Audio enhancement THE SAFE SYSTEM MS-1000 Setting Up

Monitoring station

Setting up the MS-1000

The MS-1000 requires that you download software in order to set the IP Address, Subnet

Mask and Default gateway. The software is "Device Discovery" and cab be downloaded from

here:

http://ftp1.digi.com/support/utilities/40002265_g.exe

STEP 1—Download and run the install program from your download directory

STEP 2—Before running the Device Discovery software connect the MS-1000 to the net-

work with a standard CAT 5 cable.

STEP 3—Start the program and you should see the following screen:

The software will poll the network and locate the MS-

1000 on the network. Click on the desired device if its

not already highlighted.

STEP 4 -

Click on "Configure network settings" to

bring up the configure network settings screen.

Table of Contents

Do you have a question about the THE SAFE SYSTEM MS-1000 and is the answer not in the manual?

Page 1 Setting up the MS-1000 The MS-1000 requires that you download software in order to set the IP Address, Subnet Mask and Default gateway. The software is “Device Discovery” and cab be downloaded from here: http://ftp1.digi.com/support/utilities/40002265_g.exe STEP 1—Download and run the install program from your download directory STEP 2—Before running the Device Discovery software connect the MS-1000 to the net- work with a standard CAT 5 cable.
Page 2 STEP 5—Click on "manually configure network settings" STEP 6 Enter this information based on the IP Address you obtain from your IT department Default password is “audioe”...
Page 3 Firmware updates for the MS-1000 STEP 1- Place the MS-1000 on a network that allows access to the public internet. That is -- The MS-1000 must have HTTP access to www.tac-comm.com It will automatically connect, it just needs to have access. STEP 2 - Press and continue to hold the “Enter”...
