60cm / 90cm Wide
Stainless Steel Splashback
L60SPLX10 / L90SPLX10
Unpacking
Remove all items from the packaging. Retain the packaging. If you dispose of it please do so according to any local regulations.
The following items are included:
The Main Unit
If items are missing or damaged, please
contact Partmaster (UK only). Tel: 0344 800
3456 for assistance.
Wall Mounting & Fixings
• Depending on the material of your wall, it may be neccessary to use masonry anchors or hollow wall anchors when fixing
the screws. In all cases, ensure that a secure fixing is obtained.
• The included wall plugs are only suitable for use in masonry walls. If you are in any doubt about the correct wall plugs for
your wall, seek professional advice. Failure of the product due to using incorrect fixings is the responsibility of the installer.
Instruction Manual
Wall Plugs x 4 (Ø8 x 40 mm)
Screws x 4 (4 x 30mm)
Be careful when unpacking and installing the
unit as the metal edges can cause injury if not
handled with care.
In s tr u c ti o n
M a n u a l
Instruction Manual x 1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Summary of Contents for Logik L60SPLX10
- Page 1 Instruction Manual 60cm / 90cm Wide Stainless Steel Splashback L60SPLX10 / L90SPLX10 Unpacking Remove all items from the packaging. Retain the packaging. If you dispose of it please do so according to any local regulations. The following items are included: Wall Plugs x 4 (Ø8 x 40 mm)
- Page 2 Consult a qualified technican if you are unsure. L60SPLX10 L90SPLX10 2 people are required to lift the unit during assembly, it is recommended that gloves are worn. 5. Use the screws and wall plugs provided to fix the splashback.
