    User Guide Table of Contents General Safety Precautions ........................7 Product Overview .............................8 Specifications ............................10 Typical Setup ............................11 S11064 Detector Configuration ......................11 Detector Channels ..........................12 High Voltage Interface..........................13 Preamplifier.............................14 Discriminator............................15 Top View..............................16 Component Locations and Functions....................17 SIB Connector Pinout..........................19 Mechanical Information..........................20 Technologies Limited The Coach House Watery Lane Bath BA2 1RL T: +44 (0) 1225 780 400 F: +44 (0) 8701 266 449 E: info@aptechnologies.co.uk - 5 -...
  • Page 6 Figure 6: Leading Edge Discriminator Timing..................15 Figure 7: PCB Top and Bottom Views ..................... 16 Figure 8: Component Locations and Functions ..................17 Figure 9: SIB416 Printed Circuit Board Dimensions ................20 List of Tables Table 1: Specifications..........................10 Table 2: Connectors ..........................
  • Page 7: General Safety Precautions

    To avoid electric shock, fire hazard, or damage to the product, do not apply a voltage to any input outside of its specified range. Electrostatic Discharge Sensitive Electrostatic discharges may result in damage to the SIB416. For this reason, the SIB416 board is intended to be operated in a user’s conductive instrument enclosure. Do Not Operate in Wet or Damp Conditions To avoid electric shock or damage to the product, do not operate in wet or damp conditions.
  • Page 8: Product Overview

    PhotoniQ where it can be enabled and configured through the PhotoniQ graphical user interface. A special current-sense output from the bias interface circuitry is sent to a variable gain preamplifier on the SIB416 to represent the total AC charge signal measured by all four MPPC arrays. This signal, which is available to the user on an SMB jack, is fed into a user-programmable threshold leading edge discriminator.
  • Page 9: Figure 1: Functional Block Diagram

    PREAMP DSCR VTH1 TRIG LOGIC DSCR VERTILON SIB416 VTH2 HAMAMATSU S11064 MPPC SENSOR INTERFACE BOARD Figure 1: Functional Block Diagram Technologies Limited The Coach House Watery Lane Bath BA2 1RL T: +44 (0) 1225 780 400 F: +44 (0) 8701 266 449 E: info@aptechnologies.co.uk - 9 - www.aptechnologies.co.uk...
  • Page 10: Specifications

    SIB416 Sensor Interface Board Hamamatsu S11064 MPPC Specifications = +25C, unless otherwise noted) Description Units Notes INPUT CHANNELS Quantity 64 direct coupled channels to PhotoniQ channels 1 to 64. Detector cathode voltage supplied from PhotoniQ data Cathode Bias Voltage +0.25...
  • Page 11: Typical Setup

    The SIB416 supports up to four Hamamatsu S11064 multi-pixel photon counter devices. The devices are attached to the SIB416 as shown in the figure on the following page. If one device is used, the MPPC is plugged into the receptacle pin pattern in the center of the board.
  • Page 12: Detector Channels

    IQSP580 can be used instead. The PhotoniQ utilizes DC-coupled high speed transimpedance amplifiers that maintain a DC bias voltage of +0.25 volts on each of its inputs. Because the S11064 devices are operated on the SIB416 in common anode arrangement, the current polarity to the PhotoniQ preamplifiers is out of the inputs. For this reason, the Input Polarity under the Data Configuration menu in the PhotoniQ GUI should be set to the default value of positive.
  • Page 13: High Voltage Interface

    High Voltage Interface The SIB416 employs the interface circuit shown below between the high voltage input connector, J3, and the anodes of the individual SiPMs on the S11064 devices. The monitor output (HVMON) allows the high voltage anode bias to the MPPCs to be indirectly monitored at a reduced voltage level.
  • Page 14: Preamplifier

    SIB416. The preamplifier generates a voltage signal in response to the current signal on its input from any of the 64 SiPMs from the 2 x 2 array of MPPCs. This voltage signal is available on an SMB output connector on the SIB416 and is also fed to the input of the discriminator.
  • Page 15: Discriminator

    The discriminator generates a logic signal when a pulse from the preamplifier exceeds a user-defined threshold. The SIB416 GUI dialog box allows the user to set this threshold between 0 and 100% where 100% is equal to the maximum possible signal amplitude in the discriminator channel. When a pulse is detected, the trigger output from the board becomes active.
  • Page 16: Top View

    SIB416 Sensor Interface Board Hamamatsu S11064 MPPC Top View Figure 7: PCB Top and Bottom Views Connection Pins for S11064 (U1) Negative High Voltage Bias Input (J3) Connection Pins for S11064 (U2 – U5) Preamplifier Output (J4) SIB Connector, Channels 1 to 32 (J1)
  • Page 17: Component Locations And Functions

    User Guide Component Locations and Functions 2 3 4 Figure 8: Component Locations and Functions Technologies Limited The Coach House Watery Lane Bath BA2 1RL T: +44 (0) 1225 780 400 F: +44 (0) 8701 266 449 E: info@aptechnologies.co.uk - 17 - www.aptechnologies.co.uk Vertilon Corporation, 66 Tadmuck Road, Westford, MA 01886 Tel: (978) 692-7070...
  • Page 18: Table 2: Connectors

    SIB416 Sensor Interface Board Hamamatsu S11064 MPPC Name Function Description CHANNEL 1 - 32 Sensor interface board connector, cathodes 1 through 32 from S11064 devices CHANNEL 33 - 64 Sensor interface board connector, cathodes 33 through 64 from S11064 devices...
  • Page 19: Sib Connector Pinout

    SIB Connector Pinout The SIB416 connectors and cables are fully compatible with all Vertilon PhotoniQ systems. For applications utilizing data acquisition systems other than Vertilon’s PhotoniQ series, the pinouts for connectors J1 and J2 are provided in Table 5 as a reference.
  • Page 20: Mechanical Information

    SIB416 Sensor Interface Board Hamamatsu S11064 MPPC Mechanical Information 84.00 6.00 6.00 17.20 19.20 18.20 2 3 4 102.00 44.00 19.00 15.00 ALL DIMENSIONS IN MILLIMETER Figure 9: SIB416 Printed Circuit Board Dimensions Technologies Limited The Coach House Watery Lane Bath BA2 1RL T: +44 (0) 1225 780 400 F: +44 (0) 8701 266 449 E: info@aptechnologies.co.uk...
