TMS320C5515 Evaluation Module (EVM)
C5515 EVM
System Requirements
•
2 GB of free hard disk space
•
Microsoft Windows™ XP/Vista
•
Min 1 BG RAM, 2 BG recommended
•
Min 1.5 GHz, dual core recommended
•
Color Display
•
Internet access
•
USB port
•
DVD Reader
Service and Support
Web
http://support.spectrumdigital.com
E-Mail
support@spectrumdigital.com
©Copyright Spectrum Digital 2010
12502 Exchange Dr., Ste 440, Stafford, TX. 77477
Quick Start Installation Guide
Items Required for Setup
C5515 EVM Code Composer
Studio DVD
T:281.494.4505, F:281.494.5310
+5V Universal
Power Supply
USB Cable
Description
The C5515 Evaluation Module (EVM) is an all-in-one
evaluation platform for the TMS320C5515 Digital Signal
Processor from Texas Instruments. It includes a target
board that can be used as a reference design. Included is
a board specific version of TI's flagship Code Composer
Studio development tools. An on-board JTAG emulator
allows debug from Code Composer Studio through your
PC's USB port.
This kit contains everything you need to get started with TI
DSPs. It can also be used with the full version of Code
Composer Studio and an external JTAG emulator.
512706-4001A
AC Power
Cords
Page 1 of 4
www.spectrumdigital.com
Advertisement
Summary of Contents for Mouser Electronics TMS320C5515
- Page 1 2 GB of free hard disk space The C5515 Evaluation Module (EVM) is an all-in-one • Microsoft Windows™ XP/Vista evaluation platform for the TMS320C5515 Digital Signal • Processor from Texas Instruments. It includes a target Min 1 BG RAM, 2 BG recommended •...
- Page 2 Install EVM Content from the CD-ROM CCS Configuration Instructions Note: Install ALL software prior to connecting the Launch CCS v4 from the shortcut on the desktop. C5515 EVM to the computer ! (This was created when CCS v4 was installed). Note: The user MUST be logged onto windows with The CCS v4 window will appear.
-
Page 3: Support Resources
“Launch Selected Configuration”. For additional information regarding the TMS320C5515 family of DSPs please refer to the Click “View->Debug” then click “Target->Connect following page on the TI web site: Target”. CCS will attempt to connect to the C5515 http://tiexpressdsp.com/index.php/C5000... - Page 4 USB connector comes on when power is applied to the EVM. Do not launch Code Composer until the The latest version of the Chip Support Library (CSL) LED is off. for the TMS320C5515 is available at: Error Messages http://focus.ti.com/docs/toolsw/folders/print/sprc133.html Many of the error messages below refer to USB enumeration issues.
