Summary of Contents for HOME ALARM 4099

  • Page 2 BEFORE INSTALLING AND USING THIS SYSTEM, YOU ARE STRONGLY RECOMMENDED TO READ THIS MANUAL CAREFULLY. 一、 BEFORE USING THE SYSTEM: 1. Make sure all the arming zones are working normally. 2. Avoid heavy impacts and unnecessary disassembly which might incurs accident or man-made damage.
  • Page 3 （6） Independent defense zone setting （7） Multi-way to arm and disarm (by remote controller, keyboard ,regular,mobilephone) （8） 36 event log that easily be managed the alarming scene （9） listen to the record and monitor the alarming scene using mobile phone when receiving phone calls.
  • Page 4 Position Pin switch Remote Enable (DEFAULT) Disable control switch Password Reset system Normal (DEFAULT) Reset switch If you forgot password, you can put this DIP to ON, then turn off the power, then turn on the power again, the system’s password will return to “000000”.
  • Page 5 （Picture 2） （1） power supply indicator( red): Permanently on when turning on the control panel （2） arm/disarm indicator(red) –arm : Permanently on when under status of arming, off when the unit is disarmed. （3）AC fault indicator (red): Permanently on AC power supply is off AC. （4）LCD display : display for menu and alarm event log （5）...
  • Page 6 （Picture 3） （1） Antenna: Pull out the antenna when operating the unit for better signal receiving. （2）Microphone: For monitor the alarming scene through Mobilephone. （四）ARCHITECTURE OF THE CONTROL PANEL（Picture 4） （Picture 4） （1） Telephone port: AC：18V input，For connection of power transformer（connected） Phone In: for connection of the main phone line...
  • Page 7 (Notice:If the system shares a same phone line with your daily-used telephone ,make sure the main phone line goes in the system first, then you can connect yours telephone to the PHONE OUT connector. This is to eliminate the possibility of faiture in the telephone which might block the system to get in touch with you when there is a alarming) （2）...
  • Page 8 （Picture 6） (5)Keypad (picture 6) 1、KEY * ： cancel the present operation and go to the previous menu. # : confirm the present operation and go to the next menu ARM: (1) As cursor key under status of setting or as the backspace key when editing. (2) Press the button once, the mainframe will give a short “Bi”...
  • Page 9 locates , the control panel enter the arming status if pressing “#”.(the control panel will never store the setting for next time using this way ②： ”arm” for turning on all audio defense zone and “mute” for turning on all mute defense zone (the control panel has memory function if using the way for setting) ③：...
  • Page 10 number ,repeat the process to set the 3 telephone, press “arm” to modify the input number. （4） ．CMS The system can be connected with centre monitoring station ,CMS telephone number and user’s code is needed. （5） ．Record and record playback Record is for recording message that can be heard when receiving alarm call from the control panel, the max.
  • Page 11 No.”,press “#” again after input the defense zone No., press the code learning button on the detector for 3 second when seeing “* * defense zone code is learning” display on the LCD ,the code is successfully learnt when hearing “DIDI”. Remark：...
  • Page 12 4.2.3.4 alarm delay zone the alarm delay zone is mainly for the special defense zone that needs delay alarm after the unit is triggered.”advantage menu”- “system setting”-“enter alarm delay” and set the time for delay. 4.2.4 ID card 4.2.4.1 Id card code learning The LCD displays “please read the card”...

  • Page 13: Event Log

    4. 2. 6 Event log 4. 2. 6. 1 check the event log input an event log number and the last alarm time and zones will be displayed on the LCD, then check other event logs by using “arm” or “mute” Note: the max.

  • Page 14: Alarm And Remote Control

    detecting function is being set. 4．2．7．10 restore default setting This option will restore all the setting into factory default status 4．2．8 time arming and disarming 4．2．8．1 time arming Select on to turn on the time arming function and select the exact date during a week: Press “1”...
  • Page 15 Picture 8 （2）Mute alarm If mute alarm is selected, the systems will autodial the preset phone No. and the siren will never make a sound when the system is being triggered. Note: the setting will never be successful if any of the below items are not set. ①input preset Telephone numbers ②telephone line should be inserted.
  • Page 16 seconds. Within this 20 seconds, each press on the “3#” can delay the duration for another 20 seconds. If there is no operation within the 60 seconds, the phone will be hung up automatically and the auto dialer will continue to call other preset phone numbers. Press: “5#”...
  • Page 17 Ⅶ, Troubleshoot and solution : Problems The possible reasons solution The power light not brighten The battery out of power or Recover to supply the electricity or recharge the Not connected with the electrical battery. source All Wireless signal are invalidation Was disturbed by the same Contact with the dealer.
  • Page 18 (6) Preset telephone number: 5 groups (7) Standby battery: 12V 4.5AH SLA battery (8) Built-in siren :>85db (9) Standby time:≥20 hours. (10) The size of mainframe: (11) wireless receiving distance: ≥ 150m (12) defence areas: wireless area 16, wired defence area 8.
