Tracmaster CAMON LA20 Operating Instructions & Safety Notes

MAINTENANCE GUIDE

For engine maintenance please refer to engine manufacturers
manual.
Keep all nuts, bolts and screws tight to be sure the machine is in a safe
working condition.
Examine the machine regularly and replace worn or damaged parts.
Never store the machine with petrol in the tank inside a building where
fumes can reach an open flame or spark.
Ensure the engine is cool before storing in any enclosure.
To reduce the fire hazard, keep the engine, silencer and petrol storage
area free of grass, thatch, moss, leaves or excessive grease.
After every hour of operation:
Stop engine. Remove the spark plug cap
Check engine oil level. (Recommended oil SAE 10w/40).
Visually check the blade assembly.
Do not turn the machine on its side for cleaning.
Refit the spark plug cap.
Tine Lifting Lever
Fuel Filler Cap
Choke
Fuel Tap
Oil Level Plug
Recoil Start Handle
VIBRATION & SOUND LEVELS
Machine RPM
Lawn Aerator 3400
Tracmaster Ltd, Teknol House, Victoria Road, Burgess Hill RH15 9LH
Tel: 01444 247689 Fax: 01444 871612
Website: www.tracmaster.co.uk E-mail: info@tracmaster.co.uk
© Tracmaster Ltd 2006.
Specifications are subject to change without prior notice.
OP/LA20/0906
Operating Lever
Throttle
Ignition
Switch
Rear Wheel Height
Adjuster Bolt
Tine Lifting Board
2
Vibration m/sec Sound Level
3 Axis dB(A)
5.4 79.0
INSTRUCTIONS
SAFETY NOTES
CAMON
LAWN AERATOR
Lever
Important
WEAR EAR
PROTECTION
No liability will be accepted for any damage
caused to persons or property through failure
to observe the operating and safety instructions.
OPERATING
&
PLUGGER
LA20
READ CAREFULLY
WEAR EYE
PROTECTION
WEAR SAFETY
FOOTWEAR
