Summary of Contents for RTI VTX-T
- Page 1 User Manual VTX-T Ultra-thin HDBaseT Transmitter All Rights Reserved Version: VTX-T_2017V1.0...
-
Page 2: Fcc Statement
Ultra-thin HDBaseT Transmitter Preface Read this user manual carefully before using the product. Pictures shown in this manual is for reference only, different model and specifications are subject to real product. This manual is only for operation instruction only, not for any maintenance usage. The functions described in this version are updated till November 3, 2017. -
Page 3: Safety Precautions
Ultra-thin HDBaseT Transmitter SAFETY PRECAUTIONS To insure the best from the product, please read all instructions carefully before using the device. Save this manual for further reference. Unpack the equipment carefully and save the original box and packing material for possible future shipment ... -
Page 4: Table Of Contents
Ultra-thin HDBaseT Transmitter Table of Contents 1. Introduction ......................... 1 1.1 Brief Introduction ....................1 1.2 Features ......................1 1.3 Package Contents ..................... 1 2. Panel Description ......................2 2.1 HDBaseT Transmitter ..................2 2.2 Twisted Pair Cable Description ................3 3. -
Page 5: Introduction
Note: Please use a CAT5e cable with low impedance (Shielded twisted pair will be better and should be well grounded for good transmission effect. 1.3 Package Contents 1 x VTX-T 2 x Mounting ears 4 x Black Plastic cushions 2 x Screws ... -
Page 6: Panel Description
Ultra-thin HDBaseT Transmitter 2. Panel Description 2.1 HDBaseT Transmitter LINK HDCP RS232 IR IN IR OUT HDMI IN HDBT OUT ETHERNET ETHERNET DC 24V Name Description HDBT Link status indicator: OFF: No Link ① LINK GREEN:Link Successful Blinking GREEN: Link abnormal HDCP compliant indicator ... -
Page 7: Twisted Pair Cable Description
Ultra-thin HDBaseT Transmitter the yellow LED indicators on the corresponding ports will keep blink and the green ones will keep on when working. Connect with DC24V 1.25A power adaptor. (Not necessary if ⑪ DC 24V Receiver connects with power). Pictures shown in this manual are only for reference. -
Page 8: System Connection
Projector Laptop 3.3 Connection Procedure Step1. Connect HDMI source (such as DVD player) to HDMI IN port of the VTX-T with HDMI cable. Step2. Connect HDBT OUT port of VTX-T and HDBT IN port of Receiver with single CAT5e/CAT6a cable. -
Page 9: Application
Ultra-thin HDBaseT Transmitter Emitter must be connected to “IR OUT” of VTX-T. Step5. To set as a LAN, one of the four ETHERNET ports of VTX-T and Receiver should be used for Internet access, and the others can be connected with computers. -
Page 10: Specification
Ultra-thin HDBaseT Transmitter 4. Specification Input Input Signal (1) HDMI; (1) IR IN; (1) RS232 Input Connector (1) HDMI female; (1) 3.5mm mini jack; (1) 3P captive connector Video Signal HDMI1.4 Output Output (1) HDBaseT; (1) IR OUT (1) RS232 Output Connector (1) RJ-45;... -
Page 11: Panel Drawing
Ultra-thin HDBaseT Transmitter 5. Panel Drawing LINK HDCP RS232 IR IN IR OUT HDMI IN HDBT OUT ETHERNET ETHERNET DC 24V 152 mm... -
Page 12: Troubleshooting & Maintenance
Ultra-thin HDBaseT Transmitter 6. Troubleshooting & Maintenance Problems Potential Causes Solutions Incorrect setting on the Check the display’s setting. display Output images in display show with ghost Try another high quality A cable of bad quality connection cable. Check with oscilloscope or No signal at the input / output multimeter if there is any signal at the input / output... -
Page 13: Customer Service
Ultra-thin HDBaseT Transmitter 7. Customer Service The return of a product to our Customer Service implies the full agreement of the terms and conditions hereinafter. There terms and conditions may be changed without prior notice. ① Warranty The limited warranty period of the product is fixed 3 (three) years. ②... - Page 16 Remote Technologies Incorporated 5775 12th Avenue East, Suite 180 Shakopee, MN 55379 Tel: 952-253-3100 Fax: 952-253-3131 www.rticorp.com...
