Instructions for Installation v1.0

Advertisement

loading
Need help?

Need help?

Do you have a question about the Mostat and is the answer not in the manual?

Questions and answers

Summary of Contents for Alien green Mostat

  • Page 1 Instructions for Installation v1.0...
  • Page 2 USER SAFETY GUIDANCE Read the instructions attentively before starting installation of the thermostat, as the booklet contains important information about safety guidance and normative rules regarding the thermostat and its installation. Keep the User Safety Guidance for further usage, if needed. The thermostat must be set up according to current installation standards Before starting the work, make sure the boiler is NOT supplied with voltage power Read all warnings with great attention!
  • Page 3 IN THE BOX Temperature and Humidity Transmitter (Room Sensor) Process Control Block (PCB) Power Cable Antenna Connector Outside Antenna 2x Cable Ties 2x Bolts 2x AA Batteries 2-strand Wire...

  • Page 4: Device Description

    DEVICE DESCRIPTION Process control block (PCB) is installed in the central heating boiler Wi-Fi router is connected to the Internet, and provides the connection between the devices (NOT applied to the complexion) The temperature and humidity transmitting sensor can be installed in the office, or private residence...

  • Page 5: Installation

    INSTALLATION Setting up the process control block (PCB) in the central heating boiler CAUTION: Before starting the work, please make sure that the boiler is NOT supplied with voltage power! Unpack the process control block (PCB). Open the boiler so that you can reach the printed circuit board. (If necessary, use the instructions for the boiler).
  • Page 6 1. Drill a hole in the casing to set up the antenna there, as shown on the picture. 2. Connect one end of the antenna connector to the Green Light of process control block (PCB). Boiler Indicator 3. Fix another end of the antenna connector in the hole, and wrap it around the bolt.
  • Page 7 5. Find the connector for the room thermostat with the number TA1 (if you have a boiler by Ariston), or TA,LS-LR,COM-NO (if you have a boiler by any other manufacturer but Ariston). Disconnect the connector on TA1, and connect the 2-strand wire, as shown on the picture. 6.

  • Page 8: Functional Testing

    FUNCTIONAL TESTING Push the button on the process control block (PCB) once and wait till the green light appears on the boiler. If the connector (TA1) of process control block (PCB) is connected properly, the boiler flame will appear within 10 seconds. The flame will fade when the button on the process control block (PCB) is pushed again.
  • Page 9 MOSTAT application in the mobile phone, and push the Configuration button. Using Wi-Fi of your mobile phone, connect to Mostat device named MOSTAT-[Serial number of your device] If asked for a password, type in capital letters: MOSTAT123 , and follow the application instructions.
  • Page 10 DESCRIPTION OF PROCESS CONTROL BLOCK (PCB) The red light of power indicator is on when the process control block (PCB) is supplied with voltage power. The green light of Status is blinking when the factory reset, i.e. configuration option is active. The green light of AP-Status is blinking when the device is connecting to Wi-Fi router.
  • Page 11 The distance between the floor and the device must be 120-150 cm. The device must be 200-300 cm away from the door and windows. Avoid the sunlight. 200-300 cm 200-300 cm mostat TIP: These recommendations are given for avoiding the measurement errors of temperature...
  • Page 12 CONFIGURATIONS OF THE ROOM SENSOR Take the room sensor out of the box, and move its lid off. Remove the pull to start tab for activating the battery, as shown on the picture. Take the room sensor to the central heating boiler, and push the button once; When the button is pushed, the blue light starts blinking, which means the device is ready for configuration option.
  • Page 13 When the room sensor is all set up, make sure that AP-Status Status lights on process control block (PCB) are permanently ON, without blinking. Only when AP-Status Status lights are permanently ON, close the central heating boiler and switch it on. A GUIDE TO OCCATIONAL PROBLEMS AND HOW TO SOLVE THEM AP-Status light is blinking: This signals that the process control block (PCB) cannot connect to your home Wi-Fi router.

  • Page 14: Technical Specifications

    TECHNICAL SPECIFICATIONS Dimensions: Room Sensor (83.5 mm x 26.5 mm) Process Control Block (PCB) (82 mm x 53 mm) Communication: Wireless Internet (Wi-Fi 802.11b/g/n @ 2.4GHz, 5GHz 802.15.4 @ 2.4GH) Room Sensor and Process Control Block (PCB) are connected to each other by means of Wi-Fi Unlike to other thermostats, this one does not need an additional router because both modules use the home wireless Internet Sensors: Temperature Sensor (-40ºC to +120ºC)
  • Page 15 Whether you need a technical support, or simple advices, Feel free to contact us. Sincerely, Alien Green team +995 32 2424622 https://aliengreen.ge/ka/thermostat/faq https://aliengreen.ge/ka/contact-us https://www.instagram.com/mostatge/ https://www.facebook.com/mostatge http://twitter.com/mostatge...
