THANK YOU FOR BUYING A RYOBI CORDLESS CIRCULAR SAW.
Your new cordless circular saw has been engineered and manufactured to Ryobi's high standard for dependability, ease of
operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.
CAUTION: Carefully read through this entire operator's manual before using your new cordless circular saw.
Pay close attention to the Rules for Safe Operation, Warnings, and Cautions. If you use your cordless circular saw properly
and only for what it is intended, you will enjoy years of safe, reliable service.
Thank you again for buying Ryobi tools.
SAVE THIS MANUAL FOR FUTURE REFERENCE
OPERATOR'S MANUAL
5-1/2 in. (140 mm) CORDLESS
CIRCULAR SAW MODEL NO. R10632

SPECIFICATIONS:

5-1/2 in. (140 mm)
3/8 in. (10 mm)
1-9/16 in. (40 mm)
1-1/8 in. (29 mm)
4,200 RPM
18 Volt DC
1 Hour
120 Volts, 60 Hz, AC

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the R10632 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Ryobi R10632

Summary of Contents for Ryobi R10632

  • Page 1: Specifications

    THANK YOU FOR BUYING A RYOBI CORDLESS CIRCULAR SAW. Your new cordless circular saw has been engineered and manufactured to Ryobi’s high standard for dependability, ease of operation, and operator safety. Properly cared for, it will give you years of rugged, trouble-free performance.

  • Page 2: Table Of Contents

    Inspect it carefully to make sure no breakage or damage has occurred during shipping. If any parts are damaged or missing, contact your nearest Ryobi Authorized Service Center to obtain replacement parts before attempting to operate saw. A blade, blade wrench, and this operator's manual are also included.

  • Page 3: Rules For Safe Operation

    USE RIGHT TOOL. Don't force small tool or attach- ment to do the job of a heavy duty tool. Don't use tool for purpose not intended - for example - A circular saw should never be used for cutting tree limbs or logs.

  • Page 4: Important Safety Rules For Battery Tools

    RULES FOR SAFE OPERATION (Continued) IMPORTANT SAFETY RULES FOR BATTERY TOOLS ■ Battery tools do not have to be plugged into an electrical outlet; therefore, they are always in an operating condition. Be aware of possible hazards when carrying your battery tool, when making adjustments to it, or when changing accessories.

  • Page 5: Important Safety Instructions For Circular Saws

    Do not use if lower blade guard does not close briskly over saw blade. ■ If saw is dropped, lower blade guard or bumper may be bent, restricting full return. If lower blade guard or bumper becomes bent or damaged, replace them before reuse.

  • Page 6: Symbols

    Important: Some of the following symbols may be used on your tool. Please study them and learn their meaning. Proper interpretation of these symbols will allow you to operate the tool better and safer. SYMBOL NAME Volts Amperes Hertz Minutes Alternating Current Direct Current No Load Speed...

  • Page 7: Features

    OPTIONAL RIP GUIDE SCREW (WING SCREW) SPINDLE BASE Do not allow familiarity with your circular saw to make you careless. Remember that a careless fraction of a second is sufficient to inflict severe injury. Page 7 LOCK-OFF BUTTON...

  • Page 8: Operation

    Battery Pack" for normal recharging of batteries. If the charger does not charge your battery pack under normal circumstances, return both the battery pack and charger to your nearest Ryobi Authorized Service Center for electri- cal check. Page 8 BATTERY CHARGER RED LIGHT "ON"...

  • Page 9: To Install Battery Pack

    WARNING: A 5-1/2 in. (140 mm) blade is the maximum blade capacity of your saw. Never use a blade that is too thick to allow outer blade washer to engage with the flats on the spindle. Larger blades will come in contact with the blade guard, while thicker blades will prevent blade screw from securing blade on spindle.

  • Page 10: Saw Blades

    NOTE: The guard is operating correctly when it moves freely and readily returns to the closed position. If for any reason your lower blade guard does not close freely, take it to the nearest Ryobi authorized service center for service before using. Page 10...
  • Page 11 See Figure 8. The best guard against kickback is to avoid dangerous practices. Kickback occurs when the blade stalls rapidly and the saw is driven back towards you. Blade stalling is caused by any action which pinches the blade in the wood.

  • Page 12: Depth Of Cut Adjustment

    ■ When making a cut use steady, even pressure. Never force cuts. ■ Do not cut warped or wet lumber. ■ Always hold your saw firmly with both hands and keep your body in a balanced position so as to resist the forces of kickback should it occur.
  • Page 13 After you complete your cut release the trigger and allow the blade to come to a complete stop. Do not remove your saw from workpiece while the blade is moving. CAUTION: To make sawing easier and safer, always maintain proper control of your saw.
  • Page 14 TO CROSS CUT OR RIP CUT When making a cross cut or rip cut, align your line of cut with the outer blade guide notch on the saw base as shown in figure 17. Since blade thicknesses vary, always make a trial cut in scrap material along a guideline to determine how much, if any, the guideline must be offset to produce an accurate cut.
  • Page 15 TO BEVEL CUT The angle of cut of your saw may be adjusted to any desired setting between zero and 50°. NOTE: When making cuts at 50°, blade should be set at full depth of cut. When making 45° bevel cuts, there is a notch in the saw base to help you line up the blade with the line of cut.
  • Page 16 POSITIVE 0 BEVEL STOP See Figure 21. Your saw has a positive 0° bevel stop, that has been factory adjusted to assure 0° angle of your saw blade when making 90° cuts. However, misalignment can occur during shipping. TO CHECK ■...
  • Page 17 OPTIONAL RIP GUIDE (EDGE GUIDE) See Figure 23. Use a guide when making long or wide rip cuts with your saw. An optional rip guide with a five inch scale is available or you can make an efficient rip guide by clamping a straight edge to your workpiece.

  • Page 18: Maintenance

    They contain chemicals that can damage, weaken or destroy plastic. BATTERIES Your saw's battery pack is equipped with nickel-cadmium rechargeable batteries. Length of service from each charging will depend on the type of work you are doing.
  • Page 19 NOTES Page 19...

  • Page 20: Parts Ordering / Service

    Ryobi Authorized Service Center. Be sure to provide all pertinent facts when you call or visit. Please call 1-800-525-2579 for your nearest Ryobi Authorized Service Center. You can also check our web site at www.ryobitools.com for a complete list of Authorized Service Centers.
