- Page 1 Maxem 5 English Installation manual...
- Page 2 This can lead to over current on the grid connection, damage to installations and charging stations, electric shocks or fire. Symbols in this document Warning Liability Cohere is not responsible for the installation of Maxem and for any damage arising from not following the installation manual correctly. Nor for damage resulting from typographical errors or misinterpretations of text or images.
- Page 3 Solutions B.V. Material in this document may not be modified, reproduced or copied, in part or in whole, without the explicit written consent of Cohere Energy Solutions B.V. Additional information is available upon request. Maxem is a registered trademark of Cohere Energy Solutions B.V. S M A R T C H A R G I N G C O N T R O L L E R C H A R G E S M A R T E R...
-
Page 4: Table Of Contents
Index What is Maxem? Product specifications What do I need for the installation? Installation steps 01 - Mounting of Maxem 02 - Connecting current transformers Option 2.1 - Connecting current transformers on the grid connection Option 2.2 - Connecting current transformers on the solar panels 03 - Connecting MID kWh-meters 04 - Connecting charging station Option 4.1 - Connecting Tesla Wall Connector... -
Page 5: What Is Maxem
What is Maxem? From the meter cabinet, Maxem measures the energy use in the house and the energy generation of solar panels. Based on this information, it manages the charging station, battery or heat pump smartly. Thus, it helps the user to make easier and cheaper use of sustainable energy. -
Page 6: Product Specifications
Product specifications 01 - Voorbereidingen vooraf Content of the box 6x split core Maxem including mounting plate Network cable Power cable current transformer 4x Screws 3x20 1x Phoenix connector 2x Tie-wrap MID kWh-meter extension MID kWh-meter RS485 cable 1x Phoenix connector 1 2 3 Definitions LED indicators On/off Data Charging station... - Page 7 Specifications Dimensions 184 mm (L) x 167 mm (W) x 55 mm (H) Weight 700g Working temperature 10°C to 35°C Storage temperature 0°C to 60°C Maximal humidity Protection class II (double insulated) Seal IP20 Working height 0 to 2,000 m EN 61326-1 (2013), EN 61000-3-2, 61000-3-3 Safety EN61010-1 (2010), EN61010-2-30 (2010) Immunity EN 61326-1 (2013) Overvoltage category 300V/CAT III Input power 110 - 240V. 50/60Hz. Maximum 2,75W Power coils Up to 50A...
-
Page 8: What Do I Need For The Installation
192.168.25.1/24. • In case of a firewall outgoing traffic has to be allowed on the following ports: 80, 443, 1194 t/m 1200 and 9090. With Maxem compatible charging stations KEBA P20/P30 Tesla Wall Connector ICU EVe mini ICU EVe Compatibility may change over time. See the website www.maxem.io for the current overview of compatible charging stations. Required materials • A correct circuit breaker or earth leakage circuit breaker with proper fusing value. p. 33 to determine fusing. • Schuko sockets for 230V power supply Maxem (if not already available). •... - Page 9 Current transformers of kWh-meters Maxem is standard supplied with current transformers with which the main grid connection and solar production can be measured. For more accurate measurements it is also possible to use MID certified kWh-meters. The kWh-meters Maxem works with can be ordered separately. There are situations when a kWh-meter is always required: •...
-
Page 10: Mounting Of Maxem
01 - Mounting of Maxem 01 - Voorbereidingen vooraf Mount Maxem on a clean, moisture-free wall. Use the supplied mounting plate and screws for this. Take into account sufficient space around the Maxem. 20mm 20mm 20mm Wiring at the bottom 70mm... - Page 11 Maxem has to be connected to a 230V wall socket. Prepare this already but do not power Maxem yet. 230V connection Connect Maxem with the supplied network cable to the modem or router connected to the Internet. Ethernet port to Internet Router UNLESS OTHERWISE SPECIFIED:...
-
Page 12: Connecting Current Transformers
Click the supplied current transformer around the L1 wire of the circuit breaker to the solar inverter (see fig. 2). No other loads may be connected to this circuit breaker. Connect the current transformer to port 4 of Maxem. Repeat these steps for L2 and L3; connect L2 to port 5, connect L3 to port 6. Make sure each current transformer of each phase is connected to the associated port on Maxem. - Page 13 Circuit breaker solar inverter on sub-panel Circuit breakers fuse Circuit breaker solar inverter Home Home Home Grid / Solar Grid / Solar Grid / Solar Home Grid / Solar Main circuit breaker/ main switch Grid connection meter Connection current transformers grid connection Connection current transformers solar panels...
-
Page 14: Connecting Mid Kwh-Meters
03 - Connecting MID kWh-meter Configuring an MID kWh-meter Maxem can measure different elements through an external MID certified kWh-meter. In order for the auto configuration to function properly, the kWh-meter must be set to the right address. This is done as follows: Location of the ‘addressing’ function in the menu Standard addressing kWh-meter 1 2 3 Number of devices Device type Addressing Addressing multiple elements Node/device Address Node/device Address Grid connection Solar #1 Solar Solar #2 Charging station... - Page 15 Phoenix MID kWh-meter connector as follows: kWh- Wire Phoenix- meter color connector Brown White Green Connect the green Phoenix connector to port RS1 on Maxem. Set the address of the kWh-meter to corresponding node. Connect a 1-phase solar installation which supplies L3 of the main grid connection also to L3 of the kWh-meter. The same goes for L2.
-
Page 16: Connecting Charging Station
Install a circuit breaker and/or earth leakage circuit breaker for each charging station at the maximal power available. See p. 33. Place a suitable UTP (CAT5 or CAT6) of the Wall Connector to Maxem. (To prevent electromagnetic interference at the RS485 connection, it is recommended to use FTP CAT6 cable at distance more than 25 m. Max: 50m). - Page 17 Correct LED indication Top LED is green; the Wall Connector is ready to charge. Incorrect LED indication Top LED is green, center LED blinks red 4x; the Wall Connector is set to Slave, but is not communicating with Maxem.. See installation manual Tesla Wall Connector for more information.
-
Page 18: Option 4.2 - Connecting Keba Charging Station
Install a circuit breaker and/or earth leakage circuit breaker at the maximal power available. See p. 33. Place a suitable UTP (CAT5 or CAT6) cable from the charging station to Maxem and clench RJ45 connectors on both sides. Connect the UTP cable to the Ethernet port of the charging station and the ETH port of Maxem. - Page 19 Put DSW 1.3 ON to activate smart charging. Set the DIP switches of DSW1 on the maximal available power. And leave the rest of the DIP switches on OFF. Settings on DSW1 Maximal current strength Example 10A 1 of 3-phase DSW 1.6 OFF DSW 1.7 OFF DSW 1.8 OFF See installation manual KEBA P20/P30 for more information Switch off the Keba P20/P30 (the DIP switch settings only become active after a reset of the charging station).
-
Page 20: Option 4.3 - Connecting Icu Charging Station
Install a circuit breaker and/or earth leakage circuit breaker for each charging station at the maximal power available. See p. 33. Place a suitable UTP (CAT5 or CAT6) cable from the charging station to Maxem and clench RJ45 connectors on both sides. Connect the UTP cable to the Ethernet port of the charging station and the ETH port of Maxem. -
Page 21: Commissioning By Installer
This results in OVER CURRENT OF THE GRID CONNECTION. Therefore always make sure this step is successful. Connect the 230V power supply to Maxem. Wait until the first 3 status LED’s on Maxem are green. This means that Maxem is connected to the network, the internet and the data cloud. Turn on the charging station or restart it by taking off the current for 30 sec. and putting it back on. Wait at least 1 minute for the charging station to start up. This way... - Page 22 No network and no Internet Check Internet cable and/or Light is red connection. Internet router. Connection to Maxem server Light is green is active. Something is wrong with the Call the Maxem support Light is orange Data Maxem cloud. telephone number.
-
Page 26: Ec Declaration Of Conformity
Troubleshooting EC Declaration of Conformity Cohere Energy Solutions B.V. Willem de Zwijgerlaan 350 1055 RD Amsterdam, Nederland following the provision of the following EC Directives: • 2006/95/EC The Low Voltage Directive • 2004/108/EEC The Electromagnetic Compatibility Directive Hereby declare that the product: Maxem Energy Manager 4.0 is in conformity with the applicable requirements of the following documents: Emissions • EN 61326-1 (2013) • EN 61000-3-2 (2006) + A1 (2009) + A2 (2009) • EN 61000-3-3 (2008) Immunity • EN 61326-1 (2013) Safety • EN 61010-1 (2010), • EN 61010-2-030 (2010) • EN 61010-2-023 Signee Date Place Signature Jan Willem Heinen... - Page 28 Maxem is a product of Cohere Energy Solutions Willem de Zwijgerlaan 350 | 1055 RD | Amsterdam | The Netherlands info@maxem.io | www.maxem.io...
