Whalen WS-RWTB-4D Assembly Instructions And User Manual

Mobile tool storage box

Advertisement

1.
Please read instructions prior to assembly. 5. Do not tighten any bolts until all bolts have been started.
2.
Verify that there are no missing parts.
3.
Keep instructions for future reference.
4.
Recommend to use 2 people for assembly.
MAXIMUM CAPACITY: 181.4 kg / 400 lb
MAXIMUM LOAD: 13.6 kg / 30 lb
FOR EACH DRAWER
Use with products heavier than the maximum weights indicated may result in instability
causing possible injury.
CAUTION:
Please take safety precautions when using the tool chest.
o New drawer glides may be stiff and difficult to open when first expanding the glide. A
gently outward pull should release the safety catch that is built into the glide to prevent
drawer opening while moving the tool chest.
o Do not open more than one drawer at a time.
o Do not step or climb on drawers.
o Fill the bottom drawer first. If the tool chest is filled from the top drawer down, the tool
chest may become top-heavy and become unstable.
o Set the brake on locking casters unless you are moving the tool chest.
o Lock drawers priorto moving the chest.
Please call for replacement parts or assistance:
8:30a.m. – 4:30p.m., Monday through Friday, Pacific Standard Time
Version: 2016-03-10
Whalen Furniture Manufacturing
Mobile Tool Storage Box
ITM. / ART. 583753
MODEL#: WS-RWTB-4D
This unit is intended for use only with the maximum weights indicated.
Or visit our website:
Or e-mail your request to
6. Gently set parts on a flat, protective surface.
7. For indoor use.
1-866-942-5362
www.whalenfurniture.com
parts@whalenfurniture.com
(English and Spanish)
Rev. 1
Factory # JIWOHA
