time model indicates when the output may be switched. (0 = not used) (int) Table Action (list of all workable actions in the access control system; an action group, i.e. all ac- tions with the same action number, can switch several relays) Manual Datafox ZK-Box V4 page 51 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 58: Wirering Variants For The Zk/Ac (Access Control Box) Zk-Box V4

    5.7.3. Wirering variants for the ZK/AC (Access control Box) ZK-Box V4 The can be optionally equipped with up to 3 access control bus connections RS485. This results in a variety of connection variants for setting up an access control system.
  • Page 59 Supply12 V DC for the AC-Reader ; 3A plug 4 poles for AC-Bus off / on plug 5 poles for digital in/out max. 30 V / 2A Power supply for the door opener Manual Datafox ZK-Box V4 page 53 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 60 Supply12 V DC for the AC-Reader ; 3A plug 4 poles for AC-Bus plug 5 poles for digital in/out max. 30 V / 2A Power supply for the door opener Manual Datafox ZK-Box V4 page 54 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 61: One Bus For Access-Control, 5 Relays In The Ac-Box V4

    / RS485 Busadress 3 / Bus ID 1 reader / RS485 Busadress 4 / Bus ID 1 reader / RS485 Busadress 5 / Bus ID 1 AC-Box V4 (Master device) Manual Datafox ZK-Box V4 page 55 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 62 5 poles for digital in/out number 4 plug 5 poles for digital in/out RS 485 number 5 RS 485 max. 30V / 2A Power supply for the door opener Manual Datafox ZK-Box V4 page 56 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 63 Busadresss RS 485 Resistor for terminate the bus: max. 2,5m Nr. 5 distribution box max. 30 V / 2A Power supply for the door opener Manual Datafox ZK-Box V4 page 57 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 64 5 poles for digital in/out number 4 plug 5 poles for digital in/out number 5 RS 485 RS 485 max. 30 V / 2A Power supply for door opener Manual Datafox ZK-Box V4 page 58 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 65: Two Rs485 Bus Lines And Use The Relay On The Reader

    / RS485 Busadress 1 / Bus ID 2 reader / RS485 Busadress 2 / Bus ID 2 reader / RS485 Busadress 3 / Bus ID 2 ZK-Box V4 (Master device) Manual Datafox ZK-Box V4 page 59 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 66 AC-Bus RS 485 Plug 5 poles connect on the reader RS 485 Plug 5 poles connect on the reader max. 30 V / 2A power supply for the door opener Manual Datafox ZK-Box V4 page 60 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 67  / ~ – / ~ RS 485 C max. 5m ISTY 2x2x0,8  / ~ RS 485 – / ~ C max. 5m ISTY 2x2x0,8  / ~ – / ~ Manual Datafox ZK-Box V4 page 61 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 68: Access Control Ii With Evo-Zk-Plus-Reader

    RGB colours. The control of the LED is con- trolled exclusively by the readers firmware. access denied = red - access permitted = green - Bios activated = blue - Manual Datafox ZK-Box V4 page 62 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 69: Display For State Of Acces Control

    5.7.4.4. Errormessage error communication The reader is in constant communi- cation with the master. If communication is interrupted, this is indicated by the text "Communi- cation error" on the reader. Manual Datafox ZK-Box V4 page 63 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 70: Bios-Menu

    The following information can be called up in the general con- figuration: - Installed firmware, serial number - Memory allocation for the image memory - Transponder test for the transponder configured in the mas- ter setup. Manual Datafox ZK-Box V4 page 64 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 71: Display Configuration

    The bus terminating resistor of 120 Ω is switched on or off in the bus configuration under "Terminating resistor". Note: If it is the last or only reader in the RS485 bus, the termi- nating resistor must be switched on. Manual Datafox ZK-Box V4 page 65 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 72: Function Extention For Access Control Ii

    All readings of RFID on this reader make all actions in the table “action“, with the ID 3000. Tabelle Time Weekdays TimeStart TimeEnd Description text 1234567 00:01 23:59 24houers opening possible 1234567 07:00 16:00 Time for special action Manual Datafox ZK-Box V4 page 66 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 73 Menace ActiveStart ActiveEnd Active Description 1111 2005-01-01 2015-12-31 Master of Garage 2222 2005-01-01 2015-12-31 Skilled workers 3333 2005-01-01 2015-12-31 Facility manager Facility manager second RFID-chip, 4444 2005-01-01 2015-12-31 only for closing the door Manual Datafox ZK-Box V4 page 67 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 74 Then tenant use the transponder to give only the switch for his floor free. In cabin of the elevator is install the RFID-reader. The Datafox-Device is on the top of the cabin. - RS485 Bus to the reader in the cabin...
  • Page 75 2005-01-01 2099-12-31 floor Tenant of an apartment on the 1102 2005-01-01 2099-12-31 floor 1 and 2 Tenant of an apartment on the 1104 2005-01-01 2099-12-31 floor 1, 2 and 3 Manual Datafox ZK-Box V4 page 69 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 76: Description Of The Table „Action2

    Would you like to continue working with the "action" table, the table "Action 2" may not be transferred to the device. A table "Action 2" has already been transferred to the device, it must be cleared by load- ing a new setup. Manual Datafox ZK-Box V4 page 70 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 77: State Message Off Access Control

    6 is low (Off). 56 # digital output 6 is HIGH.(On). 57 # digital output 6 is for the time ELAPSE, HIGH. for new devices hardware version 4 Manual Datafox ZK-Box V4 page 71 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 78 12 isLow 171# digital input 12 is HIGH _____ ____continuously until: 210# digital input 32 is Low 211# digital input 32 is HIGH for new devices hardware version 4 Manual Datafox ZK-Box V4 page 72 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 79 1 alarm-input 2 alarm-input 3 alarm-input 4 alarm-input 1 alarm-input 6 220# alarm-input 7 221# alarm-input 8 _______ _____ continuously until: 245# alarm-input 32 for new devices hardware version 4 Manual Datafox ZK-Box V4 page 73 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 80 State message off access control in a record: Note: Do you want see the status from accses control, to coose this settigs in the Setup.  Manual Datafox ZK-Box V4 page 74 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 81: Online Funktions For The Access Control

    With the anser from the server you are able to perform specific actions with the access readers The following examples will give you an insight in what is possible with the functions and actions. All parameters correspond the online functions with the dll. Manual Datafox ZK-Box V4 page 75 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 82 For this, the new keywords "module" and "master" were implemented. These must be used togeth- er, replacing the keyword "access". Attention: The order “access->mask->typ->duration” or master->module->mask->typ- >duration must be strictly adhered to. status=ok&checksum=2482&access=010&mask=5&type=1&duration=2 status=ok&checksum=2482&master=1&module=010&mask=5&type=1&duration=2 Manual Datafox ZK-Box V4 page 76 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 83 You can also perform multiple actions on the access control in one response. However, the total length of the response must not exceed 254 characters. Attention: A automated switch between online and offline mode is not possible in http mode Manual Datafox ZK-Box V4 page 77 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 84: Online Via Dll Connection

    LEDs. More dll functions are documented in the “Datafox SDK” on our website http://www.datafox.de/software- de.html?file=tl_files/Datafox_Devices/Downloads_Geraete_Zubehoer/MasterIV-...

  • Page 85: Funkcionfor Access Control U&Z (Locking Cylinders)

    The electronic locking systems read an RFID chip / card and transmit the read information to Data- fox access control. The Datafox access control then decides on the basis of the access logic wheth- er the door is opened or not.
  • Page 86 Construction example ZK-Box V4 with two external radio modules. Bus Nr. TCP / IP (LAN) range ca. 10 m 12V via power supply unit Bus Nr. RS 485 ZK Bus-ID 1 range ca. 10 m Bus Nr. RS 485 ZK...

  • Page 87: First Start With Locking Cylinders

    2nd) The knob module is mounted in the cylinder housing by inserting and simultaneously rotating it.(A+B) 3) To reset the disassembly mode, hold the disassembly card or an authorised transponder in front of the knob module.(C) Manual Datafox ZK-Box V4 page 81 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 88: Set Up The Wireless Network For Cylinder

    Teach out: The cylinder is removed from the FSM and can be taught in to another FSM.  Teach-in: To connect a radio lock cylinder to the FSM (the radio lock cylinder then only communicates with this FSM) Manual Datafox ZK-Box V4 page 82 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 89: Battery State And Live Time

    Battery status of the radio lock cylinders in phase 1 Battery status of the radio lock cylinders in phase 2 Battery status of the radio lock cylinders in phase 3 (empty) Radio lock cylinder set to battery change mode Manual Datafox ZK-Box V4 page 83 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 90: Change The Access Control Master Id And Nob Active Time

    FSM is established and the connection remains active as long as the Knob Active Time is active. Useful values are between 2 and 10 seconds. By default, this time is set to 3 seconds. Manual Datafox ZK-Box V4 page 84 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 91: Optische Und Akustische Signale Des U&Z Schließzylinders

     (out of range) short  short  = = red flashing red lights up  = = green flashing green lights up = long low tone = short beep Manual Datafox ZK-Box V4 page 85 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 92: Unterstützte Transponderverfahren Und Einschränkungen

    - read UID - Read file (max. 220Byte) Not supported is - Random UID (Read true UID at Random UID badges) Legic Prime and Legic Advant currently no restrictions are known. Manual Datafox ZK-Box V4 page 86 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 93: Data On Card

    3031323334353637383941424344454630 …… 6987986 Franz Zufall The terminal stores where the data is written to the ID card (e.g. segment) Doors with electronic locking cylinder or similar. Current authorization yes / no Manual Datafox ZK-Box V4 page 87 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 94: Settings For Using Dataoncard

    When importing via the DLL, the data needs to be passed on as binary data. Using the DFC GetField, DFC GetField list functions, you are working with strings, while the firm- ware converts the hexstrings to and from the binary data. Manual Datafox ZK-Box V4 page 88 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 95 1. ) RFID Configurations for the RFID reader The transponder configuration for the reading can be freely selected. However, firstly it needs to be defined in the basic transponder settings. Manual Datafox ZK-Box V4 page 89 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 96  Please note: First, complete the transponder configuration, then create the list with the binary field and finally parameterize the field function Data on Card. Manual Datafox ZK-Box V4 page 90 date: 16.01.2018 Version: 04.03.06.XX...
  • Page 97 0x30, 0x31, 0x32, 0x33, 0x34 ……  Please note: When a 3-tone sequence is signaled, the Data-On-Card option is not available on this de- vice. The option has to be purchased afterwards. Manual Datafox ZK-Box V4 page 91 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 98: Dataoncard On The Access Control Reader

    Only one access control reader (ZK) can be connected to the bus at any time. Dip switch 1 and the termination of the bus must be set to "ON" (Bus address 1). Manual Datafox ZK-Box V4 page 92 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 99: Dataoncard An A Aceess Control Reader - Wirering

    ZK-Knoten Wireringplan for EVO-access reader with using DataOnCard: EVO-access-reader connector ZK-Knoten Wireringplan for PHG-access reader with using DataOnCard: RS 485 bus line up to 500m in a twisted pair cable Manual Datafox ZK-Box V4 page 93 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 100: Barcode Reader

    From this 255 characters can you coppy maximum 60 in a global variable. More information about cut a value find you in the manual DatafoxStudioIV in the chapter "Normal (value transfer from ID card, etc ...)". Setting in the DatafoxStudioIV: Manual Datafox ZK-Box V4 page 94 date: 16.01.2018 Version: 04.03.06.XX...

  • Page 101: Tecnical Date Io-Box V4 / Zk-Box-V4 / Mobile-Box

    -20 ° C to +70 ° C (Power Supply -20 ° C to +60 ° C), IP20 Software Configuration program Setup program (Datafox-Studio) to configure without programming effort Communication tools http, DLL or C source code for inclusion in the application...

  • Page 102: Communication Modules

    RS485 Width 20mm RS485 connection for the access reader, relay modules, ... power supply from 1 external reader when using Datafox power supplies with Access Control-IO Width 20mm 1 relay changeover, 42 V AC, DC 60 V, 2 A, max. 60 W; 1 digital input for monitoring door, ...

  • Page 103: Index

    Kommunikation umstellen 31 LED 34 power supply 38 POE 39 SMS 26 System Requirements / Hardware 9 TCP/IP 20 tecnical date IO-Box V4 / ZK-Box-V4 / Mobile- Box 96 USB 15, 17 Manual Datafox ZK-Box V4 page 97 date: 16.01.2018 Version: 04.03.06.XX...
