YET YET404PC User Manual

(YET404PC - Four channel wireless intellect receiving control)
User Manual

1 Summarize .............................................................................................. 1

2 Features ................................................................................................ 2

3 Technical parameters ................................................................... 2

4 Operating instruction ................................................................. 3
4.1 Mode declaration ................................................................................ 3
4.2 Remote control function ............................................................ 4
4.3 Remote Control ................................................................................. 4
4.3.1 APP(APPlication) downl o ad and installation ................. 4
4.3.2 APP user registration and login ............................... 4
4.3.3 APP user manual ............................................................... 6
4.3.4 One Key To Net In ........................................................................ 7
4.3.5 The Main Control Page ............................................................ 8
5 FAQ .................................................................................................. 8
1. Summarize
YET404PC-WIFI(Four channel wireless intellect receiving control)is a dual system controller
with RF & and wi fiwhat can provide switch signal to the fourth relays,so it can meet many
requirements such as: control motor's corotation and reversal;the connection and lock of the
switch and other special control programs.This kind of wireless intellect receiving control mainly
APPly to auto door,curtain,lifting APPliance,gate way,lifter,industrial control and security field.
V1.0
CONTENT
1 / 8
2. Features
u Supporting Wi-Fi intranet or extranet connection: It can be used as a single product or networking
[Multi-product] to be controlled.
Supporting Smart Link network technology: Network configuration is simple and convenient.
u 315mhz/433mhz optional
u Only working with learning code (1527 and 2262)
u High confidentiality,stable characteristics,low power consume and easy to operate,plug and play.
3. Technical parameters
DC12V
Input Voltage
<10A
Contact current
IEEE802.11b/g/n
Wireless standard
2.4G ～2.5G(2400M ～2483.5M)Hz/433/315
Working frequency
WEP/TKIP/AES
Encryption type
WPA/WPA2
Security mechanism
802.11 b: -91 dbm (11 Mbps)
Receiving sensitivity 802.11 g: -75 dbm (54 Mbps)
433/315 :-112 dbm
<100mA
Static working current
Temperature：-40℃ ～ +80℃
Humidity：20% ～ 93%
Working environment
Temperature：-20℃ ～ +70℃
Storage environment Humidity：20% ～ 93%
<10
Controller capacity
128*79*31.5mm
Dimension
2 / 8
