Summary of Contents for Brandywine PTP-8080
- Page 1 PTP-8080 User Manual P/N: 900000156 Revision A For Brandywine Communications products with the following Part Numbers: 03500180X MANUAL P/N 900000156 REV A...
- Page 2 Safety Warnings WARNING This unit contains lethal AC voltages. Disconnect the unit from the AC supply before removing the cover. WARNING: This unit contains dual power supplies. Isolate BOTH power supplied from AC Power before removing the top cover. WARNING: The lightning flash with an arrowhead inside of an equilateral triangle is intended to alert the user to the presence of un-insulated “dangerous voltage”...
- Page 3 Revision History Revision Date Comments 09/27/2016 Initial release MANUAL P/N 900000156 REV A...
-
Page 4: Table Of Contents
2.1.4 Input Reference ............................ 1 0 Configuration ....................... 1 Initial Setup .............................. 1 1 3.1.1 Installing the Discovery Utility ...................... 1 1 3.1.2 Connecting to the PTP-8080 ........................ 1 1 Status ................................ 1 1 3.2.1 System Information .......................... 1 1 3.2.2 PTP Status .............................. 1 2 3.2.3 System Event Log ............................. 1 3 Configuration Pages ........................... 1 4... - Page 5 Table of Figures Figure 1 – PTP-8080 .......................... 6 Figure 2 - System Status Page ......................11 Figure 3 - PTP Status Page ........................12 Figure 4 - System Event Log Page ....................13 Figure 5 - System Information Configuration Page ..............14 Figure 6 - IP Address Configuration Page ..................14 Figure 7 - PTP Settings page. ......................16 Figure 8 - LLDP Configuration page ....................16 Figure 9 - I/O Settings Page ........................ 17 Figure 10 - RSTP Settings Page ......................18 Figure 11 - Port Settings Page ......................19 Figure 12 - IGMP Snooping Configuration Page ................ 19 MANUAL P/N 900000156 REV A...
-
Page 6: Introduction
1 Introduction Figure 1 – PTP-8080 The PTP-8080 is a GPS Network Time Server (NTS) for PTP IEEE 1588 that provides secure, accurate and reliable time synchronization for networks and offers integrated fully managed network switch capabilities for 8 (10/100/1000BASE) Gigabit Ethernet ports. The PTP-8080 can be used for data centers, test facilities, military installations, federal or municipal agencies, financial services and technology firms, and many other enterprises which need precision timing to support their network operations. The PTP-8080 provides exact time over Ethernet either based on the well- established NTP/SNTP protocol or PTP according to IEEE 1588 Std 2008. It not only provides NTP and PTP timing capabilities, but also a variety of other time codes and signals, such as GPS emulation and IRIG-B. The unit also provides backwards compatibility for older timing systems. Such interfaces are normally provided on the network boundaries integrated on relevant SNTP clients or PTP Slave Clocks platforms. The PTP-8080 is used for applications that require reliable timing to accurately synchronize networks, systems, and devices and to log events with legally traceable time. The PTP-8080 Series offers a broad portfolio of features, including network master clocks (NTP or PTP), monitoring and management capabilities, and a complete software package to deliver high performance timing for network applications and devices. The PTP-8080 is easy-to-install and is fully configurable to customize features, interfaces, ports and protocols to your needs. These features include remote login and file transfer capabilities, which provide the utmost security using industry standard interfaces. A full-suite of network protocols includes SNMP capability, support for enterprise directory servers to authenticate users, internal and external logging and monitoring of error messages through Syslog, DHCP for installation convenience, and IPv4. The PTP-8080 is a reliable and accurate NTP and PTP Grand Master Clock fulfilling the IEEE 1588 Std 2002 (v1) and IEEE 1588 Std 2008 (v2). The PTP-8080 contains a built-in state-of-the-art GPS receiver that is used as the time base for the GMC clock. The PTP-8080 platform supports 2-step clock modes and either E2E or P2P as the MANUAL P/N 900000156 REV A... - Page 7 40°F to 158°F] / [-40°C to 70°C]. MANUAL P/N 900000156 REV A...
-
Page 8: Specifications
Network RSTP 1.1 Specifications redundancy Management HTTP, telnet, CLI and Ethernet LAN ports SNMP v1/v2/v3 or IPSet 10/100/1000 4-8 tool. BASE-TX ports in Other protocols Multicast filtering based RJ45 Auto on: MDI/MDIX IGMP snooping 1000BASE-X SFP v2 or v3 slots Up to 1024 BNC multicast filters GPS antenna Male BNC connector can be active interface VLAN (802.1Q) with VLAN OUT1 PPS output signal tagging and GVRP 10MHz 10MHz output Port configuration, status, Technology statistics, monitoring, Standards IEEE 802.3 for 10Base-T security IEEE 802.3u for 100Base- Console ports... - Page 9 inch.) Weight (g) 2500g Installation 19” mounting. Environmental Storage [-40°F to 185°F] / [-40°C to Temperature 85°C] Operating [-40°F to 158°F] / [-40°C to Temperature 70°C] MANUAL P/N 900000156 REV A...
-
Page 10: Setup
2 Setup Remove the PTP-8080 from the shipping carton. The following items should be included in the shipment: 1x PTP-8080 2x Power supply cables 1x CD-ROM containing User Manual and Utility Software 1x GPS Antenna and 100’ cable if the GPS option is included 2.1 Installation 2.1.1 Mounting The PTP-8080 can be installed into a 19” rack mount cabinet using rack slides. Slides are installed using 10-32 UNF-2B hardware. Optional Rack Mount Slides: P/N 002000123, SLIDE, RACK, 24", 21" TRAVEL, 85 LB P/N 002000150, SLIDE, RACK, 28", 27" TRAVEL, 80 LB Original Manufacturer: General Devices Chassis Trak Type C300. 2.1.2 Power Insert the power cord of the PTP-8080 into an electrical socket to power up the unit. If dual redundant power is required, connect both power sources to independent power sources. 2.1.3 Ethernet Connect one end of an Ethernet patch cable to Ethernet port #1 located on the Front of the unit. Connect the other end of the Ethernet cable to the network with an Ethernet hub or switch. Connect the additional ports to the network as needed. 2.1.4 Input Reference Connect any external input references to the appropriate BNC connector. The PTP-... -
Page 11: Configuration
3 Configuration 3.1 Initial Setup 3.1.1 Installing the Discovery Utility For information on installing or using the Discovery software provided with the PTP-8080, please see the user manual for the Discovery application. (P/N 900000157) 3.1.2 Connecting to the PTP-8080 Either use the Discovery utility, or enter the IP Address of the PTP-8080 retrieved via the Discovery utility into a web browser window; this will open the PTP-8080 control webpage. 3.2 Status 3.2.1 System Information The System Information page under the status folder lists inventory information about the unit, as well as a graphical representation of which Ethernet ports are currently being used. An Ethernet port that is colored black indicates that there is no cable connected to them. An Ethernet port that is colored green indicates that there is currently a cable connected to it and it is successfully connected to a network. Figure 2 - System Status Page MANUAL P/N 900000156 REV A... -
Page 12: Ptp Status
3.2.2 PTP Status The PTP status page shows the current state of the PTP stack, as well as the current end to end path delay. The PTP-8080 is designed to automatically measure and compensate any propagation delay in a PTP network. Figure 3 - PTP Status Page MANUAL P/N 900000156 REV A... -
Page 13: System Event Log
3.2.3 System Event Log The system event log page shows a listing of all fault messages that the system has generated while running for diagnostic purposes. Figure 4 - System Event Log Page MANUAL P/N 900000156 REV A... -
Page 14: Configuration Pages
3.3 Configuration Pages 3.3.1 System Information The System Information configuration page allows the user to edit information fields for the purposes of unit identification. Editable fields include: System Name, System Location, System Contact, and Inventory ID. These fields are displayed on the System Information Status page, and are intended for use in identifying which physical unit is connected when accessed over a network. Figure 5 - System Information Configuration Page 3.3.2 IP Settings The IP Settings page allows the user to adjust the IP address, Subnet Mask and Gateway address of the PTP-8080, as well as the option to enable DHCP. Brandywine Communications recommends the use of a Static IP address for ease of management purposes. Please note that the PTP-8080 uses two IP addresses, one for the network switch, which is not accessible for the user, and a separate one for the PTP and web server. Both the PTP server and the network switch must be in the same subnet so that both parts of the PTP-8080 can talk to each other. Figure 6 - IP Address Configuration Page MANUAL P/N 900000156 REV A... -
Page 15: Ptp Settings
3.3.3 PTP Settings The PTP Settings page allows the use to adjust and configure the PTP-8080’s PTP service. More detailed information about each of these settings can be found by using the PTP-8080’s built in help menu. Two step: Setting this to TRUE runs the PTP clock in two step mode. On certain versions of the PTP-8080, this can be disabled to allow it to run in one step mode. Priority 1: This field is used to determine the precedence of the available PTP servers, so that PTP clients can correctly determine a Grandmaster. This can be any value from 0 to 255. Priority 2: This field is used to determine the precedence of the available PTP servers, so that PTP clients can correctly determine a Grandmaster. This can be any value from 0 to 255. Domain Number: Defaults to 0. This determines which PTP domain the PTP-8080 is operating in. For most applications, this is 0. Slave only: When set to TRUE, the unit will only receive time from another PTP source on the network. If this value is set to TRUE, the clock can never take the role of a network grandmaster. Sync interval: Determines the interval period in seconds for how frequently the unit synchronizes with other PTP sources. Announce interval: Determines how frequently in seconds the PTP-8080 announces to the network that it is an available PTP server for clients to connect to. Delay request interval: Determines the interval in seconds between delay request messages going from the PTP slave to the PTP master. Path delay request interval: Determines how frequently in seconds the PTP-8080 polls the network to determine the propagation delay from the PTP-8080 to its peer partners. Delay response logMessageInterval: This is the value inserted into logMessageInterval of a delay response packet going from the master back to the slave. Note that this value is a function of the sync interval since it cannot be slower than 32 times the sync interval or faster than the sync interval. This parameter only has meaning when the PTP-8080 operates as the grandmaster. Disable Ordinary Clock (TC only): When this is set to TRUE, the PTP-8080 will only operate as a TC switch, with no master or slave functionality. Time Source: Determines the time input source for the PTP service to use. This can either be GPS, IRIG, Internal Oscillator or another PTP source on the network. Please note that setting the unit to “External GPS” or switch it to a different source from “External GPS” requires a reboot of the PTP-8080. UTC Offset: Use this field to set the offset from UTC time in seconds. This is only valid if the PTP-8080 is running with the internal oscillator as a valid source. -
Page 16: Lldp Settings
Network Protocol: Whether the PTP-8080 connects to the network using IPv4 or IPv6. Currently, only IPv4 and Ethernet layer 2 are supported. On the right hand side of the PTP configuration page, is the option to enable or disable PTP on each of the Ethernet ports. Figure 7 - PTP Settings page. 3.3.4 LLDP Settings The LLDP settings page enables the user to enable Link Layer Discovery Protocol on the PTP-8080, as well as adjust the interval for when it announces itself over the network. Figure 8 - LLDP Configuration page MANUAL P/N 900000156 REV A... -
Page 17: I/O Settings
3.3.5 I/O Settings The I/O settings page allows the user to adjust various input and output settings for the PTP-8080. The PTP-8080 is capable of outputting 10MHz from a dedicated BNC connector, a dedicated IRIG-B connector, or 1PPS, IRIG-B (DC Level Shift), or 100Hz over a programmable BNC connector. In addition, the PTP-8080 can support up to four additional programmable outputs via the terminal block connector interface. Figure 9 - I/O Settings Page MANUAL P/N 900000156 REV A... -
Page 18: Rstp Settings
3.3.6 RSTP Settings The RSTP Settings page allows the user to enable or disable RSTP mode for the PTP- 8080, as well as set which version of RSTP to use. The PTP-8080 can use Rapid Spanning Tree Protocol” to quickly map out the network it’s connected to and compensate for any changes in network topology. Brandywine recommends that RSTP mode be enabled. Please note that the PTP-8080 is a network switch and it is recommended that it not be looped back from another network switch or have two of its own ports connected to each other, in order to prevent a traffic storm. Figure 10 - RSTP Settings Page 3.3.7 Port Control Settings The port control settings page enables the user to enable or disable each of the numbered PTP ports on the PTP-8080. In addition, the speed and duplex of each port can be set from the page. Please note that the PTP-8080’s network ports are 10/100/1000BaseT ports and for most use cases they should be set to “Auto Negotiation” for RJ-45 copper use. When SFP is used, the speed must be set to “1000 Full.” If it becomes necessary to force the PTP-8080 to run at a specific speed and duplex setting for other reasons, that can be set from here. MANUAL P/N 900000156 REV A... -
Page 19: Igmp Snooping
Figure 11 - Port Settings Page 3.3.8 IGMP Snooping IGMP snooping allows the PTP-8080 to passively listen in to IGMP communications between hosts and routers as a way to keep track of changes in network topology in real time in order to efficiently map IP multicast streams, filtering them from links that don’t need them in order to improve the efficiency of the PTP-8080. Figure 12 - IGMP Snooping Configuration Page MANUAL P/N 900000156 REV A... -
Page 20: Support Information
4 Support Information All Brandywine Communications products come with a one-year warranty. If the unit is still exhibiting problems not covered by the above troubleshooting guide, contact us for technical support at support@brandywinecomm.com or call us at 714-755-1050. If it becomes necessary to return the unit to the factory for repairs, call us at 714- 755-1050 extension 113 to arrange an RMA. MANUAL P/N 900000156 REV A... -
Page 21: Outline Drawings 2
5 Outline Drawings MANUAL P/N 900000156 REV A...
