Foxconn QCA9375 User Manual

Foxconn QCA9375 User Manual

Ieee 802.11a/b/g/n 2x2 wifi module
Hide thumbs
Table of Contents

Advertisement

Quick Links

1. Level 1 Environment‐related Substances should NEVER be used.
2. Purchase ink, paint, wire rods, and molding resins only from the business partners that
Sony approves as Green Partners.
3. Recycled Resin and Coated Wire should be procured from Green Partners
IEEE 802.11a/b/g/n 2x2 WiFi Module
Project Name
Customer Part No.
Approval Sheet Rev.
Foxconn Part No.
Prepared by
Gallon G.R. Tao
User Manual

QCA9375 IEEE 802.11a/b/g/n 2x2 WiFi Module
021430401
J20H076.01
Reviewed by
Robin Xu
1
HON HAI PRECISION IND. CO., LTD.
No.2, 2nd Dong Huan Road, 10th
YouSong lndustrial District, Longhua
Town, Baoan, ShenZhen
1.0
Approved by
Chang‐Fu Lin

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the QCA9375 and is the answer not in the manual?

Questions and answers

Related Manuals for Foxconn QCA9375

Summary of Contents for Foxconn QCA9375

  • Page 1 HON HAI PRECISION IND. CO., LTD. No.2, 2nd Dong Huan Road, 10th YouSong lndustrial District, Longhua Town, Baoan, ShenZhen 1. Level 1 Environment‐related Substances should NEVER be used.  2. Purchase ink, paint, wire rods, and molding resins only from the business partners that  Sony approves as Green Partners.    3. Recycled Resin and Coated Wire should be procured from Green Partners  User Manual    IEEE 802.11a/b/g/n 2x2 WiFi Module  Project Name  QCA9375 IEEE 802.11a/b/g/n 2x2 WiFi Module  Customer Part No.    021430401  Approval Sheet Rev.  1.0  Foxconn Part No.  J20H076.01  Prepared by  Reviewed by  Approved by  Gallon G.R. Tao  Robin Xu   ...

  • Page 2: Table Of Contents

    CONTENTS REVISION HISTORY ..............3 PRODUCT OVERVIEW ..............4 SIGNAL DESCRIPTION ..............5 ................5 IGNAL IAGRAM ................5 INOUTS .............5 3.2.1 Connector Specification ..............5 3.2.2 Pin definition ELECTRICAL SPECIFICATION............6 ..............6 BSOLUTE AXIMUM ATING .............6 ECOMMENDED PERATING ONDITION ..............6 OWER ONSUMPTION ..............6 OWER EQUENCE...

  • Page 3: Revision History

    1. Revision History Change History  Date  Document revision  Initial release  2013/5/24  1.0 ...

  • Page 4: Product Overview

    2 Product Overview This documentation outlines the QCA9375 WiFi Module. It is 802.11a/b/g/n compatible, ARIB STD-T66 Compatible; the module Host I/F is USB 2.0. IEEE 802.11 a/b/g and 802.11n payload data rates for Wireless Local Area Network (WLAN). 1.1 Operating Frequency: 2402~2483.5MHz, 5150MHz~5250MHz, 5250MHz~5350MHz, 5470MHz~5725MHz, 5725MHz~5845MHz 1.2 Modulation: DBPSK, DQPSK, CCK, BPSK, QPSK, 16QAM, 64QAM...

  • Page 5: Signal Description

    3 Signal Description 3.1 Signal Diagram Below figure 2 shows its signal diagram. Figure 2: Module Signal Diagram 3.2 Pinouts 3.2.1 Connector Specification JST WTB connector, Part Number: SM10B-GHS-TB(LF) Pin1 3.2.2 Pin definition Pin# Pin Name Pin Type Description Remark Ground Wake-up on wireless LAN Active high...

  • Page 6: Aximum R Ating

    4 Electrical Specification 4.1 Absolute Maximum Rating Symbol Condition Min. Typ. Unit VCC_3.3V Respect to GND -0.3 CHIP_PWD_L Respect to GND -0.3 Max Ripple on Supplied Voltage 3.3V mVpp Operating Temperature ℃ Storage Temperature ℃ 4.2 Recommended Operating Condition Symbol Condition Min.
  • Page 7 Parameter  Description  Min  Max  Unit  tA  Rise time of VDD3.3V go to 90% of 3.3V  ‐  25  ms  tC  Time from VDD3.3V reaching 90% of 3.3V to level of  5  ‐  μs  CHIP_PWD_L going above 50% of VDD3.3V.  tB  The value is tA+tC, during this time, the level of        CHIP_PWD_L should stay below 50% of VDD3.3V.  4.5 WLAN RF Specifications 4.5.1 WLAN RF Specification- 802.11b Items Contents Specification IEEE 802.11b Mode DSSS / CCK Channel CH1 to CH13 Data rate...

  • Page 8: Rx Spurious Emission

    4.5.2 WLAN RF Specification- 802.11g Items Contents Specification IEEE 802.11g Mode OFDM Channel CH1 to CH13 Data rate 6, 9, 12, 18, 24, 36, 48, 54Mbps Min. Typ. Max. Unit TX Characteristics 1. Power Levels (per chain) 1) Target Power@6Mbps 14.5 17.5 2) Target Power@9Mbps...

  • Page 9: 4.5.3 Wlan Rf Specification- 802.11N (2.4Ghz) Ht20

    4.5.3 WLAN RF Specification- 802.11n (2.4GHz) HT20 Items Contents Specification IEEE 802.11n HT20 Mode OFDM Channel CH1 to CH13 Data rate (MCS index) MCS0/1/2/3/4/5/6/7 Min. Typ. Max. Unit TX Characteristics 1. Power Levels (per chain) 13.5 16.5 1) Target Power@MCS0 13.5 16.5 2) Target Power@ MCS1...

  • Page 10: 4.5.4 Wlan Rf Specification- 802.11A

    4.5.4 WLAN RF Specification- 802.11a Items Contents Specification IEEE 802.11a Mode OFDM 5150MHz~5250MHz, 5250MHz~5350MHz, Channel 5470MHz~5725MHz, 5725MHz~5845MHz Data rate 6, 9, 12, 18, 24, 36, 48, 54Mbps Min. Typ. Max. Unit TX Characteristics 1. Power Levels (per chain) d,e,f 1) Target Power@6Mbps 14.5 d,e,f 14.5...

  • Page 11: 4.5.5 Wlan Rf Specification- 802.11N (5Ghz) Ht20

    4.5.5 WLAN RF Specification- 802.11n (5GHz) HT20 Items Contents Specification IEEE 802.11a/n HT20 Mode OFDM 5150MHz~5250MHz, 5250MHz~5350MHz, Channel 5470MHz~5725MHz, 5725MHz~5845MHz Data rate (MCS index) MCS0/1/2/3/4/5/6/7 Min. Typ. Max. Unit TX Characteristics 1. Power Levels (per chain) g,h,i 13.5 1) Target Power@MCS0 g,h,i 13.5 2) Target Power@ MCS1...
  • Page 12 4.5.6 WLAN RF Specification- 802.11n (5GHz) HT40 Items Contents Specification IEEE 802.11a/n HT40 Mode OFDM 5150MHz~5250MHz, 5250MHz~5350MHz, Channel 5470MHz~5725MHz, 5725MHz~5845MHz Data rate (MCS index) MCS0/1/2/3/4/5/6/7 Min. Typ. Max. Unit TX Characteristics 1. Power Levels (per chain) 12.5 1) Target Power@MCS0 12.5 2) Target Power@ MCS1 12.5...
  • Page 13 5 Schematic and PCB Layout 5.1 Module Schematic Block Diagram Mckinley BB/MAC/Transceiver...
  • Page 14 RF Chain 0 RF Chain 1...

  • Page 15: Ayout

    5.2 Module PCB Layout 5.2.1 PCB Stack-up PCB Thickness：1.0mm+/‐0.1mm  PCB Layers：4 Layers    Material: HF FR4, Tg150    PCB Thickness Layers Thickness Tolerance Layer 1 1.8mil ±0.4mil Perpeg 4.5mil ±0.5mil Layer 2 1.2mil ±0.2mil Perpeg 24.0mil ±1.9mil 1.0mm±0.1mm Layer 3 1.2mil ±0.2mil Perpeg 4.5mil ±0.5mil Layer 4 1.8mil ±0.4mil 5.2.2...
  • Page 16 5.2.3 PCB Layout Layer 1 (TOP View) Layer 2 (TOP View)
  • Page 17 Layer 3 (TOP View) Layer 4 (TOP View)

  • Page 18: A Ntenna P Attern

    6 Antenna Specifications 6.1 PCB Printed Antenna Pattern Ant 0 and Ant 1 pattern are horizontal mirror Ant 0 Ant 1 6.2 Antenna Radiation Performance Antenna VSWR and Isolation Antenna Peak gain and Efficiency...
  • Page 19 Antenna 0 2.4GHz radiation pattern Antenna 0 5GHz radiation pattern...
  • Page 20 Antenna 1 2.4GHz radiation pattern Antenna 1 5GHz radiation pattern...

  • Page 21: Module Mechanical Specifications

    7 Module Mechanical Specifications Dimension (W x L x H ): 40.0mmx37.5mmx5.45mm...

  • Page 22: Handling Notice

    , humidity under 90% RH, when the moisture barrier ℃ bag is sealed by Foxconn. 2. The calculated shelf life for the dry packed product shall be a 12 months from the bag seal date. 3. If Moisture barrier bag is open, the component must be stored in an environment of <25±5℃...

  • Page 23: Reliability Test Plan

    9 Reliability Test Plan...

  • Page 25: Marking Information

    Please refer to below for the laser marking details. 1: 2D barcode, content is total 37 digits, include MAC ID, Customer data, and SONY Part Number 2: MAC address 3: Foxconn model name – Label version 4: Foxconn manufacture order 5: SONY Part Number...

  • Page 26: Packing Information

    11 Packing Information...
