Sinar Sinarback S 30|45 Short Instructions

Short Instructions
Sinarback S 30|45
Mobile and Versatile
THANK YOU
Congratulations on your purchase of this high-quality
Sinar product. It was carefully manufactured by using
top quality material and thoroughly tested for perfor-
mance and reliability. We are very pleased you have
chosen Sinar and thank you for your confidence. Sinar
combines highest demands on technology, materials,
design and ease of operation. This equally applies to
professional cameras, electronics and accessories.
USER MANUAL
Before use, please read the operating instructions
carefully to correctly operate the Sinarback and fully
benefit from all the possibilities and advantages. The
manual can be downloaded from our website:
www.sinar.swiss → Support → Download
→ Brochures and Manuals
1 — APPLICATION
Sinarback S 30|45 and
lenses in Copal Shutter (CPL/CEF)
1 2 3
4 5 6 7
– USB cable
– Flash connection
– WLAN connection
– Trigger Cable Copal S 30|45 (S07080)
1 – Sinar CaptureFlow
2 – Sinarback app (IOS device)
– Flash
3
4 – Sinarback S 30|45 (S09010)
5 – S 30|45 Adapter (S09120, S09121 or third party)
6 – Sinar p3, Sinar lanTec or third party view camera
7 – CPL-lenses, CEF-lenses or lenses in Copal shutter
Sinarback S 30|45 and lenses in Sinar eShutter
1 2 3
e
4 5 6 7
– USB cable
– Flash connection
– WLAN connection
– Sinar eShutter/S30|45 Triggercable 50 (S07013)
– Sinar CaptureFlow
1
2 – Sinar eShutter Control (S04620)
3 – Flash
– Sinarback S 30|45 (S09010)
4
5 – S 30|45 Adapter (S09120, S09121 or third party)
6 – Sinar p3, Sinar lanTec or third party view camera
7
– Lens in Sinar eShutter
Sinarback S 30|45 and Sinar S-CS Adapter
1 2 3
4 5 6 7
– USB cable
– Flash connection
– WLAN connection
– Sinar CaptureFlow
1
– Sinarback app (IOS device)
2
3 – Flash
4 – Sinarback S 30|45 (S09010)
5 – S 30|45 -EL Adapter (S09121)
6 – Sinar S-CS-Adapter (S09150)
7 – Leica S (CS) lens
2 — WORKFLOW SOFTWARE
Efficient workflow and perfect color management.
Control your Sinarback remotely and compose your image
while shooting. The focus layer is set precisely using three
focal points, which you can activate separately. The shading
function allows you to correct color effects and vignetting. The
overlay function is a great tool for easy and precise position-
ing of the subject.
Sinar CaptureFlow supports Apple® MacIntosh® computers
with Intel processors with Mac OS X 10.10, or higher. Sinar
CaptureFlow can be downloaded from our website:
http:// www.sinar.swiss → /support-en-us/#!/1 Support →
Downloads → Software → Customer Area → Create New Ac-
count (if you do not have one yet)
— Pic. 1 "Screenshot of Sinar CaptureFlow"
3 — SINARBACK APP (iOS)
You can either control the Sinarback remotely using your
smartphone/tablet or you can use your smartphone/tablet as
an external storage medium. To do this, the Sinarback app
must first be installed on your smartphone/tablet.
This app is available in the Apple® App Store for iOS
devices.
— Pic. 2 "Camera" — Pic. 3 "Video"
— Pic. 4 "Play"
Above and on the left, three
screenshots of the "Sinar-
back" app can be seen:
Pic. 2 "Camera"
for capturing images
Pic. 3 "Video"
for recording videos
Pic. 4 "Play"
to review all the captured
images and videos
