Get Started
Ge�ng started with the Classic Wireless Guitar System couldn't be simpler.
Plug them in, turn them on and play.
1. Insert 2xAAA ba�eries provided into the K1100 Transmi�er
2. Plug the Transmi�er into instrument
3. Press and hold the Transmi�er bu�on for 1 second to turn ON or OFF
2
2
1
4. Plug DC adapter into K2100 Receiver
5. Connect Receiver to amp
6. Turn on Receiver
5
K2 1 00
DC ONLY
wireless receiver
9V 250mA
4
I
O
6
Made inEngland
Fine Tuning
The K2100 Receiver has three adjustable controls: Cable Tone, Latency and
Power Save. The default se�ngs will be fine for most situa�ons but if you
want to tweak, this is how to do it.
1. Control Mode The PRO bu�on enters control mode and changes values.
LONG PRESS
LONG PRESS
LONG PRESS
CLICK
CLICK
enter control
enter set
confirm &
select
change
mode
mode
control
value
1
2
3
4
3. Latency
4. Power Save
2. Cable Tone
The �me it takes to
Turns the Transmi�er
Cables affect guitar
send the sound from
off automa�cally if
tone subtly by the way
your guitar to your
instrument is not
they load the pickups.
amp is always very
played for a period of
The result is a cut in
short (8ms) but can be
�me.
the highs. The Classic
made even shorter
has no cable so may
(5ms) with this control.
sound brighter than
Only recommended for
you're used to. If you
low interference
want a warmer tone,
environments.
increase this control.
30� Cable
Lowest latency
Power Save OFF
20� Cable
Transi�on high
Power Save 60 min
10� Cable
Transi�on mid
Power Save 30 min
DEFAULT
DEFAULT
Cable Tone OFF
Highest link integrity
Power Save 10 min
Microsuction Tape
Here's a piece of 'Microsuc�on Tape'. It'll hold your K1100 Transmi�er in
place on your guitar but will come off easily when you want it to and will
not leave a residue. It uses nano-technology to create thousands of suc�on
cups to s�ck to smooth surfaces.
The tape has a strong acrylic adhesive on one side. Peel the white
backing paper away and use this adhesive to s�ck the tape to the ba�ery
door of the K1100 Transmi�er.
3
1
2
The dark side is the microsuc�on side and has a protec�ve film covering
it. Remove this before use. The tape works best when it's clean. If it gets
dirty, you can remove the ba�ery door and wash it and the Microsuc�on
tape in warm soapy water.
Status Indicators
The K1100 Transmi�er and K2100 Receiver show the state of their wireless
connec�on, signal strength/quality and Transmi�er ba�ery charge.
1
exit
1
2
3
4
3. Interference
2. Signal Strength
Bars show the current
Bars show the
amount of
received signal
interference being
strength.
seen by the Receiver.
Excellent
Interference can come
Good
from WiFi, Bluetooth
& other 2.4 GHz
Weak
devices. Protocol-K
Poor
moves quickly away
from channels that
Poor signal strength
have high interference
will lead to break-up of
the guitar signal. Move
but if there's nowhere
DEFAULT
le� to go, you'll see
closer to the receiver.
more red bars and
connec�on will
become unstable.
Bind Transmitter To Receiver
A K1100 Transmi�er and K2100 Receiver must be bound together before
they can connect. The Wireless Guitar System includes devices that are
already bound together. A Transmi�er can only be bound to one receiver at a
�me.
Bind a Transmi�er to a Receiver
by turning both off then turn
them on in turn and set to bind
mode with a double click within
5 seconds. Connec�on LED
double blinks during bind.
An unlimited number of Transmi�ers can be bound to a single Receiver but
only one Transmi�er can connect to a Receiver at a �me. The Receiver will
connect to whichever Transmi�er responds first so simply power OFF
devices that are not being used.
Change Receiver ID
Each K2100 Receiver is programmed with a unique ID that it uses for binding
to Transmi�ers. It is possible (but very unlikely) that systems with similar IDs
can connect to devices that they are not bound to. If this happens, the
Receiver's ID can be changed to one of three alternate IDs. If this is done, it
will be necessary to re-bind Transmi�ers to the Receiver.
Change a Receiver ID by
turning it off then holding the
PRO bu�on while turning it
back on again. The Receiver
will enter bind mode to re-
bind to an Transmi�er.
Certifications
This wireless system operates in the globally available ISM band 2400 MHz to
2483.5 MHz. The opera�on does not require a user license.
Meets requirements of the following standards: EN 300 328 EN 301 489
Parts 1 and 9 EN60065. Meets essen�al requirements of the following
1. Connec�on Status
European Direc�ves: R&TTE Direc�ve 99/5/EC, WEEE Direc�ve 2002/96/EC,
Transmi�er bu�on LED
as amended by 2008/34/EC RoHS Direc�ve 2002/95/EC, as amended by
Connected - Slow blink
2008/35/EC. Note: Please follow your regional recycling scheme for ba�eries
Searching - Fast blink
and electronic waste.
Binding* - Double blink
The CE Declara�on of Conformity can be obtained from:
www.smoothhound-innova�ons.com/europe/compliance
Receiver white LED
Connected - On
Information To The User
Searching - Fast blink
Binding* - Double blink
This equipment had been tested and found to comply with the limits of EN
* See 'Bind Transmi�er to Receiver'
300 328. These limits are designed to provide reasonable protec�on against
harmful interference in a residen�al installa�on. This equipment generates
uses and can radiate radio frequency energy and, if not installed and used in
accordance with the instruc�ons, may cause harmful interference to radio
4. Ba�ery Charge
communica�ons. However, there is no guarantee that interference will not
Bars show the
occur in a par�cular installa�on. If this equipment does cause harmful
condi�on of the
interference to radio or television recep�on, which can be determined by
Transmi�er ba�eries.
turning the equipment off and on, the user is encouraged to try to correct
Approx. Time Le�
the interference by one or more of thefollowing measures:
15 hours
• Reorient or relocate the receiving antenna.
12 hours
• Increase the separa�on between the equipment and the receiver.
• Connect the equipment to an outlet on a circuit different from that to
8 hours
which the receiver is connected.
2 hours
• Consult the dealer or an experienced radio/TV technician for help.
A single blinking bar
Smooth Hound Innova�ons Ltd.
shows you're almost
Cambridge
out and the
United Kingdom
Transmi�er will shut
Email: info@smoothhound-innova�ons.com
down soon.
SmoothHound
www.smoothhound-innova�ons.com
Trouble Shooting
No Sound from Amp
- Check that there are fresh ba�eries in the Transmi�er and the system is
wired correctly (see GET STARTED)
- Check that Transmi�er and Receiver are 'Connected' (see STATUS
< 5 secs
INDICATORS)
- Contact support@smoothhound-innova�ons.com
power
bind
double
Transmi�er and Receiver do not connect
ON
mode
CLICK
- Check that Transmi�er and Receiver are 'Bound' (see BIND TRANSMITTER
TO RECEIVER)
- Contact support@smoothhound-innova�ons.com
Radio Interference
Protocol-K uses radio waves in the 2.4 GHz band which is shared with
other technologies such as WiFi, Bluetooth (both on computers, tablets
and cell phones) and other proprietary wireless audio systems. Protocol-K
uses an adap�ve algorithm to select the four cleanest channels for audio
data whilst tes�ng a further four channels as backup from 79 channels
available. It's a very robust system but in an environment with many other
devices transmi�ng, a reliable connec�on cannot be guaranteed.
If you experience high levels of interference and unreliable connec�on, try
the following:
- Check the ba�eries in the transmi�er
- Turn off any unused wireless audio systems (they will be using radio
channels even if not transmi�ng an audio signal)
- Turn off or disable unnecessary WiFi or Bluetooth devices
hold PRO
- Increase the distance between compe�ng systems (a minimum of 3m
bu�on
separa�on is recommended)
ID
power
bind
- Ensure there are no large metal objects between transmi�er and receiver
ON
change
mode
- Move the receiver away from large metal objects
- Reduce the distance between transmi�er and receiver
Ini�alisa�on Error
If the Transmi�er Connec�on LED is on con�nuously (not blinking) or all
three of the Receiver bars are flashing con�nuously this indicates an
ini�alisa�on error. Remove ba�eries from the K1100 and turn off the
K2100. Wait 20 seconds then replace ba�eries and switch on.
Classic
Wireless Guitar System
User's Manual
© 2015 Smooth Hound Innova�ons Ltd.
