Trust ICS-2000 Configuration Manual

Smart home. configuration of the security system
Hide thumbs Also See for ICS-2000:

Advertisement

Quick Links

Download this manual See also: Online Manual, User Manual
www.trust.com

Advertisement

loading
Need help?

Need help?

Do you have a question about the ICS-2000 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Trust ICS-2000

Summary of Contents for Trust ICS-2000

  • Page 1 www.trust.com...
  • Page 2 ICS-2000 CONFIGURATION OF THE SECURITY SYSTEM Item 71110 Version 1.0 Visit www.trust.com for the latest instructions OCTOPUS CONTROL STATION...
  • Page 3 ICS-2000 INTERNET CONTROL STATION 1. Preparation Make sure your phone / tablet is connected to the same network as the ICS-2000 To verify this, check in the settings if the connectivity is displaying local. If this is not the case,...
  • Page 4 ICS-2000 INTERNET CONTROL STATION Unscrew the siren cap, open the contact sensors and remove the motion sensor(s) from the holders. Keep the included pin ready for pressing the pairing button.
  • Page 5 / tablet and receive push notifications when the alarm is activated. If you already have a working Trust Smart Home security system first clear the sirens memory by pressing the learning button for 2 seconds (until the LED starts flashing), then release the button and press it again for 6 seconds.
  • Page 6 ICS-2000 INTERNET CONTROL STATION The Siren is now being paired to the control station The Siren is now paired to the control station Another dialog is displayed to add a device. Press the DOOR / WINDOW SENSOR. A new dialog is displayed to give a name for the door / window sensor.
  • Page 7 ICS-2000 INTERNET CONTROL STATION Press the SET button on the sensor for about 2 sec. Then press the CONNECT button. The sensor is paired to the control station Another dialog is displayed to add a device. Press the MOTION SENSOR. A new dialog is displayed to give a name for the motion sensor.
  • Page 8 ICS-2000 INTERNET CONTROL STATION Another dialog is displayed to add a device. When you are done adding sensors, press the button I’M DONE. The security system is now being added. This may take some time (1-2 minutes) Optional: Add Remote.
  • Page 9 ICS-2000 INTERNET CONTROL STATION 1.2 Security system interface After adding the security system the overview screen will be displayed On / Off switch: With this switch the system can be turned on or off. System Status: The status of the system is shown. There are six different states.
  • Page 10 ICS-2000 INTERNET CONTROL STATION Sensor status: When the system is turned on or off, the status of the sensors are checked and displayed. : Sensor is active Anti-tamper switch is activated : Sensor is not active : Sensor has no connection...
  • Page 11 ICS-2000 INTERNET CONTROL STATION 1.3 Turn the security system ON/OFF Ensure when you turn on the security system the anti-tamper switch of the siren is well pressed and that the motion sensor is securely mounted onto the holder. Press the ON switch in the App or ON on the remote control to turn the security system on. The switch will open and become green, the status will change to “Checking Sensors”.
  • Page 12 ICS-2000 INTERNET CONTROL STATION 1.4 Add a new sensor or remote Press the + button to add an additional sensor or remote control A dialog box will appear in order to select a sensor or a remote control which to be added. Press the desired sensor or remote control.
  • Page 13 ICS-2000 INTERNET CONTROL STATION 1.5 Delete a sensor or remote To remove a sensor (in IOS) slide your finger from right to left over the sensor which you want to delete. For the removal of a sensor in Android press 2 seconds on the name of the sensor.
  • Page 14 ICS-2000 INTERNET CONTROL STATION 1.6 Update the security system The update function updates the security settings. This may take some time (2-3 minutes). Please only use this feature when it is adviced by our customer care department. To update the security system, press the SETTINGS button in the menubar. Then press SECURITY SYSTEM UPDATE.
  • Page 15 ICS-2000 INTERNET CONTROL STATION 1.7 Delete the security system The delete function can be used if you want to start over. All security sensors needs to be reconnected. Note: before you restart please reset all sensors, remote control and siren.
  • Page 16 A: Check the App settings that the connection mode says “local state” If this is not the case, connect to the Wi-Fi network of the router to which your ICS-2000 is connected. Q: What are the minimum requirements to use the system? A: To use the security system with the ICS-2000, you need at least a siren and a sensor.
