C.R. LAURENCE Co., INC.
Reciprocating Saw
CAT. NO. LD195, LD195EU, LD195AU
Subject to printing errors and design changes over which we have no control. In the event of problems please contact our Customer Service Department.
COPYRIGHT C.R. LAURENCE CO., INC. 2013
©
AVDB3104 05.13
Visit us at crlaurence.com for international toll free information

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the LD195 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for CRL LD195

  • Page 1 C.R. LAURENCE Co., INC. Reciprocating Saw CAT. NO. LD195, LD195EU, LD195AU Subject to printing errors and design changes over which we have no control. In the event of problems please contact our Customer Service Department. COPYRIGHT C.R. LAURENCE CO., INC. 2013 ©...

  • Page 2: Important Safety Information

    C.R. LAURENCE Co., INC. ImpoRtANt sAfety INfoRmAtIoN In this manual, on the labeling, and all other information provided with this product: This is the safety alert symbol. CAUtIoN, used with the safety It is used to alert you to potential alert symbol, indicates a personal injury hazards.

  • Page 3: Electrical Safety

    C.R. LAURENCE Co., INC. eLeCtRICAL sAfety 1. power tool plugs must match the outlet. Never modify the plug in any way. Do not use any adapter plugs with grounded power tools. Unmodified plugs and matching outlets will reduce risk of electric shock. 2.

  • Page 4: Reciprocating Saw Safety Warnings

    Holding the work by hand or against your body leaves it unstable and may lead to loss of control. 3. maintain labels and nameplates on the tool. These carry important safety information. If unreadable or missing, contact CRL customer service for a replacement.

  • Page 5: Vibration Safety

    C.R. LAURENCE Co., INC. 6. When using a handheld power tool, maintain a firm grip on the tool with both hands to resist starting torque. 7. Do not leave the tool unattended when it is plugged into an electrical outlet.   Turn off the tool, and unplug it from its electrical outlet before leaving.

  • Page 6: Double Insulated Tools: Tools With Two Prong Plugs

    C.R. LAURENCE Co., INC. 5. Include vibration-free periods each day of work. 6. Grip tool as lightly as possible (while still keeping safe control of it). Let the tool do the work. 7. To reduce vibration, maintain the tool as explained in this manual. If any abnormal vibration occurs, stop use immediately.

  • Page 7: Extension Cords

    C.R. LAURENCE Co., INC. eXteNsIoN CoRDs 1. Grounded tools require a three wire extension cord. Double insulated tools can use either a two or three wire extension cord. 2. As the distance from the supply outlet increases, you must use a heavier gauge extension cord. Using extension cords with inadequately sized wire cause a serious drop in voltage, resulting in loss of power and possible tool damage.

  • Page 8: Specifications

    C.R. LAURENCE Co., INC. speCIfICAtIoNs CAt. No. LD195 LD195eU LD195AU Electrical Rating 120V / 60 HZ / 6 A 220V / 50 HZ / 800W 240V / 50 HZ / 800W Speed 0-2500 SPM 0-2500 SPM 0-2500 SPM Stroke Length 7/8"...

  • Page 9: Installing The Saw Blade

    C.R. LAURENCE Co., INC. opeRAtING INstRUCtIoNs Read the eNtIRe ImpoRtANt sAfety INfoRmAtIoN section at the beginning of this manual including all text under subheadings therein before set up or use of this product. to pReveNt seRIoUs INJURy fRom ACCIDeNtAL opeRAtIoN: Squeeze the release Trigger and unplug the tool from its electrical outlet before performing any procedure in this section.

  • Page 10: Workpiece And Work Area Set Up

    C.R. LAURENCE Co., INC. WoRKpIeCe AND WoRK AReA set Up 1. Designate a work area that is clean and well lit. The work area must not allow access by children or pets to prevent distraction and injury. 2. Route the power cord along a safe route to reach the work area without creating a tripping hazard or exposing the power cord to possible damage.

  • Page 11: Plunge Cutting

    C.R. LAURENCE Co., INC. PLUNGE CUTTING Plunge cut into plywood and thin board panels. Do not attempt to plunge cut into thick, hard wood or metal panels. Rotation Tool on 1. Clearly mark the line of cut. Pivot Shoe 2. From a convenient starting point within the cutting area, place the tip of the Blade over that point with the Saw parallel to the line of cut.

  • Page 12: Cleaning, Maintenance, And Lubrication

    C.R. LAURENCE Co., INC. CLEANING, MAINTENANCE, AND LUBRICATION 1. BefoRe eACH Use, inspect the general condition of the tool. Check for: • loose hardware • damaged electrical wiring • misalignment or binding of moving parts • any other condition that may affect its safe operation •...

  • Page 13: Parts List And Diagram

    C.R. LAURENCE Co., INC. pARts LIst AND DIAGRAm PLEASE READ THE FOLLOWING CAREFULLY THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. NEITHER THE MANUFACTURER OR DISTRIBUTOR MAKE ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO REPLACE ANY PARTS OF THE PRODUCT.

  • Page 14: Assembly Diagram

    C.R. LAURENCE Co., INC. AssemBLy DIAGRAm Visit us at crlaurence.com for international toll free information...
