- Page 1 HDMI-LSP CS-HHP Compact Inline HDMI Surge Protector Compact Inline Surge Protector Operation Manual Operation Manual...
- Page 3 SAFETY PRECAUTIONS Please read all instructions before attempting to unpack, install or operate this equipment and before connecting the power supply. Please keep the following in mind as you unpack and install this equipment: • Always follow basic safety precautions to reduce the risk of fi re, electrical shock and injury to persons.
-
Page 4: Table Of Contents
CONTENTS 1. Introduction ............1 2. Applications ............1 3. Package Contents ........... 1 4. System Requirements ........1 5. Features ............. 2 6. Operation Controls and Functions ....3 7. Connection Diagram ........4 8. Specifi cations ........... 5 9. -
Page 5: Introduction
1. INTRODUCTION Unexpected voltage spikes and ESD (Electrostatic discharge) are the primary causes of component damage and failure over HDMI. This compact surge protector is designed to protect connected sources and sink (display) devices by blocking or shorting to ground unexpected voltage spikes and surges. -
Page 6: Features
5. FEATURES • HDCP 1.4 and 2.2 content pass through • Compact design with HDMI input and output interface to fi t most of electronic devices • Maximum supported pass through resolution up to 3840x2160@24/25 and 30 • 3D contents pass through supported •... -
Page 7: Operation Controls And Functions
6. OPERATION CONTROLS AND FUNCTIONS HDMI OUT HDMI IN HDMI SURGE PROTECTOR HDMI OUT Connects with displays or projector. HDMI IN Connects the source equipment such as DVD player or matrix / scaler unit. -
Page 8: Connection Diagram
7. CONNECTION DIAGRAM Display HDMI Cable HDMI OUT HDMI IN HDMI SURGE PROTECTOR HDMI Cable DVD player... -
Page 9: Specifi Cations
8. SPECIFICATIONS Input Ports 1 x HDMI Output Ports 1 x HDMI Over voltage protection Supported Resolution 480 i to 4K2K YUV 4:2:0 Supported audio formats LPCM, Dolby, DTS Support audio sampling 32kHz ~ 192kHz rate EDID Bypass Audio Return Channel Bypass 3D content Bypass... -
Page 10: Support Timing Table & Hdmi Cable Length
9. SUPPORT TIMING TABLE & HDMI CABLE LENGTH 9.1 Support Timing Table HDMI IN & OUT RESOLUTION SUPPORTED 480i 576i 480p 576p 640x480 800x600 1080i @50&60 1080p@50&60 1024x768 1360x768 1280x1024 1600x1200 1920x1200 ... - Page 11 Should you feel your product does not function adequately due to defects in materials or 1. Damage requiring service workmanship, PhD Solutions (hereby referred to as “the warrantor”) will, for the length of the period indicated below: All units should be serviced by a PhD Solutions qualified service person.: Repair the product with new or 2.
- Page 12 Product Service Provided 1. Damage requiring service 1. Damage requiring service All units should be serviced by a PhD Solutions qualified service person.: All units should be serviced by a PhD Solutions qualified service person.: 2. Servicing Personnel 2. Servicing Personnel Do not attempt to service the unit beyond that described in these operating instructions.
- Page 13 2. There are no express warranties except as listed under “limited warranty coverage.” The warrantor is not liable for incidental or consequential damage resulting from the use of this product or arising out of any breach of this warranty. 2. There are no express warranties except as listed under “limited warranty coverage.” The warrantor is not liable for incidental or consequential damage resulting from the use of this For example: damage for lost time, the cost of having a person/persons remove or re- ¥...
- Page 16 Premium High Definition Solutions Home page: http://www.phdsolutions.co...
