FDD CR 135-2C Installation Instructions

Installation Instructions for Models:
CR 135-2C, CF 135-2C, CR 165-2C, CF 165-2C, CR 200-2C, CF200-2C, CF 285-2C

Description:


The "-2C" series of heat detectors are described as alarm initiating devices, double circuit with
two sets of Normally Closed contacts.

The Model Number prefix "CR" indicates that the detector is a combination Rate-of-Rise and
Fixed Temperature, often referred to as "Dual-action". The Rate-of-Rise function allows the
detector to open both sets of its contacts when the temperature at the ceiling increases at a rate
of 8.4 Celsius degrees (15 Fahrenheit degrees) per minute. The contacts are commonly used
to initiate ancillary functions that require the opening of a circuit to operate a device.

The Fixed Temperature portion consists of a spring-loaded plunger held in place by a eutectic
solder that will fuse at the specific temperature (in F degrees) as indicated by the Model Number
i.e. 135,165,200 and 285 degrees.

The Model Number prefix "CF" indicates that the detector is Fixed Temperature Only, and will
therefore not respond to a rate of temperature increase but will operate when the detector fuses
at the prescribed temperature as indicated by the model number. This detector is referred to as
"Fixed Temperature Only, non-restorable".

Location:


The "CR" series detectors are installed in areas where rapid increases in ceiling temperature
are not expected. Such locations include dwelling units, storage cupboards, electrical closets,
material storage rooms, shafts (other than stairwells), transformer vaults, electrical rooms, and
sprinkler rooms.

The "CF" series detectors are installed in areas where rapid increases in ceiling temperature
are expected. Such locations include boiler rooms, industrial kitchens, commercial laundry
rooms, janitor closets, change rooms with shower facilities, and saunas.

It is important to consider ambient temperature conditions when selecting the detector's fusing
temperature. See Engineering Specification (below).
Engineering Specification: Models CR 135-2C, CR 165-2C and CR 200-2C detectors are dual-action
type, that will respond to a rate of temperature increase at the ceiling of 15 Fahrenheit degrees per
minute (8.4 Celsius degrees per minute).
temperature (non-restorable) threshold is exceeded. Dual-action detectors are installed in areas where
rapid fluctuations in ceiling temperature are not expected. In areas where sudden increases in ceiling
temperature are normal, specify Fixed Temperature Only units i.e. CF 135-2C, CF 165-2C, CF 200-2C
or CF 285-2C. Detectors shall be installed in areas where environmental conditions including dust,
vapours, insects, etc., would cause an ionization or photoelectric type detector to initiate a false alarm.
Model # Function
Type
CR 135-2C Dual-action
CR 165-2C Dual-action
CR 200-2C Dual-action
CF 135-2C Fixed Temp.
Only
CF 165-2C Fixed Temp.
Only
Fixed Temp,
CF 200-2C
Only
Fixed Temp.
CF 285-2C
Only
*
assumes a flat, uninterrupted ceiling at a height not exceeding 10ft / 3m.
90 Nolan Court, Unit 34, Markham, Ontario, Canada L3R-4L9 Fax(905) 477-2826, Tel(905) 479-7116
Electronic products dedicated to the safety of life and property
Web Site - http://www.firedetectiondevices.com
THERMOFLEX
FOR FIRE ALARM SYSTEMS
Release Temp. Temp. Rating
Range
135⁰F / 57⁰C Ordinary
Ordinary
165⁰F / 71⁰C
Intermediate
200⁰F / 93⁰C
Ordinary
135⁰F / 57⁰C
Ordinary
165⁰F / 71⁰C
200⁰F / 93⁰C Intermediate
285⁰F / 140⁰C High
®
AUTOMATIC THERMOSTATS
These detectors will also respond when the fixed
Max. Installation Color dot on fin
Temp
100˚F / 37.8˚C
100˚F / 37.8˚C
150˚F / 65.6˚C
100˚F / 37.8˚C
100˚F / 37.8˚C Black and Grey
150˚F / 65.6˚C Black and White
225˚F / 107.2˚C Black and Blue
Email – orders@firedetectiondevices.com
Spacing between
detectors*
None 70ft / 21m
Grey 70ft / 21m
White 70ft / 21m
Black 40ft / 12m
25ft / 7.5m
25ft / 7.5m
25ft / 7.5m
