Sanji ZX70CL User Instructions

Briefed with the idea of "The Super intelligent Design Concept" Sanji engineers developed the ZX Range of
professional vehicle security alarm systems. The ZX range
security. Read these instructions for correct system operation. All points marked
1) SETTING THE Press the lock button, the unit will
sound 2 soft chirps and the indicators
ALARM
will flash twice. If fitted with central
locking the doors will lock and the
sensor will switch on.
The unit will sound two additional loud
2) DOOR / BOOT /
chirps and flash the indicators twice
BONNET OPEN
when setting the alarm. If a door is still
WARNING
open when the unit fully arms, the
doors will be bypassed. The system will
assume a faulty door switch.
3) ALARM DELAY The sensor led will flash rapidly during
the 20 second delay period. After the
PERIOD
delay, the sensor led will go on solid.
The alarm is now fully armed.
sensor led
flashing
rapidly
4) ALARM FAST After the alarm has been set press the
lock button again. The unit will now go
ARM
to fully armed and the sensor led will
turn on solid.
sensor led
flashing
rapidly
Press the lock button, the indicators
5) ALARM ARMED
will flash once to confirm that the
CONFIRMATION
alarm is fully set.
6) SENSOR SHUT Press both buttons together when
setting the alarm. The siren will sound
DOWN
4 chirps and the indicators will flash
twice. The sensor has now been
disabled. After 20 seconds the system
will be fully armed, however the sensor
will be disabled.
7) RESETTING Press the unlock button. The unit
will sound 1 soft chirp and the
THE ALARM
indicators will flash once. If fitted
with central locking the doors will
unlock.
ZX70CL USER INSTRUCTIONS
represents the 'state of the art' in vehicle
8) SELECTIVE
UNLOCK ON
ALARM
RESET
*
9) AUTO ZONE
BYPASS
10) VIOLATION
CHIRPS
11) DOOR LOCK
ON START
*
sensor led
on solid
12) DOOR LOCK
/ UNLOCK
IN DRIVE
13) DOOR
UNLOCK
ON IGNITION
OFF
*
14) REMOTE LOW
BATTERY
WARNING
*
Press the unlock button. The unit will
reset and selectively only open the
driver's door. To open the passenger
doors press the unlock button again.
If the unit detects a permanently faulty
zone, e.g. door or sensor during alarm
set, the system will sound 3 times then
isolate the faulty zone.
When the alarm is reset, the unit will
sound 4 loud chirps if the alarm had
triggered during the alarm set mode.
When the ignition is turned on, if all the
doors, boot and bonnet are closed, the
doors will lock.
Press the unlock button to unlock the
doors. Press the lock button to lock the
doors.
UNLOCK
Switch the ignition off. All the doors
will unlock. If fitted with selective
unlock, only the driver's door will open.
Press the unlock button to open the
passenger doors.
The remote led will normally be on solid
when pressing any button. If the remote
batteries are low the led on your
remote control will flash. Replace the
batteries with: 2 x CR1220 lithium
batteries.
are optional features.
LOCK
ZX70CL_USER_REV2
