Maximus Scales GM8895 User Manual

Remote display
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
GM8895
5" [125mm] 6 digit, 7 segment, ultra bright red LED display
User's Manual
GM8895-VER-120102
48019050211001
110605070006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the GM8895 and is the answer not in the manual?

Questions and answers

Summary of Contents for Maximus Scales GM8895

  • Page 1 GM8895 5" [125mm] 6 digit, 7 segment, ultra bright red LED display User’s Manual GM8895-VER-120102 48019050211001 110605070006...

  • Page 2: Table Of Contents

    CONTENT 1. General Instructions ..............1 1.1 Function features ............... 1 1.2 Front panel illumination ............1 1.3 Specification ............... 2 2. Installation and Wiring ..............3 2.1 Installation ................3 2.2 Open Remote Display ............4 2.3 Inside Structure Diagram ........... 5 2.4 Power/Communication Terminals Connection ....

  • Page 3: General Instructions

    1. General Instructions GM8895 Remote Display is one of our independent innovation instrument for end show, which is used with various electronic weighing instruments at wide application:AD-4321 A D-4323 、 、 、 、 、 、 、 、 TOLEDO & Fairbanks R2500...

  • Page 4: Specification

    Waterproof Power Cable Input: Connect power cable with ② remote display. Lock Buckle: Lock front and back board of remote display. ③ Wireless Communication Sign Receiver: Receive weighing ④ data from the indicator in wireless communication (optional function). Main display: Display weighing data, including decimal point and minus sign.

  • Page 5: Installation And Wiring

    2. Installation and Wiring 2.1 Installation User can fix Remote Display on wall or strong metal stand according to actual application. The following instruction is to fix on wall for example. 1. Fix hanging board on wall (Suggesting using M6 dilatants bolts to fix hanging board).

  • Page 6: Open Remote Display

    2.2 Open Remote Display Please open Remote Display as following instruction before connecting power cable /communication terminals or related operation, and then begin to run. 1. Loose four lock buckles (location as following diagram). P 2-4 2. Open the front panel of Remote Display, install built-in bracket in Remote Display to support front panel.

  • Page 7: Inside Structure Diagram

    2.3 Inside Structure Diagram GM8895 Remote Display inside structure and its connection diagram are following: P 2-7...

  • Page 8: Power/Communication Terminals Connection

    L ive wire ： ： ： 2.4.2 Communication Terminals Connection The connection between the indicator and GM8895 remote display are different according to different communication mode. Please refer Chapter 3.3 (P9) for communication mode. R S232 communication mode （ ）...
  • Page 9 R S485 communication mode （ ） The connection diagram between weighing the indicator and GM8895 remote display are following: P 2-10 2 0mA Electric current loop （ ） ～ The connection diagram between weighing the indicator and GM8895 remote display are following:...

  • Page 10: Application Illumination

    D 6 of SW2 switch (blue switch) to set 、 、 、 communication address, after setting, power on again. Near number side is defined 0, and near “ON” side is defined 1. Please restart GM8895 to make new setting effect. The address table: Display Address … … …...

  • Page 11: Communication Mode Setting

    （ ） R S485 mode Multiple communications can be preceded by RS485 mode, which means more GM8895 remote displays can be connected in one 485 communication net, but display weighing data separately. Push SW1 switches (red switch) D3 and D4 to ON, other to OFF. And push JP2 switch to 485 side.

  • Page 12: Wireless Communication Function

    3.4 Wireless Communication Function （ ） W ireless communication is a transmitter by point-to-point style, thus no cables connected between the indicator and GM8895 remote display to reduce site wiring. W ithin the range of visibility, the reliable transmission （...

  • Page 13: Red&Green Lights Output Control Function

    3.5 Red&Green lights output control function GM8895 has 2 on/off data output interfaces to control the red&green lights.(Optional function) Interface definition diagram: Output Green light Red light GM8895 uses optoelectronic isolation technology to transfer the ON/OFF data. This needs 24 V DC...

  • Page 14: Working Mode

    2. When GM8895 remote display connects with the indicator properly, and can receives weighing data from the indicator, GM8895 will display the current weighing data within some time. For example, if current weighing data is net weight 1980Kg, then remote display will show as following: P 4-2 Note: if the connection is not correct, or present data haven’t...

  • Page 15: Mirror Display Mode

    4.2 Mirror Display Mode If Mirror Display switch is ON, all weighing value will be reversed on GM8895. The following diagram indicates above mirror display: 1. P 4-1 corresponding mirror display as follows: P 4-4 2. P 4-2 corresponding mirror display as follows: P 4-5 3.

  • Page 16: Communication Protocols

    5. Communication Protocols GM8895 Remote Display can connect with present famous weighing indicators, and can suit serial interface parameters (baud rate/communication protocol) automatically, which means it possess auto-recognized function for communication protocols of various weighing indicators. GM8895 remote display have three kinds communication modes: RS232/RS485, and 0~20mA current loop.
  • Page 17 5.1 A&D-4321（ （ （ （ AD-4323） ） ） ） Data format: 5.2 TOLEDO & Fairbanks R2500 Data format:...
  • Page 18 Status b yte A ： Bits0, 1 , 2 indica te the position of decim al point; Bits3, 4 a re the divisi on facto r. X.XX X.XXX X.XXXX X.XXXXX d i vis i o n d i vis i o n d i vis i o n f ac to r 2 f ac tor 1 f ac tor 5...
  • Page 19 O d d/ E v en b i t Status b yte C: St a tus A l wa ys l o g ic 0 A l wa ys l o g ic 0 A l wa ys l o g ic 0 Nor m a l ＝...
  • Page 20 5.3 UMC 600 Data format: 5.4 GSE 60 series (GSE 50 series) Data format:...
  • Page 21 5.5 WI-125 Data format: 5.6 WI-127 Data format:...
  • Page 22 5.7 DF1500 series Data format: 5.8 Rinstrum A protocol Data format:...
  • Page 23 5.9 Rinstrum C protocol Data format: 5.10 Rinstrum PC protocol Data format:...
  • Page 24 5.11 Bilanciai D800 Cb protocol Data format: 5.12 HBM WE2107 EOP 6 protocol Data format:...
  • Page 25 5.13 Gedge C2 protocol Data format: 5.14 Gedge C3 protocol Data format:...
  • Page 26 5.15 Protocol NO.1 Data format: 5.16 Protocol No.2 Data format: 5.17 Protocol No.3 Data format: Note: The display timeout is disabled, which means that the message will remain on the display until new data is sent.
  • Page 27 5.18 Protocol No.4 Date format: 5.19 Protocol NO.5 Data format: 5.20 Protocol No.6 Data format:...
  • Page 28 5.21 Protocol No.7 Data format: 5.22 Protocol NO.8 Data format: Status S1 and S2 are 0~F ASCII code: S1 Status Tare=0,preset Tare=1 Only used in Net mode. Motion=0,Stable=1 Not COZ=0,COZ=1 Gross=0,Net=1...
  • Page 29 S2 Status Units=kg Units=g Units=T Weight longer than string, Display will be blanked. 5.23 Protocol NO.9 Data format: 5.24 Protocol No. 10 Data format:...
  • Page 30 5.25 Protocol NO.11 Data format: 5.26 Protocol No.12 Data format: 5.27 Protocol No. 13 Data format:...
  • Page 31 5.28 Protocol No. 14 Data format: 5.29 Systec protocol Data format:...
  • Page 32 5.30 GM Multiple communication protocol Data format: Rinstrum protocol Multiple communication protocol are used in multiple communication mode, which communication address setting refers to illumination P8.
  • Page 33 5.31 Fidelity Protocol Data format: He ad e r He ad e r Dat a Si g n Un it ( 7) Her e: He ad e r1: 2b it s ST — — S t ab l e s i g n S = 0x 5 3 T = 0 x5 4 ，...

  • Page 34: Hanging Board Dimension Diagram

    6. Hanging Board Dimension Diagram P 6-1...
