BenQ PointWrite PW40U User Manual
Hide thumbs Also See for PointWrite PW40U:

Advertisement

PointWrite User Manual
PW40U
V1.00

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the PointWrite PW40U and is the answer not in the manual?

Questions and answers

Summary of Contents for BenQ PointWrite PW40U

  • Page 1 PointWrite User Manual PW40U V1.00...
  • Page 2: Table Of Contents

    Table of contents Shipping contents....3 Prepare for setup....4 Environmental condition ......4 Instructions for surface......5 PointWrite Module Installation on Projector ..7 About PointWrite Pen ..8 Installing the batteries ......8 Replacing the pen tip........8 Driver Installation....9 Driver installation complete ..........
  • Page 3: Shipping Contents

    Shipping contents The PointWrite is a built in Interactive Whiteboard on the projector. To use the PointWrite correctly, please find the standard accessories below and follow the instructions in this manual. PointWrite (PW40U) Quick manual Two PointWrite pens (PointWrite Pen G2) Two sets of batteries Mini USB cable Extra pen tips...
  • Page 4: Prepare For Setup

    Prepare for setup Environmental condition For an BenQ projector with the scalable interactive functionality, transforming any flat surface into a virtual interactive whiteboard. For an optimal interactive writing quality, follow these guidelines: Close window curtains. Select a projection area away from direct sunlight to prevent writing interference.
  • Page 5: Instructions For Surface

    Instructions for surface Optimal interactive quality will be dependent on the selected surface condition. It is important to choose a flat and non-reflective surface to secure the writing performance. Selecting a wall surface • Select a wall that is straight and flat, avoid any protruding objects on it. •...
  • Page 6 Selecting a board surface Attach a dry-erase board to the wall if you’re projecting on a textured wall surface. A dry- erase board is a flat surface that works well with your interactive projector and allows you to write smoothly in digital ink. Instructions for a board surface Consider the following factors when selecting a board to project to optimized the interactive quality.
  • Page 7: Pointwrite Module Installation On Projector

    PointWrite Module Installation on Projector The PointWrite module is available for BenQ selected projector. Make sure the PointWrite module is installed properly before you active interactive function. * Use the screw locked on the PointWrite dummy cover to fix the PointWrite module.
  • Page 8: About Pointwrite Pen

    About PointWrite Pen The PointWrite Pen provides the following 4 actions: Click: Touch an icon or a menu on the screen. Double Click: Touch an icon or a menu on the screen two times. Right Button Click: Touch an icon or menu for at least 1.5 seconds. Drag: Touch and drag an object on the screen.
  • Page 9: Driver Installation

    Driver Installation When you are the first time to use this PointWrite Module, please install set-up driver for Configuration setting. Please go to below BenQ Display Website to download PointWrire Set-up driver https://business-display.benq.com/en/findproduct/projector/accessory/pointwrite- pw40u.html Go to BenQ Website >> Search PW40U >> Go to "Download Page"...
  • Page 10: Driver Installation Complete

    The PointWrite icon will be created on the desktop. The installation folder will be created on C: directory. • 64-bit Windows: C:\Program Files (x86)\BenQ\PointWrite 2.0 • 32-bit Windows: C:\Program Files\BenQ\PointWrite 2.0 Remark: Only First time using the PointWrite module need to install set-up driver for Configuration setting, the subsequent users can only plug the USB cable to connect to PC to start the interaction quickly without driver installation.
  • Page 11: Connecting The Pointwrite To Pc

    Connecting the PointWrite to PC Use the USB cable to connect the projector to PC. Plug the USB mini-B end into the projector and plug the USB type-A end into PC. Check “Device Manager” from your computer to make sure that PointWrite device is recognized by your computer.
  • Page 12: Set Up For Interactive Function

    PointWrite Mode: • Pen Mode: Default selection • Finger Touch Mode: Only available when PointWrite Module works with BenQ PointWrite Touch module . When selecting Finger Touch mode, pen and finger can be used simultaneously. PointWrite Option: • Ceiling Mount Mode: Click this item if you mount the projector on the ceiling.
  • Page 13: Alignment Instructions

    Alignment instructions Alignement view The PointWrite Alignment function is to set the orientation of the PointWrite to the screen. Alignment View: When clicking on the “Alignment View”, the screen image is displayed on the alignment view as illustrated. If the screen image is not in the center, the calibration will fail. Please make sure the PointWrite module is attached to the projector properly.
  • Page 14: Pointwrite Calibration

    PointWrite Calibration PointWrite provides two kinds of calibration methods: auto calibration and manual calibration. Auto calibration: Click on and the calibration process will run automatically. When you choose this method, white image is shown on the screen and the pattern image is displayed.
  • Page 15: Start For Interactive Function

    After completing calibration, you can use PointWrite pen as mouse function or launch QWrite software for writing and annotation. Remark: *QWrite? is BenQ exclusive annotation software, please go to BenQ Website to Download QWrite software. Notice: To secure the quality of interactive function, we suggest users to adjust projector's input signal (computer output signal) to the same as projector's Native resolution.
  • Page 16: Specifications

    Inside Projector Storage Temp/Humidity -10°C ~ 60°C / 5%~95% RH (Max.) Dimensions 121 mm x 36.9 mm x 24.6 mm Weight 53 g Selected BenQ Ultra short throw models Compatible model (Throw ratio 0.21) PointWrite Pen Power AAA Battery*2 Length...
