Ogden ETR-9004 Instruction Manual

1/8 DIN Solid State Temperature
All temperature indicators in this series are made to fit
into panel cut-outs which measure 1
92mm). A minimum of 3
for electrical clearances of rear terminal connections.
The following specifications are common to all models:
INPUT
Thermocouple (T/C)
RTD
Cold Junction
Compensation
Input Break
Input Impedance
Common Mode
Rejection (CMR)
Normal Mode
Rejection (NMR)
POWER
Rating
Accuracy
Consumption
ENVIRONMENTAL & PHYSICAL
Operating Temperature 10° to 125°F (-12 to 52°C).
Humidity
Insulation
Breakdown
Vibration
Shock
Weight
Indicator Model ETR-9004
13 ⁄ " x 3 5 ⁄ " (46mm x
1 6 8
1 ⁄ " (89mm) in depth is required
2
Type K, J. Specified on
Control Label.
PT 100 ohm, 2 or 3-wire
( = .00385) DIN
( = .00392) JIS
Automatic
Built-in, upscale on open
sensor.
1M ohm.
CMRR 120dB, Min.
NMRR 60dB, Min. (60Hz)
120/240VAC field
selectable, 50/60Hz.
12-24VDC models
available on special order.
0.2% of SPAN.
Less than 3VA.
5 to 90% RH (non-
condensing).
20M ohm Min., (5000VDC).
2000VAC, 50/60Hz,
1 minute.
10 - 55Hz, Amplitude
1.0mm.
660 ft./S 2 (20g.)
11 oz. (312 grams)
INSTRUCTION
MANUAL
DIMENSIONS
DIN Case
MOUNTING
When mounting the instrument, it is important the
instrument remains within the ambient temperature
range of 10 to 125°F. Mounting it in any position is
permissible. After inserting the instrument into the
panel, secure it with the mounting bracket provided with
each unit.
• Both solderless terminals or "stripped" leads
can be used for power leads. Only "stripped" leads
should be used for thermocouple connections to
prevent compensation and resistance errors.
• Take care not to over-tighten the terminal screws.
• Unused control terminals should not be used as
jumper points as they may be internally connected,
causing damage to the unit. This indicator is not
to be used in hazardous locations as defined in
Article 500 of the National Electric Code.
MANUAL #27
H – 1 7 ⁄ " (48mm)
8
W – 3 3 ⁄ " (96mm)
4
D – 3 1 ⁄ " (83mm)
4
Depth behind panel – 3"
(76mm)
Plastic, with screw
terminals on rear,
adjustable brackets for
panel mounting.
