Gocontrol WNK01-21KIT Quick Programming Manual

Home Security Suite Quick Programming Guide
Door / Window Sensor
1.
Identify Parts
DOOR /
WINDOW
SENSOR
BRACKET
MAGNET
2.
Insert Battery
3.
Add Product Via App
a. Select "ADD PRODUCT".
b. Select Sensors.
c. Select Door / Window.
d. Follow the App
instructions.
4.
Install Device
(refer to full instructions)
MOUNT
MAGNET
SENSOR
ON WINDOW
ON WINDOW
OR DOOR
OR DOOR
FRAME
1.
Identify Parts
LED STATUS
INDICATOR
LED STATUS
INDICATOR
FRONT
CASE
VIEW
SCREW
2.
Insert Battery
OBSERVE
BATTERY
POLARITY !!!
INSERT BATTERY
INTO HOLDER
3.
Add Product Via App
a. Select "ADD PRODUCT".
b. Select Sensors.
c. Select Motion Sensor.
d. Follow the App
instructions.
PROGRAM
SWITCH
4.
Install Device
DON'T POINT AT HEAT SOURCES (HEATERS, ETC.)
WINDOWS, OTHER MOTION DETECTORS OR
DOOR/WINDOW TRANSMITTERS
FRONT
ROOM

Motion Sensor

PRESS ON TAB
TO OPEN CASE
SENSOR
LENS
PROGRAM SWITCH
ACCESS HOLE
OBSERVE
BATTERY
POLARITY !!!
INSERT BATTERY
INTO HOLDER
(refer to full instructions)
PIR
MOTION
DETECTOR
(FOR INDOOR
USE ONLY)
BEDROOM
MOUNT
DETECTOR
SO THAT
BATH
INTRUDER
KITCHEN
WILL CROSS
BEAMS
Siren / Strobe
1.
Identify Parts
REMOVABLE
LED STATUS
MOUNTING
INDICATOR
PLATE
FRONT
VIEW
REAR
SIREN
VIEW
SOUNDER
STROBE
LIGHTS
2.
Insert Batteries
OBSERVE
BATTERY
POLARITY !!!
INSERT HOLDER
INTO SIREN CASE
3.
Add Product Via App
PROGRAM a. Select "ADD PRODUCT".
SWITCH
b. Select Alarms.
c. Select Siren / Strobe.
d. Follow the App
instructions.
4.
Install Device
(refer to full instructions)
MOUNTING
PLATE
PREMIUM
BATTERY
HOLDER
REAR
VIEW
PROGRAM
MOUNTING PLATE
SWITCH
LOCKING TAB
INSERT
4 TYPE "AA"
ALKALINE
BATTERIES IN
IN HOLDER
PROGRAM
SWITCH
LOCKING
TAB
