Eurosep Instruments Spotlight Q7L Serie Quick Start Manual

Spotlight Q7L Serie
Bluetooth LED Leaf Barndoor Projector
Quick Start Manual

Installation into the 2/3 circuit track

Slide the 2/3 circuit track module into a
•
compatible circuit track,
Pull the trigger to fix the position,
•
Turn the rotary knob to the correct position
•
.
to ignite

Luminous intensity adjustment

The potentiometer located on the supply
•
module allows the light intensity to be
adjusted between 0 and 100%.

Bluetooth USB dongle installation

It is essential to have administrator rights on the computer.
1.
Download the BLED112 driver on
2.
File will appear as a .zip file in your Downloads folder
3.
Right-click on the file and Extract it into the Downloads folder,
4.
Plug in the BlueGiga BLE Dongle. It may take a few re-insertions, or switching USB ports, for your PC
to see it,
5.
Click Start menu and right-click on Computer,
6. Click Manage,
7.
Click Device Manager in left pane,
8.
In Device Manager window, expand categories and locate the dongle. If you have never installed
the driver, the dongle will appear under "Other",
9.
Right-click on the device name and select Update Driver Software
10.
Click Browse my Computer for driver software,
11.
Click Browse and navigate to the Downloads/BLED112.../windrv folder
and click OK,
12. Click
Next button to install the driver.
www.eurosep.com,
,
Rotary knob
Potentiometer
,
EUROSEP
Trigger
Instruments
