Operator ' s manual
M48 Pro M53 S Pro
Please read the operator's manual carefully and make sure you
E E E E n n n n g g g g l l l l i i i i s s s s h h h h
understand the instructions before using the machine.

Advertisement

loading

  Also See for Husqvarna M48 Pro

  Related Manuals for Husqvarna M48 Pro

  Summary of Contents for Husqvarna M48 Pro

  • Page 1 Operator ′ s manual M48 Pro M53 S Pro Please read the operator’s manual carefully and make sure you E E E E n n n n g g g g l l l l i i i i s s s s h h h h...
  • Page 2: Key To Symbols

    WARNING! A lawn mower is a dangerous tool if used carelessly or incorrectly and can cause serious, even fatal injuries. It is extremely important that you read and understand the contents of this operator's manual.
  • Page 3: Table Of Contents

    ... General safety precautions ... General working instructions ... WHAT IS WHAT? What is what on the lawn mower? M48 Pro... What is what on the lawn mower? M53 S Pro ... ASSEMBLY Fitting the handlebar ... Dismantling and assembling the cutter ...
  • Page 4: Safety Instructions

    • Cutting equipment Cutting cover and protective cover On lawn mower M53 S Pro there is a protective cover mounted over the drive's gearbox. The protective cover is designed to reduce the risk of crush injuries and to catch a broken drive belt.
  • Page 5: Checking, Maintaining And Servicing The Machine ' S Safety Equipment

    Check that the protective cover is undamaged and that it is properly secured. Checking the brake trigger Place the lawn mower on firm, flat surface and start it. Make sure that the cutter cannot come into contact with the ground or other objects. See the instructions under the heading Start and stop.
  • Page 6: General Safety Precautions

    General safety precautions • A lawn mower is only designed to mow lawns. The only accessories you can use with this engine unit are the cutters we recommend in the Technical data chapter. •...
  • Page 7: Fuel Safety

    4 Check that the muffler is securely attached and not damaged. 5 Check that all parts of the lawn mower are tightened correctly and that they are not damaged or missing. 6 Check that the cutter is undamaged and not cracked.
  • Page 8: General Working Instructions

    This can make the cutter dull and bend the engine shaft. • Never lift up the lawn mower or carry it around when the engine is running. If you must lift the lawn mower, first switch off the engine and disconnect the ignition lead from the spark plug.
  • Page 9 Shut down the engine before changing the cutting height. Set the cutting height using the cutting height control on the right-hand side of the lawn mower. On lawn mowers with the type designation M48 Pro, proceed as follows: • To raise the cutting height move the lever to the left and then forward.
  • Page 10: What Is What

    What is what on the lawn mower? M48 Pro 1 Handle / handlebar 2 Vibration damper 3 Engine brake handle 4 Starter handle 5 Throttle control/choke control 6 Cutting height control 7 Fuel tank 8 Muffler 9 Spark plug 10 –...
  • Page 11: What Is What On The Lawn Mower? M53 S Pro

    What is what on the lawn mower? M53 S Pro 1 Handle / handlebar 2 Vibration damper 3 Engine brake handle 4 Throttle control/choke control 5 Starter handle 6 Clutch lever 7 Cutting height control 8 Fuel tank 9 Muffler...
  • Page 12: Assembly

    The ignition lead should always be removed from the spark plug before repair, cleaning or maintenance work. 12 – English ASSEMBLY Always empty the fuel tank before you place the lawn mower on its side. Dismantling • Unscrew the bolt holding the cutter.
  • Page 13: Fuel Handling

    If the machine is not used for some time the fuel tank should be emptied and cleaned. Engine oil Check the oil level before starting the lawn mower. A too low oil level can cause serious damage to the engine. •...
  • Page 14: Starting And Stopping

    STARTING AND STOPPING Starting and stopping WARNING! Note the following before starting: Do not start a lawn mower unless the cutter and all covers are fitted correctly. Otherwise the cutter could come loose and cause personal injuries. Always move the machine away from the refuelling area before starting.
  • Page 15 STARTING AND STOPPING Drive The model M53 S Pro is a self-propelled machine with the drive on the front wheels. To use the drive on the wheel pull the clutch lever towards you. Stopping Set the throttle control in the idling position. Stop the engine by releasing the engine brake handle.
  • Page 16: Maintenance

    Maintenance WARNING! Make sure the cutting attachment has stopped before cleaning, carrying out repairs or an inspection. Disconnect the HT lead from the spark plug. Air filter The air filter must be regularly cleaned to remove dust and dirt in order to avoid: •...
  • Page 17: Cutter

    Cutter WARNING! Always wear heavy-duty gloves when repairing the cutting attachment. The blades are very sharp and can easily cause cuts. It is important to have a sharp and correctly balanced cutter. Loosen the bolt holding the cutter and leave the cutter at a service workshop at least once a year for grinding and balancing.
  • Page 18: Drive And Gearbox

    Daily maintenance 1 Check that the engine brake handle works safely. 2 Brush leaves, grass and the like off of the lawn mower. 3 Clean the air intake on the starter. Check the starter and starter cord. 4 Check the oil level.
  • Page 19: Technical Data

    Drive Speed, km/h Note 1: Noise emissions in the environment measured as sound power (L Note 2: Vibrations measured according to EN836 : 1997/A2:2001 TECHNICAL DATA M48 Pro Transistor NGK - BPR6ES 0,7 - 0,8 0,55 Service classification SG - SJ;...
  • Page 20: Ec-Declaration Of Conformity

    Höörs Plåt, Box 76, SE-243 22 Höör, Sweden, tel: +46-413-29600, declares under sole responsibility that the lawn mowers Husqvarna M48 Pro and M53 S Pro from the serial numbers 030600001 and onwards comply with the requirements of the COUNCIL’S DIRECTIVE: of May 3, 1989 ”relating to electromagnetic compatibility”...
  • Page 22 ´®z+H8|¶6d¨ ´®z+H8|¶6d¨...
  • Page 24 1140249-26 ´®z+H8|¶6d¨ ´®z+H8|¶6d¨ 2003-12-17...
  • Page 25 Fertiliser chainsaws spreaders Garden tractors Garden vacuums Hover mowers Husqvarna chainsaws Lawn scarifiers Lawn tractors Petrol hedge Ride on lawn cutters mowers Ryobi strimmers Scarifiers Westwood Brush Cutters tractors Chainsaws Cultivators Electric Fertiliser Chainsaws Spreaders Garden Garden Tractors Shredders Hedgecutters...

This manual is also suitable for:

M53 s pro
