Summary of Contents for Maurer Elektromaschinen Captest 1225 V2
- Page 1 Operation Manual Captest 1225 V2 Operation Manual Processor Controlled Processor Controlled Processor Controlled Processor Controlled Capacity Tester Capacity Tester Capacity Tester Capacity Tester 12V 0.3A-25A also for 24V 0.3A –25A English Version...
-
Page 2: Menu System
Operation Manual Captest 1225 V2 Introduction: With this processor controlled capacity tester you can measure the capacity of the batteries. You can set the cut off voltage (The voltage limit where you want to stop the discharge), the discharging current, and the charging time between the cycles. -
Page 3: Setting The Test Parameters
Operation Manual Captest 1225 V2 Setting the test parameters: To set the test parameters you have to switch to the test parameters screen and press the Start/Stop button. This submenu consists of 4 different screens. You can change between the screens by pressing the display change button. -
Page 4: Starting The Test
Operation Manual Captest 1225 V2 Reading the test results: In the main menu go to the read test result display and press the Start/Stop button. Pressing the Display Change button you can see the result of the each cycle. A cycle consists of a charging and a discharging part. -
Page 5: During The Test
Operation Manual Captest 1225 V2 During the test: During the test you can see the following screen: Elapsed time Voltage 0025 min 12,0 V 1/1 Disch 1.3 A.h Cycle Process Elapsed time: This is the time since the beginning of the actual process (charging or...
