TASER AXON body Quick Start Guide
English (U.S./Canada/Australia/U.K.)
Hardware
AXON body Camera
AXON body Wall Charger
Step 1:
Recording
The AXON body camera has two operating modes. The default mode, or BUFFERING
mode, provides pre-event buffering to capture activities that occur before you
activate the EVENT (recording) mode.
1 Turn the system on. Move the ON/OFF switch to the ON position.
• The camera takes a few seconds to boot up and be ready to record (the red area
under the switch will be exposed with the switch moved to the ON position).
• The operation LED will be solid red and then transition to blinking green
when the system goes into BUFFERING mode.
• The AXON body camera will go into BUFFERING mode after the boot up
sequence. The BUFFERING mode holds the previous 30 seconds of video
[NO AUDIO] leading up to the beginning of a recording.
Step 2:
Camera Operation LED
The AXON body camera's operation LED displays the system's current operating
mode.
Operating Mode
Recording
Buffering
Booting up/powering down
AXON body USB Cable
Solid Red Blinking Green
Boot Up Mode Buffering Mode
Operation LED
Blinking red
Blinking green
Solid red

Quick Reference

Operation LED
Top View
Recharging/Dataport
Data Transfer & Recharging
through PC or EVIDENCE.com
Dock
Camera Lens
Speaker
Battery LED
Green = 41% - 100%
Yellow = 20% - 40%
Red = Less Than 20%
Microphone
Audio quality will be reduced if the camera is not in the holster.
2 To record, quickly double-press the EVENT button.
• The camera now records audio as well as video.
• The camera will beep twice to let you know that recording has started. The
2 beeps will repeat every 2 minutes (if the system is muted, there will be
no audio notifications).
• The operation LED will blink red.
Event Button
3 To stop recording and return to BUFFERING mode, press and hold the EVENT
button for at least 3 seconds until there is a long, audible beep.
Because the system does not capture audio in BUFFERING mode, the first 30
seconds of a recorded event will be video-only (depending on your agency's
settings). BUFFERING mode starts only after the camera is turned on. The system
does not record when the AXON body camera is turned off.
Step 3:
Battery LED
The camera's battery LED displays the battery's remaining capacity, when the device
is being used or when charging.
Battery Status
Battery capacity is 41–100%
Battery capacity is 20–40%
Battery capacity is less than 20%
Battery critically low
Volume/Pairing
Bottom View
Bluetooth Pairing and Upload
Status LED
Power Switch
Red = On/Buffering
Event Button
Double Tap = Start Record
Hold 3 Sec = Stop Record
Battery Status Button
Push to Show Status of
Battery
Blinking Red - Record Mode
Battery LED
Green
Yellow
Red during operation; flashing red and
yellow during charging
Blinking red and yellow
