Summary of Contents for Telegesis ZigBee GW357
- Page 1 TG-PM-510 ZigBee Communications Telegesis Gateway ZigBee Communications Product Manual 0510 Gateway Telegesis ZigBee Communications Gateway Product Manual Rev: 1 Date: Aug 2013...
-
Page 2: Table Of Contents
Appendix A ............................. 28 Bootloading ETRX3 ZigBee module .................... 28 Warranty ............................31 Caution ............................32 Cleaning ............................32 Compliance with Laws and Regulations ..................33 Disclaimer ............................33 Contact Information ......................... 33 ©2013 Telegesis (UK) Ltd ZigBee Communications Gateway... - Page 3 Figure 14: Firmware Upgrade page ....................24 Figure 15: Logout page ........................27 Figure 16: Dialin socket connection ....................28 Figure 17: ETRX3 Bootload prompt ....................29 Figure 18: Ready to receive upgrade image file via XMODEM ............30 ©2013 Telegesis (UK) Ltd ZigBee Communications Gateway...
-
Page 4: Abbreviations
Hyper Text Transfer Protocol UPnP Universal Plug and Play User Datagram Protocol Transmission Control Protocol Secure Socket Layer Domain Name System SNTP Simple Network Time Protocol DHCP Dynamic Host Control Protocol Internet Protocol Media Access Control ©2013 Telegesis (UK) Ltd ZigBee Communications Gateway... -
Page 5: Package Contents
ZigBee Communications Gateway Package Contents The package contains the following items, Figure 1: Package contents a. ZigBee Communications Gateway b. Micro USB power cable c. Mounting screws ©2013 Telegesis (UK) Ltd ZigBee Communications Gateway... -
Page 6: Specifications
SD Memory Card size i.e. 4, 8 etc. Examples GW-357-11-P-W-1-8 Gateway with 2xETRX357 module, Power-over-Ethernet, WiFi, RS232/RS485 and an 8MB SD Memory Card GW-357-1 Basic Gateway with 1xETRX357 module GW-357-30-0-0-1 Gateway with 1xETRX357-LRS and RS232/RS485 ©2013 Telegesis (UK) Ltd ZigBee Communications Gateway... -
Page 7: Layout
ETRX3 Status LED Interface Active LED Gateway Activity LED Link Status LED LED1 ETRX3 Status Figure 2: Gateway front view Ethernet connector RJ45 Micro USB power socket Button-2 (B2) Figure 3: Gateway back view ©2013 Telegesis (UK) Ltd ZigBee Communications Gateway... -
Page 8: Figure 4: Gateway Bottom View
ZigBee Communications Gateway Anti-slip pads Mounting holes Button-1 (B1) Button-3 (B3) Opening for battery and SD card holder Anti-slip pads Figure 4: Gateway bottom view Power supply ratings Gateway MAC address Figure 5: Top label ©2013 Telegesis (UK) Ltd ZigBee Communications Gateway... -
Page 9: Power
The Gateway can be powered ON by plugging in the micro USB cable in the socket provided as shown in figure-3 with power source as specified in the Specifications. Selected models of gateway incorporating Power over Ethernet (PoE) can be powered on using the PoE injector through RJ45 cable. ©2013 Telegesis (UK) Ltd ZigBee Communications Gateway... -
Page 10: Led Indicators
Ethernet link active Green Any socket connected to Green either ZigBee module Web Terminal connected Any communication with Blinking ZigBee modules Amber Any communications on Ethernet lines Table 2: LED Sequence table ©2013 Telegesis (UK) Ltd -10- ZigBee Communications Gateway... -
Page 11: Buttons Actions
So whenever the B2 is pressed the command (“AT+PJOIN” by default) is issued to the 1 ETRX3 ZigBee module. Recovery mode not implemented in initial release but will be added in subsequent release soon. ©2013 Telegesis (UK) Ltd -11- ZigBee Communications Gateway... -
Page 12: Functionality
Browse to the IP address shown in the device properties or alternatively double click on the device to navigate to the webpage hosted by Gateway. Figure 7: Device Discovery ©2013 Telegesis (UK) Ltd -12- ZigBee Communications Gateway... -
Page 13: Discovery On Other Platforms
= 14099 #start a udp socket server to listen on port 14099 s = socket.socket(socket.AF_INET, socket.SOCK_DGRAM) s.setsockopt(socket.SOL_SOCKET, socket.SO_REUSEADDR, 1) s.setsockopt(socket.SOL_SOCKET, socket.SO_BROADCAST, 1) s.bind((host, port)) print "Waiting for Telegesis Gateway:" while 1: try: message, address = s.recvfrom(8192) print "Telegesis Gateway... -
Page 14: Gateway Webserver
“password” password must be provided when prompted to access the webpages. The password can be changed through the GW357 Configuration webpage as explained in the later section. Figure 10: HTTP server authentication ©2013 Telegesis (UK) Ltd -14- ZigBee Communications Gateway... -
Page 15: Web Pages
Gateway provides an access to the ZigBee module via Web Terminal page which can be used to issue commands to the ZigBee module and monitor the response of the module. The Web Terminal only supports communication in ASCII. Default value is enabled. ©2013 Telegesis (UK) Ltd -15- ZigBee Communications Gateway... - Page 16 This option enables the SSL on the outgoing socket connection This option only available in Gateway models with two ZigBee modules on-board. Please refer order codes The SSL is not implemented in current release. ©2013 Telegesis (UK) Ltd -16- ZigBee Communications Gateway...
- Page 17 This is a command string that will be sent to the 1 ETRX3 ZigBee module each time the Button-2 (B2) is pressed. This option only available in Gateway models with two ZigBee modules on-board. Please refer order codes ©2013 Telegesis (UK) Ltd -17- ZigBee Communications Gateway...
- Page 18 The current time of the gateway is displayed in this field when the page is loaded or is clicked. After changing any settings on the webpage must be clicked in order to apply the changes to Gateway configuration. Following message will be displayed to confirm the change. ©2013 Telegesis (UK) Ltd -18- ZigBee Communications Gateway...
- Page 19 The gateway uses the subnet mask specified in this field as subnet mask when DHCP option is not selected. Default Gateway The gateway uses the default gateway specified in this field as default gateway when DHCP option is not selected. ©2013 Telegesis (UK) Ltd -19- ZigBee Communications Gateway...
- Page 20 Default IP Configurations 1. DHCP Enable : Enabled 2. Static IP Address : 192.168.204.121 3. Subnet Mask : 255.255.255.0 4. Default Gateway : 192.168.204.10 The SSL is not implemented in current release. ©2013 Telegesis (UK) Ltd -20- ZigBee Communications Gateway...
- Page 21 Fill in all the fields and hit change to apply new password. Once the password is changed successfully the following message will be displayed. Password can also be reset to factory default by restoring factory default configurations mentioned in Buttons Actions. ©2013 Telegesis (UK) Ltd -21- ZigBee Communications Gateway...
-
Page 22: Figure 12: Zigbee Interface Configurations Page
ZigBee Communications Gateway ZigBee Interface Configurations Figure 12: ZigBee Interface Configurations page The Gateway comes with Telegesis ZigBee AT-commands Firmware programmed onto the assembled ETRX3 ZigBee module. This firmware communicates at baud rate settings of 19200- 8N1. The ZigBee Interface Configurations page is useful to change the serial settings of the gateway serial ports connected to the ETRX3 ZigBee modules. -
Page 23: Figure 13: Web Terminal Page
ZigBee module and expect the response in approximately one sec. Please refer AT-commands documentation at Telegesis document centre Note: Pressing Enter Key on Keyboard will NOT send the command but will refresh the page. ©2013 Telegesis (UK) Ltd -23- ZigBee Communications Gateway... -
Page 24: Figure 14: Firmware Upgrade Page
Each image stored in the Gateway has an Image Header for identifying the type of image. This field displays the image header of selected Image type. Firmware Version This field displays the firmware version of image stored. Image Size This field displays the size of stored image in bytes. ©2013 Telegesis (UK) Ltd -24- ZigBee Communications Gateway... - Page 25 Gateway “FW image sent successfully” message is displayed in a new tab in the browser. Recovery bootloader mechanism is not implemented in the initial release but will be implemented in subsequent release soon. ©2013 Telegesis (UK) Ltd -25- ZigBee Communications Gateway...
- Page 26 Upgrading may take few minutes, be patient and do not interrupt the upgrade process until power up sequence is indicated on the LED panel. The upgrade process will be indicated by blinking of gateway activity LED. ©2013 Telegesis (UK) Ltd -26- ZigBee Communications Gateway...
-
Page 27: Figure 15: Logout Page
ZigBee Communications Gateway Support Support link will redirect to telegesis Support page on the internet http://www.telegesis.com/support/ Logout Logout will end current session and “Logged out successfully” message will be displayed and the user will need to authenticate with username and password at the next login. -
Page 28: Bootloading Etrx3 Zigbee Module
2. Make sure dialin socket is enabled for the 1 ETRX3 ZigBee module as shown below 3. Connect to the Gateway’s dialin socket for the 1 ETRX3 ZigBee module using Telegesis terminal (Version 4 or higher) as shown below. Figure 16: Dialin socket connection ©2013 Telegesis (UK) Ltd... -
Page 29: Figure 17: Etrx3 Bootload Prompt
5. Navigate to ZigBee Interface Configuration and Select Module 1 as shown below. 6. Click to start the bootloader on selected ZigBee module. 7. Change the baudrate to 115200 and click 8. On Telegesis terminal hit Enter key to see following prompt Figure 17: ETRX3 Bootload prompt ©2013 Telegesis (UK) Ltd -29-... -
Page 30: Figure 18: Ready To Receive Upgrade Image File Via Xmodem
10. Go to Tools->Transfer File (XMODEM) and send the appropriate upgrade image file. 11. Once successful change the baudrate of module according to upgraded firmware and the ZigBee module will communicate according to the new firmware. For Telegesis R3xx firmware the default baud rate is 19200-8N1 ©2013 Telegesis (UK) Ltd... -
Page 31: Warranty
ZigBee Communications Gateway Warranty 1. Telegesis warrants that at the date of delivery the Goods will conform in all material respects to any written specification published or provided by Telegesis and that for the periods set out below in respect of each product type the Goods will be free from defects in workmanship and materials under normal use and service. -
Page 32: Caution
ZigBee Communications Gateway 5. If the goods are to be manufactured or any process is to be applied to them by Telegesis in accordance with a specification submitted by the Buyer, the Buyer shall indemnify Telegesis against all loss, damages, costs and expenses awarded against or incurred by Telegesis in... -
Page 33: Compliance With Laws And Regulations
Any Buyer of Telegesis products (Goods) will not knowingly sell the Goods to any person where such sale may be or may result in a sale to an end user that may put Telegesis in breach of any laws, embargoes or regulations from time to time or any relevant jurisdiction. The Buyer hereby... - Page 34 Partner in Electronic Components & Supply Chain Solutions The Netherlands Denmark Elektrostraat 17 Nørregade 15 NL-7483 PG Haaksbergen DK-9240 Nibe Tel: +31 (0)53 573 33 33 Tel: +45 88 20 26 30 Fax: +31 (0)53 573 33 30 Fax: +45 88 20 26 39 nl@texim-europe.com nordic@texim-europe.com Belgium...
