IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should always be
observed including the following:
1. Read all instructions.
2. Do not touch hot surfaces.
3. To protect against risk of electrical hazards, do not immerse cord, plugs, etc. of the
appliance in water or other liquid.
4. Close supervision is necessary when any appliance is used by or near children.
5. Unplug from the outlet when not in use and before cleaning. Allow to cool before
putting on or taking off parts, and before cleaning the appliance.
6. Do not operate any appliance with a damaged cord or plug or after the appliance
malfunctions, or has been damaged in any manner. Return the appliance to the
nearest authorized service facility.
7. The use of accessory attachments not recommended or sold by the appliance
manufacturer may cause injuries.
8. Do not use outdoors.
9. Do not use appliance for other than intended use.
10. Turn the laminator off when not in use for prolong period of time.
11. The socket-outlet shall be installed near the equipment and shall be easily
accessible.
12. Do not laminate sheets containing metal or conductive materials.
SAVE THESE INSTRUCTIONS
A short power cord may be provided with this appliance to reduce hazards resulting
from becoming entangled in or tripping over a longer cord. Extension cords may be
used if care is exercised in their use. If an extension cord is used, the following must
apply:
a. The marked electrical rating should be at least as great as the electrical rating of
the appliance.
b. The extension cord should not drop over the counter top or table top where it can
be pulled on by children or tripped over accidentally.
INTRODUCTION
Congratulations on your purchase of the laminator. Now you can protect your favorite
photos, recipe cards, membership cards, letter and legal size document and other
types of thin objects up to A4 size 222 x 349 mm (8 3/4" x 13 3/4") in a waterproof,
airtight seal. Follow the instructions for proper use and keep this book for future
reference.
Note:
* We do not recommend laminating any type of self-developing photo.
* Any photo to be laminated must be dry before processing.
* Do not laminate any documents that appear thick or heavy, as this will get stuck in
the laminator. If this occurs please contact your local service center for servicing.
* This product bonds the laminate sleeve to the item being processed. It is a
permanent seal and cannot be removed.
* We do not recommend laminating any collector's items of value or any item you may
wish to remove at a later date. Do not attempt to laminate coins or thicker items.
HOW TO USE
1. Before operation we recommend you open the lid cover.
This will help support the laminated document from curving.
2. Turn the machine on.
1
3. When the ready light comes on, the machine has warmed up and is ready to laminate.
4. Place the item to be laminated into the laminating sleeve, centering it within the
sleeve. Please make sure your document or picture is position as close to the
sealed edge as possible.
* The laminator does not require the use of a carrier in order to operate.
* The laminator can laminate film from 3.0 mil (75 micron) to 4.0 mil (100 micron).
It works with most types of heat-sealing laminating pouches.
5. Insert the sealed edge of the laminating sleeve straight into the CENTER of the
laminator opening.
6. Remove the sleeve from the rear of the machine after it has stopped moving.
7. Some sorts of paper do not laminate evenly, or appear somewhat cloudy. In such
cases the lamination can be fed through the machine a second time and the
lamination process repeated.
8. Press release button to release document when jamming occurs.
CARE AND CLEANING
An authorized service representative should perform any serving, other than
cleaning and user maintenance.
Do not immerse in water.
To reduce the risk of fire or electrical shock, do not remove the base. No user
serviceable parts are inside. Repair should be done by an authorized service
personnel only.
* Keep your hands and the cord away from hot parts of the appliance during
operation.
* Never clean with scouring powders or hard implements.
* Wipe clean with a soft cloth.
SUGGESTED USES
Photographs
Greeting cards
Recipe cards
Luggage tags
Membership cards
Make your own bookmarks
Boat license
Christmas ornaments
Hunting license
Fishing license
Look of hair from baby's first haircut
TECHNICAL DATA
Voltage
230-240V~ 50Hz
Current
0.8A
Power
Max. 200W
Film Thickness
75-100micron(3-4mil)
Max Document Size
222 x 349 mm (8 3/4" x 13 3/4")
Warm Up Time
approx. 5 mins
Laminating Speed
approx. 26cm/min
Max Document Thickness
0.4 mm
2
A4 LAMINATOR
INSTRUCTION MANUAL
Model: LM200
