amc VIBRO AV ACQUISITION 4001 User Manual

4-channel data acquisition module with gain
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
amc VIBRO Sp. z o.o.
ul. Pilotow 2e,
31-462 Krakow, Poland
T: +48 (12) 362 97 60
S: + 48 (12) 362 97 63
info@amcvibro.pl
KRS No.: 0000618618
REGON No.: 364497010
VAT No.: PL6772403385
www.amcvibro.pl
AV ACQUISITION 4001
/ ©AMC VIBRO Sp. z
4-CHANNEL DATA ACQUISITION
MODULE WITH GAIN
USER MANUAL
2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the AV ACQUISITION 4001 and is the answer not in the manual?

Questions and answers

Summary of Contents for amc VIBRO AV ACQUISITION 4001

  • Page 1 AV ACQUISITION 4001 / ©AMC VIBRO Sp. z 4-CHANNEL DATA ACQUISITION MODULE WITH GAIN USER MANUAL amc VIBRO Sp. z o.o. ul. Pilotow 2e, 2018 31-462 Krakow, Poland T: +48 (12) 362 97 60 S: + 48 (12) 362 97 63 info@amcvibro.pl...

  • Page 2: Table Of Contents

    InstaCal ....................................8 DASYLab® 16 configuration ............................8 Using the AVA 4001 module in DASYLab® 16 ......................9 Recycling ..................................11 10.1. Hazardous Materials .............................. 11 10.2. Recycling Facilities ..............................11 AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.

  • Page 3: Introduction

    USB port of a connected computer » smooth installation » compact dimensions » 2. Contents of the package The package contains: AVA 4001 module » CD with drivers » suitcase » USB cable » manual » AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.

  • Page 4: Technical Data

    5 V DC supplied by the PC USB port, max. current Power supply intake 400 mA Communication interface USB 1.1, USB 2.0 Humidity 0..90%, non-condensing Operating temperature range 0..+70°C Dimensions 130 x 110 x 40 mm AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.

  • Page 5: Measurement Accuracy

    0V should cause the converter to return the value of 32768. Any other result means an offset error. For the ± 10 V range, the maximum offset is ± 1.66 mV. AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.
  • Page 6 For the ± 10 V range, the gain error is ±0.04%. Adding the offset and the gain errors produces the device’s total measurement error. AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.

  • Page 7: Description Of Connections And Status Lights

    Attention When connected computer limits power supply to USB devices, the AVA module may operate incorrectly. Make sure that the computer is able to supply current of at least 400 mA. AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.

  • Page 8: Instacal

    In a sequence of windows that will appear, click Next, Next, Install and Finish respectively. The above procedure should be carried out only once when using the module for the first time. AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.

  • Page 9: Using The Ava 4001 Module In Dasylab® 16

    If necessary, an input can be deactivated by double right-clicking the icon of the active input. Attention In AVA 4001 module, inputs 4 - 7 are not used. Activating them will reduce the maximum available sampling frequency. AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.
  • Page 10 In the Settings tab, in the Acquisition mode field it is possible to select one of the following options: N samples or Continuous. By selecting N samples, the user may enter in the Sample count filed the number AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.

  • Page 11: Recycling

    10.2. Recycling Facilities When decommissioning out of use devices, minimize the impact of the waste created. Refer to local waste removal administration for current information on proper material collection and recycling. AV ACQUISITION 4001 / ©AMC VIBRO Sp. z o.o.
