BayCom K20S Quick Installation Manual

1. Package Contents

Baycom
Camera / Mounting Bracket / AC Power Adapter
K20H(K20,K20S,K20K)
/ Mounting Screws / Quick Installation Guide

2. Physical Descriptions

Front View
4
5
K20H Series
Wi-Fi
Back View
HD IP Camera
Quick Installation Guide
11
12
Side View
13. Audio jack (Optional)

14. Micro SD Card Slot

13
14
1. Lens
2. IR LED
(Night vision function)
1
3. Network LED Indicator
2

4. Power LED indicator

3. Network Requirements

3
5. Built-in Microphone
6 - An ADSL modem with Internet connection.
6. Speaker inside
7
- A broadband router, preferably with Wi-Fi
7. PIR Sensor (Optional)
capability. Please make sure DHCP is enabled
on your router.
8. Camera UID (Optional)

9. RJ-45 Network port

8

4. Install the hardware and connect with PC

10. WPS button

Before connect camera to the Internet, please
11. DC5V-IN Socket
check if your router has a WPS button, and then

12. Reset button

follow the WPS setup. If not (or unsure), please
follow the wire setup.
9
10
b. Press the WPS button (on the lower back of

A. Wired setup

Camera) for 4 seconds until its LED blinks.
a. Connect a network cable to the network port,
Then press the WPS button on your router and
which is on the back of Camera and a LAN
wait for the Wi-Fi connection to be established
port of the router.
(within 10 to 120 seconds).
b. Then plug the power adapter of Camera to
5VDC Power
power on the camera.
5VDC Power
ADSL Router
C. Viewing camera video image through I.E.
Ethernet Cable
Browser
a. In order to successfully install the camera,

B. Wireless setup via WPS

make sure you have these followings:
Note ： Please unplug the network cable for
- DHCP is enabled on your Wi-Fi router.
- Please link to the below hyperlink to download
Camera WPS setup.
and Install the Plug-in le in your PC.
(http://www.ucamsee.com/webe/html/news/02.
a. Plug the power adapter and power on your
php?num=33&page=1&kind=8)
Camera then wait for 40 seconds to boot the
- Make sure your camera and PC in the same
camera (operating system).
network segment.
b. Click Computer
ADSL Router
c. Click network icon, then double click the UCAM
(xx.xx.xx.xx.xx.xx)(xx.xx.xx.xx),
Windows will automatically open the browser
(please select IE browser).
Push WPS button
on the router and camera
P/N:2IGOK20H0111
