Omega OCD45W Instruction Manual

Troubleshooting

Review the following pages before calling for service.
Problem Possible Cause
Timer knob does not • Is the power cord inserted firmly?
turn
Drum does not turn • Is the door closed?
• Is the power cord inserted?
• Does the receptacle have power?
Hot air is not blowing • Is the timer incorrectly set on cold air?
out
The laundry is not • Are the front and back filters clogged?
• Is there too much laundry in the dryer?
thoroughly dried
• Have items been added whilst the dryer
is in operation?
• Has the laundry become twisted whilst
drying?
• Has the dryer been placed in a small
and badly ventilated area?
• Have you set the dryer to Anti-
Wrinkle?
Dryer does not start • Is there a power failure?
• Is the power cord inserted firmly?
• Is the door closed?
• Is the timer in the OFF position?
Model OCD45W
Drying Capacity 4.5kg
Voltage 220-240V-
Frequency
50Hz
Rated Input
1450W
Net Weight
20kg
Dimensions 600mmx 435mmx700mm
NOTE: Consistent with our continuing product development
policy, improvements may have been made which render the
contents of this package slightly different to that shown.
What to do
• Insert the power cord firmly
• Close the door.
• Insert the power cord firmly.
• Check the power cord
receptacle.
• Set the timer to hot air.
• Clean the filter.
• Reduce the amount in the dryer.
• Re-dry the items again
• Untwist the items and re-dry.
• Place the dryer in a well-vented
area.
• Try using 'Warm' or 'Hot' setting
instead
• Try again when there is power
• Insert the power cord firmly
• Close the door
• Set the dry time
12
omega
OCD45W
----------•---------
Capacity 4.5kg
./

INSTRUCTION MANUAL
