MedCenter Your Minder Manual

1 2
NOTE: To activate clock, pull plastic tab on back to connect batteries
CONTROL BUTTON DESCRIPTIONS:
1) TALK: Speaks current time and date and confirms time setting
2) ALARM CHECK: Scrolls through alarm times and Confirms Alarms Settings
3) LIGHT: Turns on LCD backlight for 6 seconds
4) ALARM ACKNOWLEDGED: When the alarm is sounding, stops the alarm
and tells when next alarm is due
5) LCD TIME DISPLAY: Digital display of the current time
6) LCD ALARM INDICATION: Shows which of the (6) available alarms are
currently turned on and active
7) LCD DAY DISPLAY: Digital display of the day of the week
8) LCD DATE DISPLAY: Large digital display of the Date
9) ALARM OFF / BEEP / VOICE: Master Alarm Function settings including Off,
Beeping only alarm, and Voice and Beeping alarm
SETTING THE CURRENT TIME / CALENDAR:
Setting sequence: Hour set > Minute Set > Month Set > Date Set > Year Set
• Slide "MODE SELECTION"
• Press "SET / ADVANCE"
Use "- " and "+" buttons on the back to select the current hour.
• Press "SET / ADVANCE"
• Press "SET / ADVANCE"
• Press "SET / ADVANCE"
• Press "SET / ADVANCE"
• Press green "TALK" button on top of the clock once to confirm the time settings and exit
Time Set Mode. The Your Minder Clock will now speak the current time and date.
• Slide "MODE SELECTION"
NOTE: If no buttons are pressed within 1 minute, the clock will exit TIME SET MODE automatically.

SETTING THE ALARM TIMES:

NOTE: The Alarms are preset to default to 7:00 AM, 9:00 AM, 12:00 PM, 3:00 PM, 6:00 PM and 9:00 PM when batteries are inserted into the MedCenter Clock.
• Slide "ALARM SELECTION"
• Slide "MODE SELECTION"
• Press "SET / ADVANCE"
Use "- " and "+" buttons to select the current hour:
• Press "SET / ADVANCE"
• Press "SET / ADVANCE"
• Press blue "ALARM CHECK"
• Repeat the above steps for each of the 6 alarm times you wish to set.
• Slide "MODE SELECTION"
• To Turn Off all 6 Alarms, slide "ALARM OFF / BEEP / VOICE"
NOTE: If no buttons are pressed within 1 minute, the clock will exit TIME SET MODE automatically.
3 4
5 6
switch to "TIME SET".
button once to enter Hour Set Mode.
once to enter Minute Set Mode, use "- " and "+" to select the current minute.
once to enter Month Set Mode, use "- " and "+" to select the correct month.
once to enter Date Set Mode, use "- " and "+" to select the correct date.
once to enter Year Set Mode, use "- " and "+" to select the correct year.
switch back to "LOCK / RUN".
switch to the alarm [1 - 6] you wish to set.
switch to "ALARM SET".
button to enter Alarm Set Mode.
once to enter Alarm Minute Set Mode, use "- " and "+" to select alarm minute.
once to enter Alarm ON/OFF Set Mode, use "- " and "+" to toggle alarm on / off.
button on top of the clock to confirm the alarm settings and exit Alarm Set Mode.
switch back to "LOCK / RUN".
7 9
8 10
11
12
13
10) MODE SELECTION: Used to toggle between setting the clock, setting the
alarm and locking the clock into "Run" Mode
11) SET / ADVANCE: Advances through each step of the setting procedures
12) " - " : Setting Selection backward
13) " + " : Setting Selection forward
14) ALARM SELECTION: Sliding switch is used to select each of the individual
alarms during all modes
15) MIC: Microphone input used for recording alarm messages
16) RECORD: When pressed and held, used to record selected alarm message
17) ERASE: When pressed and held, erases recording for selected alarm
18) PLAY: Plays the current recorded message for the selected alarm
19) POWER ADAPTER INPUT: Input for included AC Adapter
ANS: Input: 120V AC 60Hz, Output: 5V DC 450mA
switch to "OFF" Position
15
16
14
17
18
19
1
10
11
12
13
9
10
11
12
13
2
14
