PuriTeam Purity UC-12, UCD-12 & UCD-12C
UNDER-COUNTER WATER FILTER MANUAL
IMPORTANT: INSPECT ALL PARTS AND FILTER CARTRIDGES FOR ANY DAMAGE.
Congratulations on your purchase of the high quality Purity under counter water filter system
for you and your family! You will enjoy fresh, clear water for years to come.
Operating Specifications
Temperature range: 39°F - 100°F (4°C-38°C).
Service Flow: 1 gpm (3.8 L./min.)
Rated Capacity: 12,000 gal. (45,425 L.)
Minimum to Maximum Operating pressure: 20 psi (1.4 bar) to 125 psi (8.6 bar)
Components
UC Filter Unit w/blue & red tubing
GAC/KDF Cartridge (inside unit)
1 mic. Pre-filter (UCD only)
Ceramic Pre-filter (UCD-C only)
Faucet Spigot
Beveled Spacer Disk (black)
Rubber Gasket
Flat Spacer Disk (black)
Lock Washer
Brass Nut
Quick Connect Faucet Fitting (gray)
EZ Faucet Connector (tri-colored)
IMPORTANT NOTE: For UCD-C, under counter filters with ceramic pre-filter, it is necessary to remove the
bubble wrap from the ceramic cartridge and insert ceramic filter into the housing on the inlet side of the filter (red
tubing). Insert the cartridge with screen side facing the threaded opening. If installed improperly, no water will
pass through the filter. Simply remove cartridge and re-insert correctly.
1.
Find a convenient location under the sink on the cold water side to place the filter. The system is only to
be supplied with cold water.
2.
The faucet spigot should be secured through an existing hole in the sink ledge (such as a sprayer or soap
dispenser) or a ½" hole can be drilled in the desired location. If you have a porcelain sink, you might
consider having a professional do the drilling, or install the faucet into the countertop, back from the sink
ledge.
INSTALLATION INSTRUCTIONS
