Laser SPK-S10 User Manual

2.0
SPEAKER SYSTEM
For technial support please visit
http://www.laserco.com.au
SPK-S10 User Manual

SPECIFICATION

Frequency response 120Hz – 20KHz
Power Input: 240VAC/50Hz
Dimensions: 67mm (W) X 200mm (H) X 58mm (D).

INSTALLATION AND OPERATION GUIDE

A: Before connecting be sure that all components are switched off.
B: Insert the 3.5mm stereo jack in to the audio out socket of the PC sound card,
MP3 Player or other Audio Devices.
C: Plug the AC power cable in to the power socket.
D: Turn the volume control to minimum and then switch the speaker system on
by pressing the POWER button. The LED will light up.
E: Adjust the volume knob to a desirable volume level.
POWER
Headphone Jack
VOLUME
1
Speaker : 5090 x 2 FULL RANGE
Audio input: 3.5 mm stereo jack
SPK-S10

User Manual

Please read carefully before use

CONNECTIONS

( CD/ MP3/ Radio/ Computer......) To Audio Source
*Disconnect AC power cord from the power outlet when not in use.
2
