Osaka F 10 User Manual

WWW.OSAKASOLUTIONS.COM
DIGITAL ELECTRONIC TEMPERATURE
CONTROLLER WITH DEFROSTING
FUNCTION
USER MANUAL - V1
www.osakasolutions.com
PREFACE
This manual contains the information necessary for the
j
m
product to be installed correctly and also instructions for
its maintenance and use; we therefore recommend that
the utmost attention is paid to the following instructions
and to save it
This document is the exclusive property of Osaka Solutions, S.L.
which forbids any reproduction and divulgation, even partially,
of the document, unless expressly authorized.
Osaka Solutions, S.L. reserves the right to make any formal or
functional changes at any moment and without any notice.
Osaka Solutions, S.L. and its legal representatives do
j m
not assume any responsibility for any damage to peo-
ple, things or animals deriving from violation, wrong or
improper use or in any case not in compliance with the
instrument features.
Whenever a failure or a malfunction of the device may
j
m
cause dangerous situations for persons, thing or animals,
please remember that the plant has to be equipped with
additional electromechanical devices which will guaran-
tee safety.
F 10
Osaka - F 10 - User Manual - V1 - PAG. 1
Index
1. Instrument description ....................................................... 1
1.1 General description .............................................................................. 1
1.2 Front panel pescription ....................................................................... 2
2. Programming ....................................................................... 2
2.1 Fast Set point programming .............................................................. 2
2.2 Standard mode parameters programming ................................... 2
2.3 Parameter protection using the password ................................... 3
2.4 Customized mode parameter programming
(parameters programming level) ...................................................... 3
2.5 Reset parameters to default value .................................................. 3
2.6 Keyboard lock function ........................................................................ 3
3. Usage warnings ................................................................... 3
3.1 Admitted use .......................................................................................... 3
4. Installation warnings .......................................................... 4
4.1 Mechanical mounting .......................................................................... 4
4.1.1 Mechanical dimensions, panel cut-out and mounting [mm] .................... 4
4.2 Electrical connections .......................................................................... 4
4.2.1 Electrical wiring diagram .................................................................................................. 4
5. Functions ............................................................................. 4
5.1 ON/Stand-by function ......................................................................... 4
5.2 Normal and economic operation ...................................................... 5
5.2.1 Normal/Economic operation selection ................................................................... 5
5.3 Measure and display configuration ................................................. 5
5.4 Digital input configuration .................................................................. 5
5.5 Temperature control............................................................................. 6
5.6 Compressor protection function and power-on delay ............... 6
5.7 Defrost control ....................................................................................... 6
5.7.1 Manual defrost ........................................................................................................................ 7
5.7.2 Display lock during Defrosting ...................................................................................... 7
5.8 Alarm functions ..................................................................................... 7
5.8.1 Temperature alarms ............................................................................................................ 7
5.8.2 External alarm from digital input ................................................................................ 8
5.8.3 Open door alarm .................................................................................................................... 8
5.9 Function of keys
5.10 Parameters configuration by "KEY USB" ....................................... 8
6. Programmable parameters table ....................................... 9
7. Problems, maintenance and warranty............................. 10
7.1 Notifications ........................................................................................ 10
7.1.1 Error messages ....................................................................................................................10
7.1.2 Other messages...................................................................................................................10
7.2 Cleaning ................................................................................................ 10
7.3 Warranty and Repairs ....................................................................... 10
7.4 Disposal ................................................................................................ 10
8. Technical data .................................................................... 10
8.1 Electrical characteristics .................................................................. 10
8.2 Mechanical characteristics .............................................................. 10
8.3 Functional features ........................................................................... 11
1.

INSTRUMENT DESCRIPTION

1.1

General description

The model F 10 is a microprocessor based digital electronic
temperature controller that is typically used in cooling applica-
tions with ON/OFF temperature control and defrost control
with intervals time by stopping compressor
The instrument has 1 relay output and 2 NTC temperature
probes inputs one of which can be configured as digital input;
it can also be equipped with a built-in buzzer for acoustic report
of the alarms.
