Summary of Contents for ICOP Technology VSX-DIP-PCI-V2
- Page 2 VSX/VDX-DIP-PCI Development Kit & VSX-DIP-PCI-V2 CPU Module with 5S/4USB/LAN/2GPIO 128MB DDR2 Onboard User’s Manual (Revision 1.0A)
- Page 3 No part of this manual may be reproduced, copied, translated or transmitted, in whole or in part, in any form or by any means without the prior written permission of the ICOP Technology Inc. ©Copyright 2007 ICOP Technology Inc.
-
Page 4: Table Of Contents
T a b l e C o n t e n t s T a b l e o f C o n t e n t s .............iii C h a p t e r 1 Introduction……………………………………………1 Packing List............1 Product Description .......... -
Page 5: Chapter 1 Introduction
IDE cable (2.0 ) x 1 IDE cable (2.54 ) x 1 GPIO cable x 3 Product Name Package Embedded Vortex86SX DIP 204pin-PCI VSX-DIP-PCI-V2 CPU Module x1 Product Name Package XGI Z9S VGA/ DVI PCI board x1 PCI-VGA-Z9s Vortex86SX™ DIP-204pin-PCI CPU Module... -
Page 6: Product Description
Product Description The VSX-DIP-PCI-V2 family of low-power x86 embedded controller is designed to meet DIP-204pin-PCI specification, and integrated with the following features. 300MHz Vortex86SX System-On-Chip Enhanced IDE 128 / 256MB DDR2 system memory JTAG interface 4 USB 2.0 (host) AMI BIOS... -
Page 7: Specifications
External 3-pin Mini DIN connector for Power x1 Power Requirement Single Voltage +5V @ 250mA Dimension 240 X 160 mm (9.45 x 6.3 inches) Weight 300g Operating C ~ +70 Temperature -40°C ~ +85°C (Optional) Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... - Page 8 VSX-DIP-PCI-V2 Features VSX-DIP-PCI-V2 DM&P SoC CPU Vortex86SX- 300MHz Real Time Clock with Lithium Battery Backup Cache L1:16K I-Cache, 16K D-Cache BIOS AMI BIOS Bus Interface PCI interface System Memory 128 / 256MB DDR2 onboard Watchdog Timer Software programmable from 30.5 us to 512 seconds x2...
- Page 9 Video Memory 32MB DDR2 VGA Memory, support resolution up to 1600 x 1200 @ 16M External 15-pin D-Sub Female connector for VGA x1 Connectors External DVI Female connector for VGA x1 Operating C ~ +60 Temperature Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
-
Page 10: Board Dimension
Board Dimension VSX-DEV-204-PCI Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... - Page 11 VSX-DIP-PCI-V2 Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
-
Page 12: Chapter 2 Installation
C h a p t e r 2 Installation Board Outline VSX / VDX -DEV-204-PCI Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... - Page 13 VSX-DIP-PCI-V2 Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 14 PCI-VGA-Z9s VSX-DIP-PCI-V2 Development Kit VSX-DIP-PCI-V2 Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
-
Page 15: Connectors & Jumpers Location
Connectors & Jumpers Location Connectors VSX / VDX-DEV-204-PCI Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... - Page 16 VSX-DIP-PCI-V2 Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
-
Page 17: Connectors & Jumpers Summary
USB 0/ USB 1 USB connector 8-pin x-PCI & Multi I/O 204-pin Pin Header, 2.0∅ 34x6 Connector-204 Pin JH12 BUZZER Power SWITCH IDE- LED IDE Active LED (Green ) LED-SMD PWR-LED Power Active LED (Red) LED-SMD Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... -
Page 18: Pin Assignments & Jumper Settings
Note: Add 0 ohm on R38 position, COM3 will change to TTL J8: COM4: RS232 / TTL Mode Selector Pin # Signal Name Pin # Signal Name DCD4 RXD4 TXD4 DTR4 DSR4 RTS4 CTS4 Note: Add 0 ohm on R39 position, COM3 will change to TTL Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... - Page 19 TXDEN1 TXDEN2 J10: RESET Pin # Signal Name Pin # Signal Name Reset J11: PS/2 Keyboard / Mouse Pin # Signal Name Pin # Signal Name KBDATA KBCLK MSDATA MSCLK GGND GGND GGND GGND GGND Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 20 Signal Name Pin # Signal Name IDERST IDED7 IDED8 IDED6 IDED9 IDED5 IDED10 IDED4 IDED11 IDED3 IDED12 IDED2 IDED13 IDED1 IDED14 IDED0 IDED15 IDEREQ IDEIOW IDEIOR ICHRDY IDEACK IDEINT IDESA1 IDECBLID IDESA0 IDESA2 IDECS-0 IDECS1 IDELED Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 21 IDED1 IDED14 IDED0 IDED15 IDEREQ IDEIOW IDEIOR ICHRDY IDEACK IDEINT IDESA1 IDECBLID IDESA0 IDESA2 IDECS0 IDECS1 IDELED J15: DC +5V INPUT Pin # Signal Name J16: Power Connector (Terminal Block 5.0mm) Pin # Signal Name Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 22 (Open: On, Close: Off) Mode Selector Pin # Signal Name Pin # Signal Name RS232 Disable JP4: COM2: On/ Off (Open: On, Close: Off) Mode Selector Pin # Signal Name Pin # Signal Name RS232 Disable Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 23 J45A: COM 1 Signal Signal Pin # Pin # Name Name DCD1 RXD1 TXD1 DTR1 DSR1 RTS1 CTS1 J45B: COM 2 Signal Signal Pin # Pin # Name Name DCD2 RXD2 TXD2 DTR2 DSR2 RTS2 CTS2 Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 24 J46A: COM 3 Signal Signal Pin # Pin # Name Name DCD3 RXD3 TXD3 DTR3 DSR3 RTS3 CTS3 J46B: COM 4 Signal Signal Pin # Pin # Name Name DCD4 RXD4 TXD4 DTR4 DSR4 RTS4 CTS4 Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 25 VSX-DIP-PCI-V2 Summary Table Description Type of Connections Pin nbrs. JTAG 6-pin Wafer, 1.25∅ , 6x1 x-PCI & Multi I/O 204-pin Box Header, 2.0∅ 34x6 Connector-204 Pin JH12 PWR-LED Power Active LED (Green) LED-SMD MTBF-LED MTBF-Out (Orange) LED-SMD Vortex86SX™ DIP-204pin-PCI CPU Module...
- Page 26 J1: JTAG Pin # Signal Name Pin # Signal Name Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 27 JH7/JH8/JH9/JH10/JH11/JH12: DIP-204pin-PCI Signal Assignment Note: 1-Multi-function pins of JH10, JH11, and JH12 are controlled by BIOS setting. 2- If you Enable 2M SPI flash Disk on the BIOS setting, you cannot use GP30~GP33 Pins. Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
-
Page 28: System Mapping
System Mapping Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... - Page 29 Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
- Page 30 Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
-
Page 31: Watchdog Timer
The M6117D compatible watchdog timer is called WDT0 and new one is called WDT1. We also provide DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file: http://www.dmp.com.tw/tech/vortex86dx/ Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... -
Page 32: Gpio
We also offer DOS, Linux and WinCE example for your reference. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file: http://www.dmp.com.tw/tech/vortex86dx/ Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... -
Page 33: Spi Flash
Floppy (A: Driver or B: Driver). Then you must know how to set for this condition in CMOS Setup and boot up under DOS 6.22, X-DOS, DR-DOS and Free DOS. For more technical support, please visit: http://www.dmp.com.tw/tech or download the PDF file: http://www.dmp.com.tw/tech/vortex86dx/ Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... -
Page 34: Chapter 3 Driver Installation
Please get the drivers from the Driver CD which attached with the standard packing of VSX-DIP- PCI-V2 “DIP-204pin- PCI” CPU board or please get it from DMP official website: http://www.dmp.com.tw/tech/vortex86sx/ VSX-DIP-PCI-V2 CPU board also supports most of the popular Linux distributions, for more detail information, please visit DMP official website: http://www.dmp.com.tw/tech/vortex86sx/ Vortex86SX™... -
Page 35: Appendix
ICOP also provide the business version of DSock for those customers who are using other x86 CPUs. If you would like to use DSock or business version of DSock, Please mail to info@icop.com.tw contact your regional sales. Please download the trial DSock software and Utilities from our website: http://www.dmp.com.tw/tech/dmp-lib/dsock/ Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... -
Page 36: Vsx-Dip-Pci & Vsx-Dev-204-Pci Schematic
Designer can place connectors precisely where needed for the application on a baseboard designed to optimally fit a system’s packaging. Please contact or e-mail our regional sales to get VSX-DIP-PCI-V2、VDX-DIP-PCI and VSX-DEV-204-PCI Schematic. Vortex86SX™ DIP-204pin-PCI CPU Module... -
Page 37: Bios Default Setting
CMOS as default setting. Press “End” Key, when the power on Press <Del> to enter the AMI BIOS setup Press “F9” to Load Optimized Defaults Press “F10” to Save configuration changes and exit setup Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2... -
Page 38: Warranty
Authorization can be obtained by calling or faxing the vendor and requesting a Return Merchandise Authorization (RMA) number. Returned goods should always be accompanied by a clear problem description. Vortex86SX™ DIP-204pin-PCI CPU Module VSX-DIP-PCI-V2...
