Summary of Contents for eBEAM SMARTMARKER
- Page 1 Userguide www.e-beam.com...
- Page 2 Components Digital Marker Smartmarker Sleeve Sensor power status marker release Bluetooth status Digital Marker color ring Power status...
- Page 3 USB dongle eraser felt eraser USB cable magnetic plate magnetic plate for sensor for eraser single charger manual...
- Page 4 Main Key Features power on/off new page or duplicate page memory mode Bluetooth mode...
- Page 5 Windows e-beam.com Computer About the USB Dongle The USB dongle is for Windows users only. In order to connect to the eBeam Smartmarker, plug the USB dongle in to your Windows PC. Make sure you install eBeam Note from www.e-beam.com...
- Page 6 Installing the eBeam Smartmarker Attach the magnetic mounting bracket to the back of the sensor by lining up the bump on the bracket with the indent on the back of the sensor. Remove the protective backing on the tape and place the sensor firmly onto the surface.
- Page 7 Download the app. iPhone & iPad iPhone & iPad Android Windows www.e-beam.com/smgo Power on the sensor. power on/off Windows users should connect the USB dongle to their computer at this time.
- Page 8 Start the eBeam Note application. eBeam Note will search for your sensor. Once the sensor is found, select the sensor name on the list. If the sensor is not found, check the scenarios listed in the message box to help you find a solution.
- Page 9 The application will notify you when your sensor is connected. TIP: No matter where you are in the mobile application, when you start writing, you will automatically be navigated to a new page screen where everything you write is captured. Main Menu Screen Page Screen Previews Screen...
- Page 10 Sensor memory can save up to 20,000 pages. TIP: Notes saved on the sensor can only be downloaded by connecting the USB cable to your PC (Windows/Mac). For more details, navigate to the ‘help’ menu in the eBeam Note desktop application.
- Page 11 Downloading Memory Data (Windows/Mac) Download steps: Connect the eBeam Smartmarker Sensor to your PC using the provided USB cable. Power the sensor on. To start the download, in eBeam Note, navigate to: Menu --> Memory --> Download Memory If the memory cannot be found, follow the above steps.
- Page 12 Set Up Your Board Size The default board size is 8ft x 5ft and set for the sensor to be placed on the left side of the whiteboard or capture area. Leave a 2 inch space between the sensor and your capture area.
- Page 13 Board Size - Maximum Size The default board size is set to the maximum capture area, 8ft x 5ft. On the diagram, choose the location of where you installed your sensor. capture area If you choose the right sensor location, the board size will automatically be adjusted to 8ft x 5ft with the capture area on the left side of the sensor.
- Page 14 Inserting the Whiteboard Marker into the Digital Marker Sleeve. Press the side button with the ridges to open the end of the digital marker. Insert the marker and close the end. Compatible whiteboard markers: e-boardmarker Expo Legamaster bold color dry marker low odor e-boardmarker Sharpie Sharpie...
- Page 15 The Eraser The eraser is powered using a single AA battery. To replace the battery, slide the top cover open and insert a new one. When the LED light turns in red, it means the battery power is low. – Sensor LED Meanings Color Action...
- Page 16 The capture signal may be influenced by loud sounds such as vacuum cleaners or metal clinking sounds. The capture signal may be influenced by other IR or ultra sound products. Please disable these other products before using eBeam Smartmarker.
- Page 17 Write anything, anywhere on the board. The application automatically opens a new page and captures everything you write. Use the icon shown below to connect or disconnect the Smartmarker sensor. Press the icon to disconnect Press the icon to connect Converting handwriting to text...
- Page 18 Create a Meeting to share notes in real-time. To create a meeting, navigate to Meeting --> Create meeting. Mobile After creating the meeting, invite as many people as you would like. For a dynamic and interactive meeting experience, the meeting host can give participants write permissions allowing them to write on the board.
- Page 19 FCC Information to User This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions, may cause harmful interference to radio communications.
- Page 20 Please note that the use of this accessory with iPod, iPhone, or iPad may affect wireless performance. © 2017 PNF Co., Ltd. All Rights Reserved. eBeam and the eBeam Logo are registered trademarks of PNF Co., Ltd.
