- Page 1 DSP-405 multi-switch pack...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 04.05.2018, ID: 148581...
-
Page 3: Table Of Contents
1.2 Notational conventions........................7 1.3 Symbols and signal words....................... 8 Safety instructions..........................10 Features............................... 14 Installation and starting up........................ 15 Connections and controls........................17 Operating..............................21 Technical specifications........................23 Plug and connection assignments....................24 Protecting the environment......................25 DSP-405 multi-switch pack... - Page 4 DSP-405 multi-switch pack...
-
Page 5: General Notes
If you sell the unit please make sure that the buyer also receives this manual. Our products are subject to a process of continuous development. Thus, they are subject to change. DSP-405 multi-switch pack... -
Page 6: Further Information
Our online guides provide detailed information on technical basics Online guides and terms. Personal consultation For personal consultation please contact our technical hotline. If you have any problems with the device the customer service will Service gladly assist you. DSP-405 multi-switch pack... -
Page 7: Notational Conventions
The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. Displays Texts and values displayed on the device are marked by quotation marks and italics. Examples: ‘24ch’ , ‘OFF’ . DSP-405 multi-switch pack... -
Page 8: Symbols And Signal Words
Press [Auto]. ð Automatic operation is started. Switch off the device. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. DSP-405 multi-switch pack... - Page 9 This combination of symbol and signal word indicates a pos- sible dangerous situation that can result in material and environmental damage if it is not avoided. Warning signs Type of danger Warning – high-voltage. Warning – danger zone. DSP-405 multi-switch pack...
-
Page 10: Safety Instructions
Choking hazard! Ensure that children do not detach any small parts (e.g. knobs or the like) from the unit. They could swallow the pieces and choke! Never let children unattended use electrical devices. DSP-405 multi-switch pack... - Page 11 Do not use the device if covers, protectors or optical components are missing or damaged. DANGER! Electric shock caused by short-circuit Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a registered electrician. DSP-405 multi-switch pack...
- Page 12 Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. DSP-405 multi-switch pack...
- Page 13 Failure to do so could result in damage to the device and possibly injure the user. Unplug the device before electrical storms occur and when it is unused for long periods of time to reduce the risk of electric shock or fire. DSP-405 multi-switch pack...
-
Page 14: Features
Features Features 4 dimmer channels Outputs: 4 protective contact sockets Control via DMX 512, buttons and display on the unit Individual DMX addressing per channel Operating modes: – – Automatic Single channel protection DSP-405 multi-switch pack... -
Page 15: Installation And Starting Up
First, connect the loads to the terminals on the sides of the device. If you want to operate the device in ‘DMX’ mode, establish the DMX connection to the controller. Finally, connect the power plug of the device to a mains power socket. DSP-405 multi-switch pack... - Page 16 Connect the output of the first DMX device to the input of the second one, and so on to form a daisy chain. Always ensure that the output of the last DMX device in the daisy chain is terminated with a resistor (110 Ω, ¼ W). DSP-405 multi-switch pack...
-
Page 17: Connections And Controls
Connections and controls Connections and controls Front panel DSP-405 multi-switch pack... - Page 18 [DMX signal]: lights up when the unit is turned on and receives a DMX signal. 7 Channel indicators [1]…[4]. In all operating modes, the channel indicators show which channels are currently being used by the running pro- gramme (LEDs light up). DSP-405 multi-switch pack...
- Page 19 Connections and controls Bottom DSP-405 multi-switch pack...
- Page 20 Connections and controls 8 [1]…[4] Fuses for dimmer channels 1…4. 9 [POWER] On / off switch. 10 [POWER INDICATOR] Lights up when the unit is powered. 11 [DMX OUT] DMX output. 12 [DMX IN] DMX input. 13 Mains cable. DSP-405 multi-switch pack...
-
Page 21: Operating
Press [MODE] repeatedly until the display shows ‘PA:xx’ . external DMX controller: to select the desired chase programme. 16 programmes and the sequential run of the 16 programmes are available. Press [MODE] to then select with the desired chase speed. The display shows ‘SP:xx’ . DSP-405 multi-switch pack... - Page 22 If ‘2ch’ is displayed, two sets with each two channels of the device are controlled via one DMX channel each. If ‘4ch’ is displayed, each channels of the device is controlled via its own DMX channel. DSP-405 multi-switch pack...
-
Page 23: Technical Specifications
DMX 512 via 3-pin XLR socket Outputs 4 outlets, 5 A per channel, 16 A max. total Temperature range 5 °C … +35 °C Dimensions (W × H × D) 210 mm × 260 mm × 88 mm Weight 3.5 kg DSP-405 multi-switch pack... -
Page 24: Plug And Connection Assignments
The unit offers a 3-pin XLR socket for DMX output and a 3-pin XLR plug for DMX input. Please refer to the drawing and table below for the pin assignment of a suitable XLR plug. Configuration Ground, shielding Signal inverted (DMX–, ‘cold signal’) Signal (DMX+, ‘hot signal’) DSP-405 multi-switch pack... -
Page 25: Protecting The Environment
Dispose of this device through an approved waste disposal firm or through your local waste facility. When discarding the device, comply with the rules and regulations that apply in your country. If in doubt, consult your local waste disposal facility. DSP-405 multi-switch pack... - Page 26 Notes DSP-405 multi-switch pack...
- Page 28 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
