Page 1 JET VAC COMPACT Jet Vac Compact...
Page 2 JET VAC COMPACT JVC 44/15...
Page 3 JET VAC COMPACT Interpretation of the symbols placed on the unit BEFORE USING THE STEAM GENERATOR, READ AND FOLLOW THIS INSTRUCTION MANUAL. IT IS RECOMMENDED TO KEEP THIS INSTRUCTION MANUAL TO CONSULT IT LATER OR TO GIVE IT TO THE FOLLOWING OWNERS.
Page 4 JET VAC COMPACT ENVIRONMENT PROTECTION ALL THE PACKINGS ARE RECYCLABLE, PACKINGS DO NOT HAVE TO BE THROWN IN THE DOMESTIC WASTE BUT THEY HAVE TO BE DELIVERED TO THE CENTERS SPECIALIZED FOR THE DISPOSING OF THE WASTE. DEVICES NOT USED ANYMORE CONTAIN PRECIOUS RECYCLABLE MATERIALS THAT SHOULD BE DELIVERED TO THE CENTERS SUITABLE FOR THE DISPOSING OF THE WASTE.
Page 5: Table Of Contents
JET VAC COMPACT SUMMARY SUMMARY SAFETY REGULATIONS PREFACE TECHNICAL CHARACTERISTICS PARTS LIST TECHNICAL DRAWINGS OPERATING INSTRUCTIONS MAINTENANCE BEFORE REFERRING TO THE TECHNICAL SERVICE DECLARATION OF CONFORMITY 2. SAFETY REGULATIONS  It is recommended not to open or remove any machine part for any reason; in case the unit should present an abnormal functioning or a failure, disconnect the power plug and contact an authorized service center or the dealer where the product has been purchased.
Page 6 JVC 44/15...
Page 7 JET VAC COMPACT  ATTENTION. Do not use the appliance within the range of persons.    ATTENTION. The high pressure jets can be dangerous if not used properly. The jet does not have to be directed against persons, electrical devices under tension or the unit itself.  ...
Page 8: Preface
With the goal of improving and continually updating production by always offering innovative products, JVC has studied, designed and created the JET VAC COMPACT, a combined model for cleaning which brings together the power of steam and the force of vacuuming.
Page 9 JVC 44/15...
Page 10: Technical Characteristics
JET VAC COMPACT TECHNICAL CHARACTERISTICS FACTORY: JVC SRL VIA DEI SASSI 1A 37026 PESCANTINA VERONA ITALY Model Jet Vac Compact Rated Voltage Current type 50/60 Rated Power Boiler Max Rated Power Rated Steam Pressure 1200 Permissible Steam Pressure Max. Steam Rated Flow g/min Max.
Page 11 JET VAC COMPACT NOMENCLATURE 1) Vacuum cleaner motor head 35) Detergent switch 35A) Hot water switch (optional) 2) Vacuum cleaner power switch 35B) Detergent/hot water switch (optional) 03) Clamping hooks for vacuum drum 36) Steam adjustment switch - minimum 04) Vacuum drum (5,5 – 7,5 liters)
Page 12: Technical Drawings
JET VAC COMPACT TECHNICAL DRAWINGS JVC 44/15...
Page 13 JET VAC COMPACT H2O Optional KIT RADAMES OPEN BLOK JVC 44/15...
Page 14 JET VAC COMPACT H2O Optional KIT JULY BLOCK OPEN BLOCK JVC 44/15...
Page 15 JET VAC COMPACT JVC 44/15...
Page 16 JET VAC COMPACT CONTROL PANEL 9 – Control panel 10 : “Power / Stand-by” button 11 : “Power / Stand-by” indicator 12 : “Boiler” button 13 : “Boiler on” indicator 14 : “Steam Ready” indicator 15 : “Low Water” indicator...
Page 17: Operating Instructions
JET VAC COMPACT OPERATING INSTRUCTIONS (a) After opening the packaging box, insert the main handlebar (18) onto the trolley base and block into place by inserting the large basket (17) into the bottom holes of the handlebar. Then insert the small basket (16) into the top holes of the handlebar.
Page 18 JVC 44/15...
Page 19 JET VAC COMPACT Hour counters The device is equipped with two hour counters, one resettable by the user and one non resettable. To visualize the hours, switch the device off by using the button (10), subsequently press the button (12), every time you press this button you can read the respective partial hour counter and total hour counter.
Page 20 JET VAC COMPACT 7.1. OPERATING OF JET VAC COMPACT WITH KIT RADAMES Attention!! It is recommended to switch the steam generator off before connecting the steam hose to the steam outlet. Insert the vacuum hose (75) into the vacuum hose outlet (6) and the steam plug (34) into the steam outlet (27) on the machine.
Page 21 (33) and the suction conduits. Wash and dry all accessories used. Remove the vacuum drum (4) and, after emptying and rinsing it, let it dry before storing it away. 7.2. OPERATING OF JET VAC COMPACT WITH KIT JULY Attention!! It is recommended to switch the steam generator off before connecting the steam hose to the steam outlet.
Page 22 JET VAC COMPACT 7.3. OPERATING OF JET VAC COMPACT WITH KIT STAR Attention!! It is recommended to switch the steam generator off before connecting the steam hose to the steam outlet. Insert the vacuum hose (75) into the vacuum hose outlet (6) and the steam plug (34) into the steam outlet (27) on the machine.
Page 23: Maintenance
JET VAC COMPACT MAINTENANCE 8.1. Maintenance of the boiler ATTENTION DESCONNECT THE UNIT FROM THE ELECTRICAL POWER SUPPLY BEFORE CARRYING OUT USER MAINTENANCE. ATTENTION. BURNING DANGER The boiler cleaning must be carried out when the equipment has cooled down (i.e. switched off for at least 5 hours) - for this reason we suggest to maintain the boiler in occasion of the following use, as long as at least 5 hours have passed.
Page 24 JVC 44/15...
Page 25 JET VAC COMPACT 8.2. Maintenance of the vacuum cleaner The vacuum cleaner of JET VAC COMPACT models does not require any specific maintenance. Always clean the drum and filter after use. 8.3. Maintenance of the tools Grease occasionally joints on the extension tubes and on the accessories.
Page 26: Before Referring To The Technical Service
JET VAC COMPACT BEFORE REFERRING TO THE TECHNICAL SERVICE PROBLEM POSSIBLE CAUSE REMEDY Machine does not produce steam and Lack of power. Make sure that the plug (26) is well inserted and that vacuum does not work. the main switch of the building is activated.
Page 27: Declaration Of Conformity
JVC S.R.L. con la presente dichiara che: la macchina per pulizia a vapore modello: (Certifies that the steam cleaning machine model:) Chattanooga Jet Vac Compact Risulta conforme alle specifiche delle direttive (conforms to the specifications of directives) 2006/95/CE 2004/108/CE 2006/42/CE 2002/95/CE Per il controllo della conformità...
Page 28 JET VAC COMPACT Ordinary maintenance procedures Generator working Frequency Notes hours intervention JVC 44/15...
Page 29 JET VAC COMPACT Extraordinary maintenance procedures Generator Date of working intervention Intervention description, replaced components etc. hours JVC 44/15...
Page 30 JET VAC COMPACT NOTES JVC 44/15...
Page 31 JET VAC COMPACT JVC 44/15...
Page 32 JET VAC COMPACT THE MANUFACTURER RESERVES THE RIGHT TO BRING TECHNICAL AND STRUCTURAL IMPROVEMENTS WITHOUT PRIOR NOTICE. Via dei Sassi 1/A, Pescantina (VR) Italy - Tel. +39 045 6767252 Fax. +39 045 6703631 – E-mail: JVC@JVC.it – www.JVC.it JVC 44/15...
