Summary of Contents for Arkin Touch 7
- Page 1 Arkin Touch 7 User manual 1300 089 967 info@arkin.com.au www.arkin.com.au...
-
Page 2: Table Of Contents
Table of Contents In the Box Initial Setup Reconfiguring the Control Panel Enabling/Disabling the Blue LED Lighting In-Wall Mounting the Control Panel Removing the Control Panel (In-Wall/Glass Mount) On-Wall Mounting the Control Panel... -
Page 3: Initial Setup
In the Box Arkin Touch, power supply, 2 screws, in-wall bracket, 2 x on-wall bracket (90 degree bend), 2 x desk mount (45 degree bend), user manual. Glass/On-wall mount sold separately. Initial Setup Connect the power and network using one of the following options:... -
Page 4: Reconfiguring The Control Panel
Configure the network using one of the following options: Ethernet with DHCP: This is the default, so nothing further to do. Note that Ethernet will not work if Wi-Fi is enabled. To see the allocated IP address, press "More..." under "WIRELESS & NETWORKS". Click "Ethernet" on the right, and the IP Address is shown. -
Page 5: Enabling/Disabling The Blue Led Lighting
Click "ABAS" on the right. On the right, click "Clear data". Power cycle the Control Panel by removing and reinserting the power. After the device has started, you can now enter a new IP Address and click "Save". Enabling/Disabling the Blue LED Lighting Once the Control Panel has started and is showing the control interface, long press the upper left corner of the screen for 8 seconds to bring up a dialog box. -
Page 6: Removing The Control Panel (In-Wall/Glass Mount)
Installing the Control Panel: Insert the ethernet cable (marked "A" in Figure 3) into the RJ-45 connector (LAN / POE) on the Control Panel (marked "A" in Figure 4). You should also insert the power cable at this point if not using POE. Align the tabs on the mounting bracket (marked "B"... -
Page 7: On-Wall Mounting The Control Panel
On-Wall Mounting the Control Panel The Control Panel was supplied with two L shipped brackets with a 90 degree bend. The long side of the two brackets should be screwed into the wall with two screws per bracket, and the short side should protrude out from the wall at the bottom. The hole centres of the two brackets should be 108mm apart.
